Pioneer TS-D6802R

6" x 8" 2-way D-Series Coaxial Car Speakers (also mounts in most 5" x 7" locations)

Pioneer
Shop all Pioneer
Product videos
highlight-star-icon

• Peak Power: 260W
• RMS Power: 60W
• Dual layer injection molded matrix fiber composite cone
• Butyl rubber surround
• 1-1/8" soft dome tweeter with rear chamber enclosure
• Passive crossover

Learn more about the tsd6802r

We apologize

This item has been discontinued


Loading...
70-1761 main

Metra 70-1761 Wiring Harness

Install a new car stereo in select 1984-2022 vehicles from Toyota, Subaru, Scion

97
-14.31%

$5.99

List price $6.99

SAC656 main

Scosche SAC656

Add 5-1/4" or 6-1/2" Speakers to Factory 7" Mounting Locations

50
-6.69%

$13.95

List price $14.95

99-8104 main

Metra 99-8104 Dash Kit

Install a new Single-DIN or Double-DIN car stereo in select 1984-2004 vehicles from Toyota

4
-10.42%

$42.99

List price $47.99

Limited time!
XAV-AX3200 main

Sony XAV-AX3200

6.95" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, WebLink, Apple CarPlay, and Android Auto (SiriusXM Ready)

14
-25.50%

$298.00

List price $399.99

Limited time!
46CSC354 main

Kicker CSC35 (46CSC354)

180W Peak (60W RMS) 3.5” CS Series 2 Way Coaxial 4-ohm Speakers

16
-30.71%

$51.96

List price $74.99

JBL GX608C (GX608CAM)

420W Peak (140W RMS) 6.5” GX Series 2 Way 2.3-ohm Component Speaker System

7

$119.95

Product Highlights


• Peak Power: 260W
• RMS Power: 60W
• Dual layer injection molded matrix fiber composite cone
• Butyl rubber surround
• 1-1/8" soft dome tweeter with rear chamber enclosure
• Passive crossover

Description


Pioneer brand icon

Authorized dealer



General Features

  • 6" x 8" Premier D-Series Car Speakers
  • Power Handling:
    • Peak: 520 watts per pair / 260 watts each
    • RMS: 120 watts per pair / 60 watts each
  • Injection molded matrix aramid-basalt fiber composite cone woofer
  • Butyl rubber surround
  • 1-1/8" Soft dome with magnetic fluid and neodymium magnet
  • Rear chamber tweeter structure
  • Full depth basket design for fuller bass response
  • Dispersion control wave guides
  • Compatible for mounting on Ford and Mazda installation
  • Built-in 12 dB/octave low/high pass crossover
  • Glass-imide voice coil bobbin
  • Conex damper
  • 4 ohm impedance
  • Top-mount depth: 2-3/4"
  • 1-year SonicElectronix.com warranty

Priced Per Pair

Product history:

Pioneer TS-D6802R thumbnail
(newest, current model)
Pioneer TS-D681R thumbnail
(previous model, replaced by Pioneer TS-D6802R)

Loading...
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

3
-19.05%

$339.99

List price $420.00

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

Limited time!
DMX709S main

Kenwood eXcelon DMX709S

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

20
-33.50%

$399.00

List price $600.00

Limited time!
iLX-W670-M main

Alpine iLX-W670-M

6.75" Double DIN Touchscreen Digital Multimedia Receiver with iDataLink Maestro Support, Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

2
-30.01%

$349.95

List price $500.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

MVH-S322BT main

Pioneer MVH-S322BT

Single DIN Digital Media Receiver with Bluetooth and Amazon Alexa

7
-13.34%

$129.99

List price $150.00


Best selling similar products

JS68K small

Jensen JS68K

• 250 watts Peak Each, 60 watts RMS Each
• 1-3/16" PEI (Polyetherimide) Dome tweeters
• 2-1/4" PEI (Polyetherimide) Dome midranges
• Woven Aramid Fiber cone material
• Impedance: 4 ohm
• Sensitivity: 88 dB

$139.99

List price $139.99

C1-570x small

JL Audio C1-570x

• 50 watts RMS Each
• 3/4" Silk-Suspended Aluminum Edge Driven Dome tweeters
• Mineral-Filled Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 93 dB

(4)

$129.99

List price $129.99

V68 small

Cerwin-Vega V68

• 300 watts Peak Each, 100 watts RMS Each
• 3/4" Silk Balanced Dome Tweeters
• Carbon Fiber Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 87 dB

$139.99

List price $139.99

Specifications & Details


Speaker Specifications
Series
D-Series
Priced Per
Pair
Speaker Size
6" x 8" (also mounts in most 5" x 7" locations)
Design
2-way Coaxial
Tweeter Design
Dome
Tweeter Composition
PEI (Polyetherimide)
Woofer Composition
Dual-Layer IMX Aramid/Basalt Fiber Composite
Woofer Surround
Butyl Rubber
Peak Power Handling
260 watts
RMS Power Handling
60 watts
Sensitivity
88 dB
Frequency Response
30 - 32,000 Hz
Impedance (Per Voice Coil)
4 ohm
Top-Mount Depth (Mounting Depth)
2-3/4"
Cutout Dimensions
7-1/2" x 5-1/4"
General specifications
Speaker Grilles
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

TS-D6802R

Weight:

5.70lbs

Internal SKU:

tsd6802r

Internal Product ID:

11270
