Alpine R2-W10D2 (Open Box, Good)

2250W Peak (750W RMS) 10" R2-Series Dual 2-ohm Car Subwoofer

Alpine
Shop all Alpine
highlight-star-icon

• Peak Power: 2250 watts
• RMS Power: 750 watts
• Impedance: Dual 2 ohm
• Kevlar Reinforced Pulp Paper Cone
• High-Amplitude Multi-Roll (HAMR) Surround
• Mount depth: 5.92"
• Sensitivity: 82.3 dB

Learn more about the ls-r2w10d2-u7

We apologize

This item has been discontinued

Description


Alpine brand icon

Authorized dealer

Item Condition - Open Box, Good:

This product is used, but it will work like new and is in overall good condition. It will show signs of wear that can include scuffing, scratches, fingerprints, dents, and worn corners or installation marks. May be missing non-essential parts, accessories or original packaging.


R2-W10D2

Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output. The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.


Product Details:

  • 10" Dual 2 ohm R2 Series Subwoofer
  • Power Handling:
    • Peak: 2250 watts
    • RMS: 750 watts
  • Kevlar Reinforced Pulp Paper Cone
  • High-Amplitude Multi-Roll (HAMR) Surround
  • 2.6" High Temperature Voice coil
  • 20 mm Xmax
  • 123 oz. Double Stacked Ferrite magnet motor structure
  • Frequency Response: 26 - 200 Hz
  • Resonance Frequency (Fs): 31 Hz
  • Sensitivity: 82.3 dB
  • Recommended sealed box volume: .4 cubic feet - .85 cubic feet
  • Recommended ported box volume: .75 cubic feet - 1.3 cubic feet
  • Top-mount depth: 5.92"
  • Cutout diameter: 9.06"
  • Authorized Internet Dealer
  • Subwoofer grille Alpine KTE-10G optional (sold separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

PDF IconAlpine R2W10D2 owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Alpine R2-W10D2 (Open Box, Good) Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Alpine R2-W10D2 (Open Box, Good) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Alpine R2-W10D2 (Open Box, Good) Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 Alpine R2-W10D2 (Open Box, Good) Subwoofers

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
R2 Series
Subwoofer Size
10"
Peak Power Handling
2250 watts
RMS Power Handling
750 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohm
Voice Coil Diameter
2.6"
Frequency Response
26 - 200 Hz
Sensitivity
82.3 dB
Xmax (millimeters)
20 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Kevlar Reinforced Pulp Paper
Woofer Surround
High-Amplitude Multi-Roll (HAMR)
Magnet Structure
Double Stacked
Magnet weight
123 oz.
Magnet Type
Ferrite
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
.4 cubic feet
Maximum Sealed Box Volume
.85 cubic feet
Minimum Ported Box Volume
.75 cubic feet
Maximum Ported Box Volume
1.3 cubic feet
Top-Mount Depth (Mounting Depth)
5.92"
Cutout Diameter
9.06"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
31 Hz
Equivalent Compliance (Vas)
18.2 liters
Total Speaker Q Value (Qts)
0.47
Electrical Q Value (Qes)
.50
Electrical Resistance of Voice Coil (Re)
1.8 ohm
Mechanical Q Value (Qms)
7.07
What is in the box?
Paperwork
User manual
Warranty/Registration card
WITB: Subwoofers
Subwoofer
Mounting screw cover (detached)
Other Accessory #1
10" R2-Series DVC Subwoofer with Cosmetic Trim Ring
Other Accessory #2
2 Jumper Wires for DVC Configuration
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

R2-W10D2-3

Weight:

25.00lbs

Internal SKU:

ls-r2w10d2-u7

Internal Product ID:

227501
