See all parts that fit your 2003 Thunderbird

Sony XS-R1346

230W Max (70W RMS) 5-1/4" XSR Series 4-Way Coaxial Car Speakers

Sony
Shop all Sony
highlight-star-icon

• 230W Max Each, 35W RMS Each
• 1" Balanced Dome Piezo Midrange with Two 7/32" Piezo Tweeters
• MIca Filled Polypropylene Cone
• 4 ohm Impedance
• Sensitivity: 87dB
• Mounting Depth: 1-13/16"

Learn more about the xsr1346

We apologize

This item has been discontinued


Loading...
70-1771 main

Metra 70-1771

Install a New Car Stereo in select 1998-2011 vehicles from Ford, Mazda, Mercury

51
95-5000B main

Metra 95-5000B Dash Kit

Install a new Double-DIN car stereo in select 2000-2006 LS and Thunderbird (Black)

1
-40.76%

$15.99

List price $26.99

Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

123
-33.36%

$79.96

List price $119.99

Limited time!
DMH-241EX main

Pioneer DMH-241EX

6.2" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth and Built-in Alexa

20
-35.00%

$194.99

List price $300.00

INE-W970HD main

Alpine INE-W970HD

6.5" Double DIN Touchscreen DVD Receiver with Bluetooth, Apple CarPlay, Android Auto and Built-in Navigation (SiriusXM Ready)

6
-16.67%

$999.95

List price $1200.00

DDX57S main

Kenwood DDX57S

6.75" Double DIN Touchscreen CD/DVD Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

5
-31.21%

$399.00

List price $580.00

TS-T110 main

Pioneer TS-T110

240W Peak (80W RMS) 7/8-Inch Hard-Dome Tweeters (Pair)

43
-9.09%

$50.00

List price $55.00

Description


Sony brand icon

Authorized dealer

General Features:

  • 5.25" XSR Series Car Speakers/Component System
  • Power Handling:
    • Peak: 460 watts per pair / 230 watts each
    • RMS: 70 watts per pair / 35 watts each
  • Mica filled polypropylene matrix cone
  • Rubber coated cloth surround
  • 1" balanced dome piezo mid-range
  • Two 7/32" PEI piezo tweeters
  • CTA-2031 compliant speakers
  • Ferrite magnet motor structure
  • Top-mount Depth: 1-13/16"
  • Cutout Dimensions: 5-1/8"
  • 4 ohm impedance
  • Frequency Response: 60 - 24000 Hz
  • Sensitivity: 87dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • Priced Per Pair


Loading...
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

3
-19.05%

$339.99

List price $420.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

JVC KW-M560BT

6.8" Double-DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

10
Limited time!
DMX709S main

Kenwood eXcelon DMX709S

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

20
-33.50%

$399.00

List price $600.00

Limited time!
iLX-W670-M main

Alpine iLX-W670-M

6.75" Double DIN Touchscreen Digital Multimedia Receiver with iDataLink Maestro Support, Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

2
-30.01%

$349.95

List price $500.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00


Best selling similar products

Club 522F small

JBL Club 522F (SPKCB522FAM)

• 135 watts Peak Each, 45 watts RMS Each
• Silk Edge Driven Dome tweeters
• UV-Resistant Polypropylene cone material
• Plus One woofer architecture
• Impedance: 3 ohm
• Sensitivity: 91 dB

$74.99

List price $129.95

43DSC504 small

Kicker DSC50 (43DSC504)

• 200 watts Peak Each, 50 watts RMS Each
• 1/2" PEI (Polyetherimide) Balanced Dome tweeters
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 90 dB

(17)

$74.99

List price $84.99

46CSC54 small

Kicker CSC5 (46CSC54)

• 225 watts Peak Each, 75 watts RMS Each
• 1/2" PEI (Polyetherimide) Balanced Dome tweeters with neodymium magnets
• Polypropylene cone material
• Impedance: 4 ohm
• Sensitivity: 90 dB

(5)

$79.96

List price $119.99

Specifications & Details


Speaker Specifications
Priced Per
Pair
Number of Speakers
2
Speaker Size
5-1/4"
Design
4-way Coaxial
Tweeter Design
Balanced Dome
Tweeter Size
1"
Tweeter Composition
PEI (Polyetherimide)
Woofer Composition
Mica Injected Polypropylene - MIPP
Woofer Surround
Treated Cloth
Peak Power Handling
230 watts
RMS Power Handling
35 watts
Sensitivity
87 dB
Frequency Response
60 - 24000 Hz
Impedance (Per Voice Coil)
4 ohm
Shallow Mount Installation
No
Top-Mount Depth (Mounting Depth)
1-13/16"
Cutout Dimensions
5-1/8"
General specifications
Marine Certified
No
Hi-Res Certified
No
Color
Black
Speaker Grilles
Yes
What is in the box?
Paperwork
User manual
Warranty/Registration card
WITB: Speakers
Speakers (2)
Grilles (2, attached)
Mounting screws (8)
Mounting clips (8)
Speaker connection cables (2)
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

XS-R1346

Weight:

3.20lbs

Internal SKU:

xsr1346

Internal Product ID:

138703
