Phoenix Gold SX18S4 SX1 8 INCH SINGLE 4 OHM SUBWOOFER

Phoenix Gold SX18S4

SX1 8 INCH SINGLE 4 OHM SUBWOOFER

SX1 8 INCH SINGLE 4 OHM SUBWOOFER

• SX Series 8" Single 4 Ohm Subwoofer
• 200W RMS power
• 35mm excursion
• Butyl rubber surround
• 2.0 inch copper voice coils
• Optimized for sealed or vented enclosures

We apologize

This item has been discontinued

DESCRIPTION
Phoenix Gold

Authorized dealer

General Features:

  • SX Series 8" Single 4 Ohm Subwoofer
  • RMS Power Handling: 200W
  • 35mm of Peak to Peak Excursion
  • High Excursion CAE/CAD Motor Design
  • Vented Aluminum Former
  • Long Throw Spider Suspension
  • One Piece Polypropylene Plated Dustcap
  • High Roll Butyl Rubber Surround
  • 2.0 Inch High Temperature OFC Copper Voice Coils
  • Nickel Plated 12 Gauge Speaker Terminal
  • Optimized for Sealed or Vented Enclosures
  • Powder Coated Anti-Resonant Steel Basket
  • Impedance: Dual 2-Ohms
  • Mounting Depth: 4.375in - 110mm
  • Mounting Diameter: 7.25in - 185mm
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

View the SX Series Subwoofer Manual for detailed specs, wiring diagrams, enclosure recommendations, and more!


FEATURES & SPECS
Subwoofer Specifications
Subwoofer Series
SX Series
Subwoofer Size
8"
Peak Power Handling
400 watts
RMS Power Handling
200 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohms
Voice Coil Diameter
2"
Sensitivity
89 dB
Xmax (millimeters)
35 mm
Subwoofer Design
Round / Circle
Main Cone Color
Dark Gray
Woofer Composition
Polypropylene w/ Metallic Finish
Woofer Surround
Butyl Rubber
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Top-Mount Depth
4.375"
Cutout Diameter
7.25"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
40.2 Hz
Equivalent Compliance (Vas)
9.22 liters
Total Speaker Q Value (Qts)
.66
Electrical Q Value (Qes)
.714
Electrical Resistance of Voice Coil (Re)
3.8 ohms
Mechanical Q Value (Qms)
7.96
What is in the box?
WITB: Subwoofers
Subwoofer
Authorized Dealer
Authorized Dealer
Authorized Dealer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer
REVIEWS
Phoenix Gold SX18S4

Phoenix Gold SX18S4


Write a review

Overall rating distribution

5 star
0%
4 star
0%
3 star
0%
2 star
0%
1 star
0%

By feature average rating

Durability
0
Value
0
Features
0
Design
0
Usability
0
ACCESSORIES
WIRING GUIDE
Wiring Guide to Wire 1 Phoenix Gold SX18S4 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Phoenix Gold SX18S4 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Phoenix Gold SX18S4 Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 Phoenix Gold SX18S4 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp
