See all parts that fit your 1996 LS400

MTX FPR10-02 (Open Box)

600W Peak (300W RMS) 10" Flat Piston Round Series Single 2 Ohm Subwoofer

MTX
Shop all MTX
highlight-star-icon

• 600W Peak
• 300W RMS
• Molded Polypropylene woofer cone material
• Rubber surround
• Shallow mount application
• 1.75" High temperature voice coil

Learn more about the LS-fpr1002-OB

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Description


MTX brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.



General Features:

  • Item Condition: Like New, Open Box
  • 10" Flat Piston Round Series Car Subwoofer
  • Power Handling:
    • Peak: 600 watts
    • RMS: 300 watts
  • Recommended power range: 100 - 300 watts RMS
  • Impedance: Single 2 ohm
  • Molded Polypropylene woofer cone material
  • Rubber surround
  • Shallow mount application
  • One piece spider cone
  • 1.75" High temperature voice coil
  • 53oz. magnet motor structure
  • Frequency response: 25-150 Hz
  • Resonance Frequency (Fs): 35 Hz
  • Top-mount depth: 3-3/8"
  • Sensitivity: 81dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Product history:

MTX FPR10-02-OB thumbnail
(newest, current model)
MTX TT6510-02 thumbnail
(previous model, replaced by MTX FPR10-02 (Open Box))

This item is currently not eligible for our low price guarantee. This may be due to supply constraints, manufacturer restrictions, or another reason. We're always here to help you get the best price possible so give us a call or email today. Our experts will do their best to build the system that works for you within the rules.

Subwoofer Wiring Guide


Wiring Guide to Wire 1 MTX FPR10-02 (Open Box) Subwoofer

Mono Amp

Wiring Guide to Wire 2 MTX FPR10-02 (Open Box) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 3 MTX FPR10-02 (Open Box) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 MTX FPR10-02 (Open Box) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Flat Piston Round Series
Subwoofer Size
10"
Peak Power Handling
600 watts
RMS Power Handling
300 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
2 ohm
Voice Coil Diameter
1-3/4"
Frequency Response
25 - 150 Hz
Sensitivity
81 dB
Xmax (millimeters)
13 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Magnet Structure
Single Stacked
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Sealed
Minimum Sealed Box Volume
.60 cubic feet
Maximum Sealed Box Volume
.80 cubic feet
Top-Mount Depth (Mounting Depth)
3-1/3"
Cutout Diameter
9-1/8"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
35 Hz
Equivalent Compliance (Vas)
0.613 liters
Total Speaker Q Value (Qts)
0.746
Electrical Q Value (Qes)
.854
Electrical Resistance of Voice Coil (Re)
1.88 ohm
Mechanical Q Value (Qms)
5.890
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

MTX

Model Number:

FPR10-02-OB

Weight:

12.50lbs

Internal SKU:

LS-fpr1002-OB

Internal Product ID:

117193

Customer Ratings & Reviews


MTX FPR10-02 (Open Box) thumbnail image

5 star
75%
4 star
25%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
4.5
Usability
5

Customer Reviews

Sort by:

Loading...

Great

The following review is for FPR10-02, which is a part of the bundle you are viewing.

Tested according to the enclosed box MTX standards. Dynamic sub that hits hard.

By Fabien on February 13, 2014

28 found this helpful


Great shallow mount sub

The following review is for FPR10-02, which is a part of the bundle you are viewing.

I bought this sub to replace my discontinued Pioneer shallow mount (TS-SW2501S2) that got fried when my amp had two capacitors go bad. This sub plays the lows way better than the pioneer did with a 1/3 less gain put to it. Also, I run a very small box with poly-fill (0.35 cu. ft.) and this sub still performs.

By gmeek on November 17, 2014

24 found this helpful
