JL Audio 6W3V3-4 (Open Box, Great)

150W RMS 6.5" W3v3 Series Single 4-ohm Car Subwoofer

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

• RMS Power: 150 watts
• Impedance: Single 4 ohm
• Mineral-Filled Polypropylene Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 4.25"
• Sensitivity: 80.49 dB

Learn more about the ls-6w3v34-u8

We apologize

This item has been discontinued

Product Highlights


• RMS Power: 150 watts
• Impedance: Single 4 ohm
• Mineral-Filled Polypropylene Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 4.25"
• Sensitivity: 80.49 dB

Description


JL Audio brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.


JL Audio 6W3V3-4

If you need a small-format subwoofer that really delivers in extremely small enclosures, this is where your search ends. The 6W3v3 is a true subwoofer, through-and-through. It employs the same technologies as its larger diameter brethren to deliver a whopping 0.35 in. (8.9 mm) one-way linear excursion. The 6W3v3-4 is best used with amplifier power in the 50W - 150W range and is optimized to operate in a tiny 0.15 cu. ft. (4.2 l) sealed enclosure, or a 0.25 cu. ft. (7.1 l) ported enclosure.


Product Details:

  • 6.5" Single 4 ohm W3 v3 Series Subwoofer
  • Power Handling:
    • RMS: 150 watts
  • Mineral-Filled Polypropylene Cone
  • Nitrile Butadiene Rubber NBR Surround
  • Stamped steel basket
  • Customization trim ring
  • Floating-cone attach method
  • Highly linear, DMA-Optimized motor system
  • Insert molded suspension, coil and terminal sub-assembly
  • Patented vented reinforcement collar (VRC)
  • Elevated frame cooling design
  • Nickel plated brass spring terminals
  • Engineered lead-wire design and attachments
  • 8.89 mm Xmax
  • Single Stacked magnet motor structure
  • Resonance Frequency (Fs): 41.80 Hz
  • Sensitivity: 80.49 dB
  • Recommended sealed box volume: 0.15 cubic feet
  • Recommended ported box volume: 0.25 cubic feet
  • Top-mount depth: 4.25"
  • Cutout diameter: 5.50"
  • Authorized Internet Dealer
  • JL Audio SGRU-6 optional protective subwoofer grille (sold separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

PDF IconJL Audio 6W3V34 owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 6W3V3-4 (Open Box, Great) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 6W3V3-4 (Open Box, Great) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 6W3V3-4 (Open Box, Great) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 6W3V3-4 (Open Box, Great) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
W3 v3 Series
Subwoofer Size
6.5"
RMS Power Handling
150 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Frequency Response
30 - 300 Hz
Sensitivity
80.49 dB
Xmax (millimeters)
8.89 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mineral-Filled Polypropylene
Woofer Surround
Nitrile Butadiene Rubber NBR
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Re-Cone Kit Available
No
CTA-2031 Compliant
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.15 cubic feet
Optimum Ported Box Volume
0.25 cubic feet
Top-Mount Depth (Mounting Depth)
4.25"
Cutout Diameter
5.50"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
41.80 Hz
Equivalent Compliance (Vas)
5.13 liters
Total Speaker Q Value (Qts)
0.508
Electrical Q Value (Qes)
0.533
Electrical Resistance of Voice Coil (Re)
3.476 ohm
Mechanical Q Value (Qms)
11.027
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

LS-6w3v34-u8

Weight:

7.30lbs

Internal SKU:

ls-6w3v34-u8

Internal Product ID:

215768
