Pyramid PA305

300W, Professional Amplifier with LED Level Display and Front 3.5mm Auxiliary Input

Pyramid
Shop all Pyramid
highlight-star-icon

300W Professional Amplifier • Front 3.5mm AUX CD Input Jack • Controls Volume Up To 4 Microphones • Rotary Feedback Filter • Lighted VU Meter • Rack Mountable • Clipping and Protection LEDs

Learn more about the pa305

We apologize

This item has been discontinued


Loading...

Dual XRM59BT

Single DIN Digital Media Receiver with Bluetooth, USB and Aux

28

Description


Pyramid brand icon

Authorized dealer

General Features:
  • Professional Sound Reinforcement Amplifier
  • 300 Watts Output
  • Front 3.5mm AUX CD Input Jack
  • MIC 1 Talkover
  • PHONO/MIC 4 Input Selector
  • Phono RCA Inputs
  • THD Better Than 0.05%
  • Controls Volume Up To 4 Microphones
  • Controls Vol./Balance of Phono/CD/Aux
  • Master Output Level Control
  • Rotary Feedback Filter
  • Lighted VU Meter
  • Four 1/4'' & XLR Phone Jacks
  • EQ Input/Output Jacks with Bypass
  • Mix Bus Input Jack Connects To Another System
  • Clipping and Protection LEDs
  • 4, 8, 16 ohm & 70 Volt Speaker Outputs
  • 110/220 Voltage Selector
  • Heavy Duty Aluminum Heatsinks
  • Rack Mountable w/ Handles
  • Power On/Off Switch w/LED Indicator
  • Outputs for 1 or More 4, 8 or 16 Ohm Speakers
  • For Use w/all Mixers, PA Equipment, Home Audio
  • Dimensions: 11-15/16"D x 19"W x 4-15/16"H
  • 1-year Manufacturer's warranty
Specifications:
  • THD at 70 Watts, 8 Ohm, 1kHz, Bow-Pass Filter
    • MIC (PHONE Jack): 0.25%
    • MIC (XLR Jack): 0.35%
    • AUX: 0.20%
    • PHONO: 0.25%
  • Frequency Response (at 1W, +/- 3 dB)
    • MIC (PHONE Jack): 60 Hz - 20 kHz
    • MIC (XLR Jack): 80 Hz - 20 kHz
    • AUX: 80 Hz - 20 kHz
    • PHONO (RIAA 100 Hz/10 kHz): +12 dB/-12.5 dB
  • Input Sensitivity (at 2% THD, 1kHz)
    • MIC (PHONE Jack): 1.35 mV
    • MIC (XLR Jack): 1 mV
    • AUX: 150mV
    • PHONO: 2.8mV
  • Signal-Noise Ratio (Input Shorted) with WTD
    • MIC (PHONE Jack): 60dB
    • MIC (XLR Jack): 54dB
    • AUX: 73dB
    • PHONO: 60dB
  • Notch filter Effect
    • RANGE: 300Hz-3kHz
    • DEPTH: -12dB
  • Hum and Noise with 30kHz Low Pass Filter at 8 Ohm
    • At MASTER VOLUME MIN: 0.75 mV
    • At MASTER VOLUME MAX, Other MIN: 6 mV
