See all parts that fit your 1983 Regal

JBL GTO1514D OPEN BOX COMPLETE

350W 15" GTO Series Dual 4 ohm Subwoofer

JBL
Shop all JBL
Product videos
highlight-star-icon

Item has been Installed, opened, and used
• 1400W Peak
• 350W RMS
• Polypropylene cone woofer
• Rubber surround
• Tinsel wire protector
• Die-cast aluminum basket
• 2" Dual 4 ohm voice coil

Learn more about the LS-gto1514d-OBCra223161

We apologize

This item has been discontinued

Product Highlights


Item has been Installed, opened, and used
• 1400W Peak
• 350W RMS
• Polypropylene cone woofer
• Rubber surround
• Tinsel wire protector
• Die-cast aluminum basket
• 2" Dual 4 ohm voice coil

Description


JBL brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Grand Touring Series

Ever wonder what a high quality subwoofer sounds like? Now you not only hear one, but own one too. These affordable subwoofers are built with die-cast aluminum frames to ensure durability of the product. The Butyl Rubber surround provides a tone of bass that sounds superior to most others. The Polypropylene woofer cone provides the loudest and highest quality punch on every note. When properly powered, these hungry speakers will extend deep into the audible frequencies for an even presence of your low end bass. Get yours now and you will not regret it!



The Sound of quality

Sonic Electronix, one of the leaders in car audio, recently visited Harman, the premium global audio and infotainment group, at their research and development locations in Northridge, California and Detroit, Michigan. The purpose of these visits was to utilize and combine the powerful brand of Harman and the industry leading knowledge behind Sonic Electronix to begin working together on developing future car audio projects.


Item Condition: Open Box Complete

  • Item has been Installed, opened, and used.
    • General Features:

      • 15" Dual 4 ohm Grand Touring Die-Cast Series Subwoofer
      • Power Handling:
        • Peak: 1400 watts
        • RMS: 350 watts
      • Impedance: Dual 4 ohm
      • Polypropylene cone woofer
      • Rubber surround
      • Tinsel wire protector
      • Die-cast aluminum basket
      • 2" Dual 4 ohm voice coil
      • Frequency response: 23-400 Hz
      • Sensitivity: 96 dB
      • Authorized Internet Dealer
      • 1-year Manufacturer's warranty

    Product history:

    JBL LS-GTO1514D-OBC thumbnail
    (newest, current model)
    JBL GTO1504D thumbnail
    (previous model, replaced by JBL GTO1514D OPEN BOX COMPLETE)

    Subwoofer Wiring Guide


    Wiring Guide to Wire 1 JBL GTO1514D OPEN BOX COMPLETE Subwoofer

    Mono Amp

    2 Channel Amp - Bridged

    Wiring Guide to Wire 2 JBL GTO1514D OPEN BOX COMPLETE Subwoofers

    Mono Amp

    Mono Amp - Option 1

    2 Channel Amp

    2 Channel Amp - Bridged

    4 Channel Amp - Bridged

    Wiring Guide to Wire 3 JBL GTO1514D OPEN BOX COMPLETE Subwoofers

    Mono Amp

    4 Channel Amp

    Wiring Guide to Wire 4 JBL GTO1514D OPEN BOX COMPLETE Subwoofers

    Mono Amp

    2 Channel Amp

    2 Channel Amp - Bridged

    4 Channel Amp

    Specifications & Details


    Subwoofer Specifications
    Series
    GTO Series
    Subwoofer Size
    15"
    Peak Power Handling
    1400 watts
    RMS Power Handling
    350 watts
    Voice Coil(s)
    Dual
    Impedance (Per Voice Coil)
    4 ohm
    Voice Coil Diameter
    2"
    Frequency Response
    23 - 400 Hz
    Sensitivity
    96 dB
    Xmax (millimeters)
    15 mm
    Subwoofer Design
    Round / Circle
    Main Cone Color
    Black
    Silver
    Woofer Composition
    Polypropylene
    Woofer Surround
    Rubber
    Subwoofer Grille
    No
    Re-Cone Kit Available
    No
    Recommended Enclosure Specifications
    Recommended Enclosure Type
    Ported / Vented
    Sealed
    Minimum Sealed Box Volume
    1.5 cubic feet
    Maximum Sealed Box Volume
    1.5 cubic feet
    Minimum Ported Box Volume
    3.5 cubic feet
    Maximum Ported Box Volume
    3.5 cubic feet
    Top-Mount Depth (Mounting Depth)
    6-13/16"
    Cutout Diameter
    13-15/16"
    Shallow Mount Installation
    No
    T/S Parameters (Electromechanical)
    Free-Air Resonance (Fs)
    24.90 Hz
    Equivalent Compliance (Vas)
    161.40 liters
    Total Speaker Q Value (Qts)
    0.47
    Electrical Q Value (Qes)
    0.51
    Electrical Resistance of Voice Coil (Re)
    1.90 ohm
    Mechanical Q Value (Qms)
    7.15
    Warranty and Return Policy
    Parts Warranty Duration
    1 year
    Labor Warranty Duration
    1 year
    Warranty Provider
    Manufacturer

    Item Details


    Manufacturer:

    JBL

    Model Number:

    LS-GTO1514D-OBC

    Weight:

    27.00lbs

    Internal SKU:

    LS-gto1514d-OBCra223161

    Internal Product ID:

    98083
