See all parts that fit your 1983 CJ7

JL Audio 12W3v3-8

Single 8 ohm 12" W3v3 Subwoofer 12W3v3

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

12" Single 8 Ohm W3v3 Series Subwoofer • 1000W Max • 500W RMS • DMA (Dynamic Motor Analysis) modeling to deliver unsurpassed dynamic stability • DMA-optimized, long linear excursion • Mineral-filled polypropylene upper cone

Learn more about the 12w3v38

We apologize

This item has been discontinued


Loading...
R14X2 main

Rockford Fosgate Prime R14X2

120W Peak (60W RMS) 4” Prime Series 2 Way Coaxial 4-ohm Speakers

14
P152 main

Rockford Fosgate Punch P1 P152

160W Peak (80W RMS) 5.25" Punch Series 2 Way Coaxial 4-ohm Speakers

27

Product Highlights


12" Single 8 Ohm W3v3 Series Subwoofer • 1000W Max • 500W RMS • DMA (Dynamic Motor Analysis) modeling to deliver unsurpassed dynamic stability • DMA-optimized, long linear excursion • Mineral-filled polypropylene upper cone

Description


JL Audio brand icon

Authorized dealer

  • 12" Single 8 Ohm W3v3 Series Subwoofer
  • Power Handling:
    • Peak: 1000 watts
    • RMS: 500 watts
  • Impedance: Single 8 ohm
  • DMA-optimized, long linear excursion capability to virtually eliminate distortion and increase sound output
  • Perform outstanding in compact sealed or ported enclosures
  • DMA (Dynamic Motor Analysis) modeling to deliver unsurpassed dynamic stability and low-distortion operation within intended power range
  • Mineral-filled polypropylene upper cone with a metallic JL Audio medallion logo gives the W3's a whole new, classy and sophisticated look
  • Sensitivity: 87 dB
  • Free Air Resonance (Fs): 28.28 Hz
  • Electrical "Q" (Qes): 0.553
  • Mechanical "Q" (Qms): 6.936
  • Total Speaker "Q" (Qts): 0.512
  • Equivalent Compliance (Vas): 2.729 cu. ft (not recommended box size)
  • Xmax Linear Excursion: 0.510 in. / 13.0 mm
  • Driver Displacement: 0.071 cu. ft.
  • Net weight: 14.50 lbs.
  • Black Steel-Mesh Grille Insert Available: JL Audio SGRU-12
  • 1-year SonicElectronix.com warranty

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 12W3v3-8 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 12W3v3-8 Subwoofers

Mono Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 12W3v3-8 Subwoofers

Mono Amp

Wiring Guide to Wire 4 JL Audio 12W3v3-8 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged


Loading...
21576K main

Select Increments Intra-Pod (21576K)

Custom-fit center console subwoofer enclosure with 8" Kicker Subwoofer for select 1976-1995 CJ7 and Wrangler and Scrambler

1
-7.02%

$529.91

List price $569.94

21576KA main

Select Increments Intra-Pod (21576KA)

Custom-fit center console with 8" Kicker subwoofer and Amplifier for select 1976-2006 vehicles from Jeep

108
-13.10%

$729.90

List price $839.92

63092KA main

Select Increments Sono-Pod (63092KA)

Custom-fit subwoofer enclosure with 10" Kicker Subwoofer and 400W Monoblock

109
-17.58%

$543.90

List price $659.92

63092K main

Select Increments Sono-Pod (63092k)

Custom-fit enclosure with 10" Kicker subwoofer for

2
-11.80%

$343.91

List price $389.94

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00


Best selling similar products

Marine Club 12 small

JBL CB122 Club Marine 12

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Polypropylene Cone
• Rubber Surround
• Impedance: Single 4 ohm
• Mount depth: 7-13/16"
• Sensitivity: 89 dB

(1)

$119.95

List price $379.95

VCW124v3 small

NVX VCW124 Version 3 (VCW124v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(132)

$239.99

List price $287.99

SQW124 small

NVX SQW124

• Peak Power: 1200 watts
• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Polypropylene Cone
• Rubber Surround
• Mount depth: 3.51"
• Sensitivity: 84 dB

$299.99

List price $359.99

Specifications & Details


Subwoofer Specifications
Subwoofer Size
12"
Peak Power Handling
1000 watts
RMS Power Handling
500 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
8 ohm
Sensitivity
87 dB
Xmax (millimeters)
13 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mineral-Filled Polypropylene
Woofer Surround
Nitrile Butadiene Rubber NBR
Subwoofer Grille
Optional (Accessory required and sold separately)
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
1.25 cubic feet
Maximum Sealed Box Volume
1.25 cubic feet
Minimum Ported Box Volume
1.75 cubic feet
Maximum Ported Box Volume
1.75 cubic feet
Top-Mount Depth (Mounting Depth)
6.65"
Cutout Diameter
11.0625"
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

12W3v3-8

Weight:

18.00lbs

Internal SKU:

12w3v38

Internal Product ID:

7396

Product and How-to Videos


Customer Ratings & Reviews


JL Audio 12W3v3-8 thumbnail image

5 star
67%
4 star
33%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
4.4
Features
4
Design
4.7
Usability
4.7

Customer Reviews

Sort by:

Loading...

Nice Bass

man i have 2 friends that have this and these shizzles hit hard, nice, and clean..

1 friend has 2 of these in an unported box with an audiobahn 1200 watt amp pushin it and it raddles the hell out of you when your in it.. it feels like my eardrums are about to burst!

my other friend has a 01 toyota tacoma ext cab and he has 1 in a ported box while being pushed by a 1200 watt performance teknique amp and man oh man this is some clean ass bass! the ported box gives it a different deeper bass.. i like them in a ported box better but no doubt these speakers are a bad mutha lol.. i recomend these to anyone

By andrew on January 11, 2007

1 found this helpful


Clean Bass!!!!!

These are great subs for SQ!!!!!! I have these powered with a Rockford Fosgate Punch 700S amp and these subs can produce a loud bass without loosing any SQ. The only reason i got the 8 Ohm was because i got them cheap from a friend so if you were to buy W3's I would suggest getting the DVC 4 Ohm.

By Inland on March 6, 2009


i have had two of these in a suburban with a 1000/1 JL amp and they sound great. i would recommend this product to anyone.

By mike on March 6, 2008
