American International DWH-610

Wire Harness to Connect an Aftermarket Stereo Receiver to Select 1984-1994 Dodge and Mitsubishi Vehicles

highlight-star-icon

In-dash car radio harness that plugs into the factory OEM radio plug for select 1984-1994 Chrysler and Mitsubishi Vehicles, keeping it in tact (instead of cutting it off), and converting colors to the aftermarket standard

Learn more about the dwh610

We apologize

This item has been discontinued


Loading...
480BRGB main

Boss Elite 480BRGB

Double DIN Digital Media Receiver with Bluetooth

17

Description


American International brand icon

Authorized dealer

When replacing your factory radio with an after-market car stereo, the DWH-610 wire harness is a must for a quick and clean installation. It eliminates cutting your OE radio plug. After connecting it, your install is simple as the wires will color-match and easily connect to the after-market stereo. Without the DWH-610, you would have to cut the OE radio plug and manually test each wire to connect to your after-market receiver.

In addition, because you do not have to cut your OE radio plug off, the DWH-610 allows you to reinstall your factory receiver if necessary. A great example is if you sold your car, but wanted to keep your after-market radio and re-install your factory stereo receiver. We also recommend the Scosche BOBAZT for a quick connection that is sure to last.

Product Features:
  • Harness is used when installing an aftermarket stereo
  • Connects the aftermarket stereo harness to the vehicles factory harness
  • Designed specifically to fit the compatible vehicles
  • Plugs into the factory harness without cutting any wires
  • Standard color coded wires provide a consistent and simplified installation
  • Made from OEM quality materials
  • Compatible with Select 1984-1994 Chrysler and Mitsubishi Vehicles
  • Metra equivalent: Metra 70-1743 or Scosche equivalent: Scosche MC01B
Connections:
  • Yellow – 12V Constant
  • Red – 12V Accessory
  • Black - Ground
  • Orange – Dash Light Dimmer/Illumination
  • Green – Left Rear Speaker (+)
  • Green with Black Stripe Left Rear Speaker (-)
  • White – Left Front Speaker (+)
  • White with Black Stripe – Left Front Speaker (-)
  • Purple – Right Rear Speaker (+)
  • Purple with Black Stripe – Right Rear Speaker (-)
  • Gray – Right Front Speaker (+)
  • Gray with Black Stripe – Right Front Speaker (-)
Compatible with the following vehicles:
  • Dodge:
    • 1987 - 1994 Colt
    • 1987 - 1994 Ram Pickup
    • 1987 - 1989 Raider
    • 1990 - 1994 Stealth
  • Mitsubishi:
    • 1987 - 1994 Galant
    • 1987 - 1994 Mighty Max Pickup
    • 1987 - 1989 Mirage
    • 1990 - 1994 Montero
    • 1991 - 1994 Eclipse
    • 1991 - 1994 3000GT
