See all parts that fit your 2013 Corolla

Pioneer TS-W258D4 Open Box

(Ope Box) 10" Dual 4 ohm Champion Series Subwoofer w/ Double Stacked Magnet

Pioneer
Shop all Pioneer
Product videos
highlight-star-icon

10" Champion Series Subwoofer • 1200 Watts Max • 350 Watts RMS • Dual 4 Ohm • Interlaced Basalt/Carbon Fiber Reinforced IMPP Cone • Three-Layer Fiber Woven Surround • High-Power (74oz) Magnet • Conex Spider

Learn more about the LS-tsw258d4-OB

We apologize

This item has been discontinued

Product Highlights


10" Champion Series Subwoofer • 1200 Watts Max • 350 Watts RMS • Dual 4 Ohm • Interlaced Basalt/Carbon Fiber Reinforced IMPP Cone • Three-Layer Fiber Woven Surround • High-Power (74oz) Magnet • Conex Spider

Description


Pioneer brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

  • 10" Dual 4 ohm Champion Series Subwoofer
  • Power Handling:
    • Peak: 1200 watts
    • RMS: 350 watts
  • Impedance: Dual 4 ohm
  • Interlaced basalt/carbon fiber reinforced IMPP cone
  • Cone reinforcement arcs
  • Wide roll, three-layer fiber woven radial surround
  • Standard top plate
  • Stamped basket with magnet cover
  • 4-Layer long voice coil
  • Double mass high-power (74oz) magnet
  • Frequency response: 20-450 Hz
  • Mounting depth: 5-5/8"
  • Integrated single-sided silver compression wire terminals
  • Conex damper (spider)
  • Molded gasket
  • Phenol resin coated glass cloth voice coil bobbin
  • Copper voice coil wire
  • 1-year SonicElectronix.com warranty

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Pioneer TS-W258D4 Open Box Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Pioneer TS-W258D4 Open Box Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Pioneer TS-W258D4 Open Box Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Pioneer TS-W258D4 Open Box Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Champion Series
Subwoofer Size
10"
Peak Power Handling
1200 watts
RMS Power Handling
350 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Frequency Response
20 - 450 Hz
Sensitivity
90 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Carbon Fiber
Woofer Surround
Fiber Woven Radial
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Sealed
Minimum Sealed Box Volume
0.65 cubic feet
Maximum Sealed Box Volume
1.25 cubic feet
Top-Mount Depth (Mounting Depth)
5-5/8"
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

TS-W258D4-OB

Weight:

15.00lbs

Internal SKU:

LS-tsw258d4-OB

Internal Product ID:

38825

Product and How-to Videos


Customer Ratings & Reviews


Pioneer TS-W258D4 Open Box thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
5
Usability
4

Customer Reviews

Sort by:

Loading...

get it while they're left!

i bought this just to compliment the other 4 subs in my blazer and to use up my extra amp, and DAMN.

i have it hooked up backwards to a sony 1000 in a MTX roadthunder bandpass box (kind of a tight fit with the plastic around the ourside), and it definally moves some air. I had to plug one of the ports on the box but thats MTXs' tuning's fault, it wouldnt hit the lows worth crap. but its nice and heavy, the surround is huge and durable, easy to hook up, and being an open box, in really good shape, not a mark on it! i would suggest this to anyone and everyone wanting cheap, competition quality sound.

By Dilli on August 31, 2011
