PAC AAI-CHY (aaichy) Audio Auxiliary Input Adaptor for Select

PAC AAI-CHY

Audio Auxiliary Input Adaptor for Select 2005-up Chrysler/Dodge/Jeep Vehicles

Audio Auxiliary Input Adaptor for Select 2005-up Chrysler/Dodge/Jeep Vehicles

• Auxiliary Audio Input For Chrysler, Dodge and Jeep Vehicles
• Satellite Or VES Option
• 2 AUX Inputs
• 12V Wire Output
• Adjustable Left/Right Signals

See compatible vehicles

3.6

(13)
List price $99.95
Save: $35.96

$63.99

Special Order. Ships at Later Date with warranty
Thanks , You Pay:
60Days
60-Day Money-Back

Hassle Free Returns

365days
365-Day Coverage

Warranty assistance for a year

DESCRIPTION
PAC

Authorized dealer

Product Features:

  • Auxiliary Audio Input for Chrysler, Dodge and Jeep vehicles with Satellite or VES option
  • 2 AUX Inputs
  • 12V Wire Output
  • Adjustable left/right signals
  • Works with Navigation (REC), 6 Disc/MP3 (RAQ), 6 Disc/Cassette (RAK) and Single Disc (REF) model radios. This is indicated on the front of the radios by the right knob.
  • 1-year Manufacturer's warranty

Compatibility List:

  • Dodge
    • 2004 - 2007 Durango
    • 2005 - 2007 Magnum
    • 2005 - 2007 Dakota
    • 2005 - 2007 Charger
    • 2006 - 2008 Caliber
    • 2006 - 2008 Ram
  • Chrysler:
    • 2005 - 2007 300
    • 2007 - 2008 PT Cruiser
    • 2007 Aspen
  • Jeep
    • 2005 - 2007 Commander
    • 2005 - 2007 Grand Cherokee
    • 2007 - 2008 Compass
    • 2007 - 2008 Patriot
  • Mitsubishi
    • 2006 - 2007 Raider

Note: In order for the harness to function properly, certain conditions must be met. 1) If the vehicle has both Satellite and VES, one of the devices will have to be disconnected. 2) If you are using a single disc radio (REF model), the factory SAT (if available) must be disconnected. This radio has no option for VES, therefore the AAI-CHY can not emulate it.

Connections:

  • Yellow – 12V Constant
  • Red – 12V Accessory
  • Black - Ground
  • Orange – Dash Light Dimmer/Illumination
  • Green – Left Rear Speaker (+)
  • Green with Black Stripe Left Rear Speaker (-)
  • White – Left Front Speaker (+)
  • White with Black Stripe – Left Front Speaker (-)
  • Purple – Right Rear Speaker (+)
  • Purple with Black Stripe – Right Rear Speaker (-)
  • Gray – Right Front Speaker (+)
  • Gray with Black Stripe – Right Front Speaker (-)
COMPATIBLE VEHICLES

Please use our Fitment Guide to determine specific compatibility for the submodel and audio features

  • 2005 Chrysler 300
  • 2005 Dodge Dakota
  • 2005 Dodge Durango
  • 2005 Dodge Magnum
  • 2005 Jeep Grand Cherokee
  • 2006 Chrysler 300
  • 2006 Chrysler PT Cruiser
  • 2006 Dodge Charger
  • 2006 Dodge Dakota
  • 2006 Dodge Durango
  • 2006 Dodge Magnum
  • 2006 Jeep Commander
  • 2006 Jeep Grand Cherokee
  • 2007 Chrysler 300
  • 2007 Chrysler Aspen
  • 2007 Chrysler PT Cruiser
  • 2007 Dodge Caliber
  • 2007 Dodge Charger
  • 2007 Dodge Dakota
  • 2007 Dodge Durango
  • 2007 Dodge Magnum
  • 2007 Dodge Ram 1500
  • 2007 Dodge Ram 2500
  • 2007 Dodge Ram 3500
  • 2007 Jeep Commander
  • 2007 Jeep Compass
  • 2007 Jeep Grand Cherokee
  • 2007 Jeep Patriot
  • 2008 Chrysler PT Cruiser
  • 2008 Dodge Caliber
  • 2008 Dodge Ram 1500
  • 2008 Dodge Ram 2500
  • 2008 Dodge Ram 3500
  • 2008 Dodge Ram 4500
  • 2008 Dodge Ram 5500
  • 2008 Jeep Compass
  • 2008 Jeep Patriot
FEATURES & SPECS
Product Features
Type of Auxiliary Input
Audio
Compatible Vehicle Make
Chrysler
Dodge
Jeep
Mitsubishi
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer
REVIEWS
PAC AAI-CHY

PAC AAI-CHY

3.6

(13)

Write a review

Overall rating distribution

5 star
38%
4 star
31%
3 star
0%
2 star
15%
1 star
15%

By feature average rating

Durability
3.4
Value
3.6
Features
3.8
Design
3.3
Usability
4.3

Robert

June 28, 2006

Works well - Just like I\'d expect from Pac-Audio

I have a 2006 Dodge Magnum Srt8 with Nav and no VES. This unit works just like it should and the install is so simple, I had it done in under 10 minutes.

Sonic had the best price after searching throughout the net and it was here the day after I ordered it with ground shipping!

The level adjustment is nice too.

38

found this helpful.

John

January 23, 2012

Great value

This is the solution for those of you who want the ease of adding an mp3 player without having to buy a whole new radio and interface components to interact with other car controls such as steering wheel controls.

32

found this helpful.

James Laugesen

September 10, 2012

Easy and reliable

I installed this in a 2005 Jeep Grand Cherokee WH (WK Export, Australia.) with the RAR 6-stacker CD radio (Export model, maybe the same as the US RER?).

Very straight-forward to install.
I just corrected the input volumes for my most common input devices (iphone and ipad.) and haven't touched it since.

I've been using it daily (music from my iphone through the stereo) for 6 months without any problems.

31

found this helpful.

Bandit

August 8, 2012

Short Term product

I now have owned a few of these; they are poor quality and will not last very long before problems start to rise. Some go without a problem but most people on the forums will tell you to go a different route. They are too expenisive to be consumable.

29

found this helpful.

JM

March 6, 2012

Garbage

This thing is junk. Like many other people, I had it work for a month, and then it would stop being recognized by the radio. To fix this, you either need to unhook the battery and reset everything in your vehicle, or take the dash apart and unplug the radio from power, then hook it all back up again. Not worth the money. I would never buy another one of these.

29

found this helpful.

Bill

January 28, 2013

Works as advertised but has some issues.

This works fine except that occasionally it goes to sleep and you have to pull the power to it to restore its function. I have had similar issues with other products from the same company.

29

found this helpful.

ethington04

January 18, 2011

This works like a charm

This was extremely easy to install in my 05 Jeep Grand Cherokee with navigation (REC) system. and it works perfect. A nice surprise is that my satellite radio still works also, I thought I was going to have to sacrifice it even though I do not use it. C** T**** wanted 300 bucks to do this same thing, maybe a little prettier, but I am not even sure about that. I paid 70 bucks. I am no mechanic and it was even easy for me to install. I was being very careful and didn't want to break any of the trim or short anything, and it took me about 30 minutes, most of that was deciding where to route the cable to go to my device. we will see if it holds up but for now I would recommend this for anyone wanting to add an aux. jack.

27

found this helpful.

CRD Patriot

January 30, 2013

Hey, look it worked!

The little black box arrived from its trip most of the way around the world remarkably quickly and incredibly well packaged.It was easy to install and I would recommend it to anyone who wants to listen to something other than the radio or those old fashioned CD's.

The only problem I have had is that it lost connectivity once in the 6 months I have had it installed. I simply disconnected the battery, re-connected it and Voila! back on the air!

26

found this helpful.

Dakota

September 20, 2012

works great - 2005 dakota

Easily installed, works as described. All I wanted was an additional 3.5mm aux input and this is the most cost effective way of doing it.

28

found this helpful.

Rasp

August 28, 2011

PAC AAI-CHY review

Product works great, but had to turn up output level, set to low from factory.

24

found this helpful.

Jay

July 5, 2006

Perfect

Easy install. Only took me 10 minutes. My DVD players sounds much better now. A must have when keeping stock radio but adding a DVD player.

24

found this helpful.

TCJoker

August 17, 2017

easy to install

This is easy to install, in my case all I needed was a Phillip head screwdriver! This is true plug and play. Now I have a AUX on my factory radio.

1

found this helpful.

Brian

May 30, 2017

Works half of the time

This is the second unit I have installed, first one did not work at all, second one worked for a short while, than failed, removed the unit, unplugged and plugged the unit back together, unit worked for another short time.
