JBL CS300.1 R/B

460W Max, Monoblock Class D CS Series Amplifier

JBL
Shop all JBL
Product videos
highlight-star-icon

CS Series 1-Channel Class D Car Amplifier • 200W x 1 chan. @ 4 ohm • 300W x 1 chan. @ 2 ohm • 460W Max x 1 chan. • LED power and protection indicators • CEA-2006 compliant amplifier

Learn more about the LS-cs3001-RB

We apologize

This item has been discontinued

Product Highlights


CS Series 1-Channel Class D Car Amplifier • 200W x 1 chan. @ 4 ohm • 300W x 1 chan. @ 2 ohm • 460W Max x 1 chan. • LED power and protection indicators • CEA-2006 compliant amplifier

Description


JBL brand icon

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

  • CS Series 1-Channel Class D Car Amplifier
  • RMS Power Rating:
    • 4 ohm: 200 watts x 1 chan.
    • 2 ohm: 300 watts x 1 chan.
  • Max power output: 460 watts x 1 chan.
  • LED power and protection indicators
  • Tuned Bass EQ (0-6 dB bass boost at 50 Hz)
  • Single channel operation
  • Preamp RCA outputs
  • DC protection circuitry
  • Variable low-pass filter (32-320 Hz, 24 dB/octave)
  • CEA-2006 compliant amplifier
  • Frequency response: 10-300 Hz
  • Dimensions: 12-11/16" L x 10-1/4" W x 2-3/16" H
  • 8-gauge power and ground leads recommended. Contact us for information regarding a discount on a select amplifier kit when purchased together.
  • 1-year SonicElectronix.com warranty

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
200 watts x 1 channel
RMS Power @ 2 ohms
300 watts x 1 channel
Amplifier Specifications
Amplifier Class
D
Number of Channels
1 - Mono
Total Peak Power Output
460 watts
Total RMS Power Output
300 watts
Minimum Impedance Unbridged
2 ohm
THD at Rated RMS Power
1%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
Low-Pass Crossover Frequency
32 - 320 Hz
Signal-to-Noise Ratio
100 dB
Bass Boost
0 - 6 dB
Remote bass/level controller
No
Fuse Rating
20A x 2
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

JBL

Model Number:

CS300.1-RB

Weight:

10.00lbs

Internal SKU:

LS-cs3001-RB

Internal Product ID:

20438
