See all parts that fit your 2002 Cooper

JVC CS-FX502

** CLOSEOUT!! ** 5-1/4" 2-way Speakers with Aramid Fiber Cones for Superb Sound

JVC
Shop all JVC
Product videos
highlight-star-icon

5.25" Car Speakers • 180W Max • 60W RMS • Cloth carbon and aramid fiber cone woofer • Butyl rubber surround • Titanium dome tweeter • 4 ohm impedance

Learn more about the csfx502

We apologize

This item has been discontinued


Loading...
KMM-BT732HD main

Kenwood KMM-BT732HD

Single DIN Digital Media Bluetooth Receiver with HD Radio

3
-14.09%

$189.00

List price $220.00

MPR2110 main

Jensen MPR2110

Single DIN Digital Media Receiver with Bluetooth

13
Lowest price in 30 days
H7694 main

Cerwin Vega H7694

800W Peak (150W RMS) 6x9" HED Series 4-Way Coaxial 4-ohm Speakers

32
-25.93%

$79.99

List price $107.99

H7653 main

Cerwin-Vega H7653

680W Peak (120W RMS) 6.5" HED Series 3-Way Coaxial 4-ohm Speakers

43
-16.67%

$79.99

List price $95.99

C2-690tx main

JL Audio C2-690tx

140W RMS 6x9" C2 Series 3-Way Coaxial 4-ohm Car Speakers

21

Crunch CS653

600W Peak (120W RMS) 6.5" CS Series 3-Way Coaxial 4-ohm Car Speakers

21
-9.09%

$29.99

List price $32.99

Kenwood KFC-6996PS

1300W Peak (300W RMS) 6x9" Performance Series 5-way Dual 4-ohm Coaxial Car Speakers

2
-46.67%

$79.99

List price $150.00

Limited time!

Kenwood KFC-ST01

320W Peak (80W RMS) 1" KFC Series PEI Balanced Dome Car Tweeters

11
-37.89%

$59.00

List price $95.00

Product Highlights


5.25" Car Speakers • 180W Max • 60W RMS • Cloth carbon and aramid fiber cone woofer • Butyl rubber surround • Titanium dome tweeter • 4 ohm impedance

Description


JVC brand icon

Authorized dealer

  • 5-1/4" Car Speakers
  • Power Handling:
    • Peak: 360 watts per pair / 180 watts each
    • RMS: 120 watts per pair / 60 watts each
  • Cloth carbon and aramid fiber cone woofer
  • Butyl rubber surround
  • Titanium dome tweeter
  • 4 ohm impedance
  • Strontium magnet
  • Top-mount depth: 2.24"
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Priced Per Pair


Loading...
CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

AVH-3500NEX main

Pioneer AVH-3500NEX

7" Single DIN Flip-Out Touchscreen CD/DVD Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

9
-10.75%

$829.99

List price $930.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

DEH-S7200BHS main

Pioneer DEH-S7200BHS

Single DIN CD Receiver with Bluetooth, HD Radio and SiriusXM Ready

2
-10.72%

$249.99

List price $280.00

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00

Limited time!
CAR1013 main

Jensen CAR1013

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto

5
-11.43%

$309.99

List price $349.99

KDC-BT782HD main

Kenwood KDC-BT782HD

Single DIN CD Receiver with Bluetooth, Built-in Alexa, and HD Radio Tuner (SiriusXM Ready)

5
-18.89%

$219.00

List price $270.00


Best selling similar products

Club 522F small

JBL Club 522F (SPKCB522FAM)

• 135 watts Peak Each, 45 watts RMS Each
• Silk Edge Driven Dome tweeters
• UV-Resistant Polypropylene cone material
• Plus One woofer architecture
• Impedance: 3 ohm
• Sensitivity: 91 dB

$74.99

List price $129.95

46CSC54 small

Kicker CSC5 (46CSC54)

• 225 watts Peak Each, 75 watts RMS Each
• 1/2" PEI (Polyetherimide) Balanced Dome tweeters with neodymium magnets
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 90 dB

(5)

$79.96

List price $119.99

43DSC504 small

Kicker DSC50 (43DSC504)

• 200 watts Peak Each, 50 watts RMS Each
• 1/2" PEI (Polyetherimide) Balanced Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 90 dB

(17)

$74.99

List price $84.99

VSP525 small

NVX VSP525

• 240 watts Peak Each, 80 watts RMS Each
• 1" Silk Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 88 dB
• Mounting Depth: 2.16"

(23)

$79.99

List price $95.99

THUNDER52 small

MTX Audio THUNDER52

• 45 watts RMS Each
• 1" Silk Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 92 dB

(2)

$95.96

List price $119.95

TS-G1320S small

Pioneer TS-G1320S

• 250 watts Peak Each, 35 watts RMS Each
• 1-3/16" Polyethylene Terephthalate (PET) Balanced Dome tweeters
• Mica Injected Polypropylene - MIPP cone material with Progressive Flex Suspension System (PFSS) spider
• Impedance: 4 ohm
• Sensitivity: 87 dB

(7)

$44.99

List price $65.00

DB522 small

Polk Audio DB522 (DB 522)

• 300 watts Peak Each, 100 watts RMS Each
• 3/4" Silk Dome tweeters
• UV-tolerant Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 91 dB

(13)

$100.00

List price $109.99

T152 small

Rockford Fosgate Power T1 T152

• 120 watts Peak Each, 60 watts RMS Each
• 1" Aluminum Dome offset cantilever coaxial mounted tweeters
• Polypropylene-Carbon Fiber Hybrid cone material
• Impedance: 4 ohm
• Sensitivity: 86.5 dB

(22)

$219.99

List price $219.99

P152 small

Rockford Fosgate Punch P1 P152

• 80 watts Peak Each, 40 watts RMS Each
• 3/4" PEI (Polyetherimide) Dome tweeters
• Mineral-Filled Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 87 dB

(27)

$109.99

List price $109.99

PNW-525 small

AudioControl PNW-525

• 75 watts Peak Each, 50 watts RMS Each
• Hybrid Silk Dome tweeters
• Rigid Poly Mica cone material
• Impedance: 3 ohm
• Sensitivity: 88.41 dB

(1)

$239.00

List price $259.00

Specifications & Details


Speaker Specifications
Speaker Size
5-1/4"
Design
2-way Coaxial
Tweeter Design
Dome
Tweeter Composition
Titanium
Woofer Composition
Cloth Carbon Aramid Fiber
Woofer Surround
Butyl Rubber
Peak Power Handling
180 watts
RMS Power Handling
60 watts
Impedance (Per Voice Coil)
4 ohm
Top-Mount Depth (Mounting Depth)
2.24"
Bottom-Mount Depth
3.09"
Cutout Dimensions
4.53" x 4.53"
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

JVC

Model Number:

CS-FX502

Weight:

7.00lbs

Internal SKU:

csfx502

Internal Product ID:

12121

Product and How-to Videos


Customer Ratings & Reviews


JVC CS-FX502 thumbnail image

5 star
75%
4 star
25%
3 star
0%
2 star
0%
1 star
0%



Durability
4
Value
5
Features
5
Design
4.8
Usability
5

Customer Reviews

Sort by:

Loading...

Awesome!!!

I love these speakers. I installed them in the front doors and installed 6 X 9 separate components in the rear deck, including 6 tweeters throughout the car. They sound GREAT...amazing how much kick they have for such small speakers. I highly recommend them...especially at that price.

By Eli on December 3, 2009

7 found this helpful


jvc speakers

I put 2 sets jvc cs-fx502 (4 speakers) in my semi truck w/a jvc hd 50 stereo head and a jvc cs-bbs pre amp sub woofer they sound great together.

By northstar1995 on October 19, 2009

7 found this helpful


Great sounding at a great price!

Excellent speakers for rear fill, should sound good as the mains up front also. Easily handle cranked up 55w RMS with HPF set at 125.

By mark on January 4, 2010

7 found this helpful


JVC Delivers!

I have these in the rear roof of my jeep, and Infinities in the front. They are each getting at least 35 watts RMS from a 200.4 kicker 4 channel amplifier and they scream. Super clear highs and mids. Highly recommend them. Titanium tweeters are more durable, yes, a little more harsh than silk domes, but i'm hard on my stereo equipment. Great speakers, big ol' magnet so make sure you have te room. The tweeter doesn't stick out like other speakers so thats good! BTW... They are biampable, and come with eternal crossovers! BUY THEM!

By oldskewl on May 31, 2009

4 found this helpful
