JL Audio 8W3V3-4 (Open Box, Like New)

250W RMS 8" W3v3 Series Single 4-ohm Car Subwoofer

JL Audio
Shop all JL Audio
highlight-star-icon

• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Mineral-Filled Polypropylene Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 4.63"
• Sensitivity: 83.24 dB

Learn more about the 8w3v34_obn

We apologize

This item has been discontinued

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


JL Audio 8W3V3-4

If you need an 8-inch subwoofer that can create outstanding bass in extremely small enclosures, the 8W3v3 will do the job and surprise you with its power and accuracy. It employs the same technologies as its larger diameter brethren to deliver a whopping 0.375 in. (10 mm) of controlled, one-way, linear excursion. The 8W3v3-4 is best used with amplifier power in the 75W - 250W range and is optimized to operate in a tiny 0.30 cu. ft. (8.5 l) sealed enclosure, or a 0.35 cu. ft. (9.9 l) ported enclosure.


JL Audio 8W3V3-4

250W RMS 8" W3v3 Series Single 4-ohm Car Subwoofer
Quantity: 1

Product Details:

  • 8" Single 4 ohm W3 v3 Series Subwoofer
  • Power Handling:
    • RMS: 250 watts
  • Mineral-Filled Polypropylene Cone
  • Nitrile Butadiene Rubber NBR Surround
  • Stamped steel basket
  • Customization trim ring
  • Floating-cone attach method
  • Highly linear, DMA-Optimized motor system
  • Insert molded suspension, coil and terminal sub-assembly
  • Patented vented reinforcement collar (VRC)
  • Elevated frame cooling design
  • Nickel plated brass spring terminals
  • Engineered lead-wire design and attachments
  • 10 mm Xmax
  • Single Stacked magnet motor structure
  • Resonance Frequency (Fs): 35.14 Hz
  • Sensitivity: 83.24 dB
  • Recommended sealed box volume: 0.30 cubic feet
  • Recommended ported box volume: 0.35 cubic feet
  • Top-mount depth: 4.63"
  • Cutout diameter: 7.09"
  • Authorized Internet Dealer
  • JL Audio SGRU-8 optional protective subwoofer grille (sold separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 8W3V3-4 (Open Box, Like New) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 8W3V3-4 (Open Box, Like New) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 8W3V3-4 (Open Box, Like New) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 8W3V3-4 (Open Box, Like New) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
W3 v3 Series
Subwoofer Size
8"
RMS Power Handling
250 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Sensitivity
83.24 dB
Xmax (millimeters)
10 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mineral-Filled Polypropylene
Woofer Surround
Nitrile Butadiene Rubber NBR
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Re-Cone Kit Available
No
CTA-2031 Compliant
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.30 cubic feet
Optimum Ported Box Volume
0.35 cubic feet
Top-Mount Depth (Mounting Depth)
4.63"
Cutout Diameter
7.09"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
35.14 Hz
Equivalent Compliance (Vas)
15.29 liters
Total Speaker Q Value (Qts)
0.467
Electrical Q Value (Qes)
0.501
Electrical Resistance of Voice Coil (Re)
3.77 ohm
Mechanical Q Value (Qms)
7.071
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

8W3V34_OBN

Weight:

9.70lbs

Internal SKU:

8w3v34_obn

Internal Product ID:

223962

Customer Ratings & Reviews


JL Audio 8W3V3-4 (Open Box, Like New) thumbnail image

5 star
87%
4 star
11%
3 star
0%
2 star
2%
1 star
0%



Durability
4.9
Value
4.7
Features
4.6
Design
4.9
Usability
4.9

Customer Photos & Videos


Customer Reviews

Sort by:

Loading...

Great sub

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

Sub has performed better than I thought it would. JL Audio has great products.

By Joe on May 13, 2012

85 found this helpful


Great Sub

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

Have 2 of these underneath the backseat in a F-150 2010 extended cab. Great sub hits the notes very LOUD!!! Great sub for having no space to put them. Have it setup w/ JL audio to get rid of factory speakers and you can hear every note high and low. Worth the buy. May be worried about not getting the bass you want. DON'T worry about that at all. Get a great box too and they work superb.

By Smiley Jake on December 22, 2011

84 found this helpful


THE BEST

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

I purchased these subs and I'm very pleased with them.

JL Audio makes a good product. I have made many buys from Sonic, very pleased.

By JIM on November 23, 2010

84 found this helpful


Very Solid

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

I am very pleased with these subs. I have 2 of these in my 03' f150 supercrew and these fit under my backseat perfectly without any real modifications. my amp is a Alpine MRP-f300
SOUND: these subs really do sound great. They have what i would call "grown man bass." Your probably not going to shake your neigbors cars mirrors but they provide a very solid thump without being flooded or sloppy. I have always had 2 12's in all my previous cars and while these don't hit as hard as those did on the very deep lows they still hit amd I would say it is rather close and these sound better.
SIDE NOTE: As always it depends on what amp and whatnot you have running your speakers but with these i can set loose change on my console and watch it move with the bass where i have never really been able to do that before even with my 12's
CONCLUSION: if you are a teen and just what the most flooded. ratteling bass you can find these might not be for you. but if you want a very clean sound that will still shake your seat and fit conveniently in a tight space i would highly reccomend. .
*Only giving 4 stars for look/design and durability as i never see speakers and have only had them for 6 months so can't fully speak to durability.

By RickyBobby on March 27, 2012

80 found this helpful


8" W3?

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

These really do not sound like 8's. They slap hard and people are always amazed when they hear them. I have 2 8 W3 in a sealed box in a nissan frontier crew cab and they hit so hard. I had someone come into my car not knowing i had subs and asked them what they sounded like and he said he thought it was a 12 in a large box. No one believes they are only 8's until they see them. I definitely recommend this to anyone limited in space and wanting the most boom for their buck

By 8w3 owner on November 18, 2010

78 found this helpful


Hammers

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

I put a single 8W3 in a fiberglass enclosure in the back of my SUV on 240 watts. It really gets down! Best in a sealed enclosure.

By Adrian on September 10, 2012

76 found this helpful


sound supreme ++

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

i have a lexus sc 400 these speakers with components and all fit flawlessly and offer a sound that is truly extraordinary, i was advised to buy this brand with guaranteed satisfaction, and i openly admit that is what i have. Complete satisfaction and super pounding power, highly recommended, state of the art is JL Audio, and i got a 8 inch sub instead of 10 i was very worried it would not provide the bass i wanted wow it vibrates the mirrors and seats and thumps!! more than expected and surpassed 2 friends 10 and 12s they had

By Phillip on June 14, 2010

76 found this helpful


Great

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

I got 3 and they sound real good. They are a must buy.

By Marcus on July 19, 2012

68 found this helpful


Super 8

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

2008 Wrangler Unlimited. Made spacer so that the 8w3v fits in OEM enclosure. Being fed by Cadence XAH250.2 mono. If you are reading the reviews, you know the praise for this little thing. No BS, this little thing is awesome for an 8. In previous vehicles, I've had a single 10 and a single 12. Both Polk db's. The JL is as loud as the 10 and musically it sounds better than both the 10 and 12. Both db's sounded "messy". This one is very precise. Definitely worth they extra money and for this particular application, it is perfect.

By John on February 9, 2012

66 found this helpful


Great deal

The following review is for 8W3V3-4, which is a part of the bundle you are viewing.

i would recommend these speakers to anyone who is tight on space but still wants the good sound and or bass. They are a little pricey but i would buy them again in a heart beat

By Jake on January 3, 2010

68 found this helpful
