  6. Pioneer TS-D6802R-2

See all parts that fit your 2004 Expedition

Pioneer TS-D6802R (OPEN BOX COMPLETE)

6" x 8" 2-way D-Series Coaxial Car Speakers (also mounts in most 5" x 7" locations)

Pioneer
Shop all Pioneer
highlight-star-icon

• Peak Power: 260W
• RMS Power: 60W
• Dual layer injection molded matrix fiber composite cone
• Butyl rubber surround
• 1-1/8" soft dome tweeter with rear chamber enclosure
• Passive crossover

Learn more about the LS-tsd6802r-OBCRA233677

We apologize

This item has been discontinued

Show me more products from this category
Go to Category

Description

Pioneer brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

This is an Open Box Item


We have checked, tested, and confirmed this item to function properly. It contains all the same parts as a new unit, but shows some visible signs of use.

This open box product has a 30-day return policy and a 90-day warranty


Item Condition: Open Box Complete

  • Item has been installed, used.

    • General Features

    • 6" x 8" Premier D-Series Car Speakers
    • Power Handling:
      • Peak: 520 watts per pair / 260 watts each
      • RMS: 120 watts per pair / 60 watts each
    • Injection molded matrix aramid-basalt fiber composite cone woofer
    • Butyl rubber surround
    • 1-1/8" Soft dome with magnetic fluid and neodymium magnet
    • Rear chamber tweeter structure
    • Full depth basket design for fuller bass response
    • Dispersion control wave guides
    • Compatible for mounting on Ford and Mazda installation
    • Built-in 12 dB/octave low/high pass crossover
    • Glass-imide voice coil bobbin
    • Conex damper
    • 4 ohm impedance
    • Top-mount depth: 2-3/4"
    • 1-year SonicElectronix.com warranty

    Priced Per Pair

    Specifications & Details

    Speaker Specifications
    Series
    D-Series
    Priced Per
    Pair
    Speaker Size
    6" x 8" (also mounts in most 5" x 7" locations)
    Design
    2-way Coaxial
    Tweeter Design
    Dome
    Tweeter Composition
    PEI (Polyetherimide)
    Woofer Composition
    Dual-Layer IMX Aramid/Basalt Fiber Composite
    Woofer Surround
    Butyl Rubber
    Peak Power Handling
    260 watts
    RMS Power Handling
    60 watts
    Sensitivity
    88 dB
    Frequency Response
    30 - 32,000 Hz
    Impedance (Per Voice Coil)
    4 ohm
    Top-Mount Depth (Mounting Depth)
    2-3/4"
    Cutout Dimensions
    7-1/2" x 5-1/4"
    General specifications
    Speaker Grilles
    No
    Warranty and Return Policy
    Parts Warranty Duration
    90 days
    Labor Warranty Duration
    90 days
    Warranty Provider
    Sonic Electronix

    Item Details

    Manufacturer:

    Pioneer

    Model Number:

    TS-D6802R-2

    Weight:

    5.70lbs

    Internal SKU:

    LS-tsd6802r-OBCRA233677

    Internal Product ID:

    106231
