See all parts that fit your 1978 630CSi

Pioneer TS-D6802R Open Box Complete (Very Good, Used)

6" x 8" 2-way D-Series Coaxial Car Speakers (also mounts in most 5" x 7" locations)

Pioneer
Shop all Pioneer
highlight-star-icon

• Item Condition: Open Box
• Peak Power: 260W
• RMS Power: 60W
• Dual layer injection molded matrix fiber composite cone
• Butyl rubber surround
• 1-1/8" soft dome tweeter with rear chamber enclosure
• Passive crossover

Learn more about the ls-tsd6802r-obc6

We apologize

This item has been discontinued

Description


Pioneer brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Very Good Condition:
A Very Good Open Box used product represents a well-cared-for product that has seen only brief installation and/or limited use, but remains in great condition. The item is complete, unmarked, and undamaged, but may show some limited signs of wear. Original packaging, paperwork or protective wrapping may be missing or slightly damaged from the item being opened. Product works perfectly. Warranty details are included in the item description or comments.

Open Box (Complete): Item was previously installed and used. Item is in good condition and has been tested to be fully functional. Nonessential accessories (screws) may have been replaced with generic parts.

General Features

  • 6" x 8" Premier D-Series Car Speakers
  • Power Handling:
    • Peak: 520 watts per pair / 260 watts each
    • RMS: 120 watts per pair / 60 watts each
  • Injection molded matrix aramid-basalt fiber composite cone woofer
  • Butyl rubber surround
  • 1-1/8" Soft dome with magnetic fluid and neodymium magnet
  • Rear chamber tweeter structure
  • Full depth basket design for fuller bass response
  • Dispersion control wave guides
  • Compatible for mounting on Ford and Mazda installation
  • Built-in 12 dB/octave low/high pass crossover
  • Glass-imide voice coil bobbin
  • Conex damper
  • 4 ohm impedance
  • Top-mount depth: 2-3/4"
  • 1-year Manufacturer's Warranty

Priced Per Pair

Specifications & Details


Speaker Specifications
Series
D-Series
Priced Per
Pair
Speaker Size
6" x 8" (also mounts in most 5" x 7" locations)
Design
2-way Coaxial
Tweeter Design
Dome
Tweeter Composition
PEI (Polyetherimide)
Woofer Composition
Dual-Layer IMX Aramid/Basalt Fiber Composite
Woofer Surround
Butyl Rubber
Peak Power Handling
260 watts
RMS Power Handling
60 watts
Sensitivity
88 dB
Frequency Response
30 - 32,000 Hz
Impedance (Per Voice Coil)
4 ohm
Top-Mount Depth (Mounting Depth)
2-3/4"
Cutout Dimensions
7-1/2" x 5-1/4"
General specifications
Speaker Grilles
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

TS-D6802R Open Box Complete

Weight:

5.70lbs

Internal SKU:

ls-tsd6802r-obc6

Internal Product ID:

132483
