DS18 ZR12.4D (Open Box, Good)

1500W Peaks (750W RMS) 12" ZR Series Dual 4-Ohm Car Subwoofer

DS18
Shop all DS18
highlight-star-icon

• Peak Power: 1500 watts
• RMS Power: 750 watts
• Impedance: Dual 2 ohm
• Non-Pressed Paper cone
• Foam surround
• Mount depth: 6.58"
• Sensitivity: 82 dB

Learn more about the ls-zr124d-u7

We apologize

This item has been discontinued

Description


DS18 brand icon

Authorized dealer

Item Condition - Open Box, Good:

This product is used, but it will work like new and is in overall good condition. It will show signs of wear that can include scuffing, scratches, fingerprints, dents, and worn corners or installation marks. May be missing non-essential parts, accessories or original packaging.


DS18 ZR12.4D

Introducing the DS18 ZR12.4D, a true powerhouse designed to deliver mind-blowing bass and precision performance. The ZR subline is renowned for its exceptional performance, and the ZR12.4D is no exception. With a robust 1500W of MAX power handling and 750W of RMS power handling, the ZR12.4D guarantees a spine-tingling audio experience that will leave you craving for more. Its 2.5-inch high-strength aluminum voice coil ensures that every note is delivered with precision and clarity, elevating your car audio system to new heights. Its 4+4-ohm dual voice coil configuration allows you to match your amplifier's optimal impedance, providing maximum power transfer and efficiency.


Product Details:

  • 12" Dual 2 ohm ZR Series Subwoofer
  • Power Handling:
    • Peak: 1500 watts
    • RMS: 750 watts
  • Non-Pressed Paper cone
  • Foam surround
  • Matte black steel basket material
  • 2.5" Copper voice coil
  • 25 mm Xmax
  • 100 oz. Single Stacked Ferrite magnet motor structure
  • Frequency Response: 25 - 200 Hz
  • Resonance Frequency (Fs): 28 Hz
  • Sensitivity: 82 dB
  • Recommended sealed box volume: 1.5 cubic feet
  • Recommended ported box volume: 2.4 cubic feet
  • Top-mount depth: 6.58"
  • Cutout diameter: 11"
  • Authorized Internet Dealer
  • Includes protective subwoofer grille
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 DS18 ZR12.4D (Open Box, Good) Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 DS18 ZR12.4D (Open Box, Good) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 DS18 ZR12.4D (Open Box, Good) Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 DS18 ZR12.4D (Open Box, Good) Subwoofers

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
ZR Series
Subwoofer Size
12"
Peak Power Handling
1500 watts
RMS Power Handling
750 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohm
Voice Coil Material
Copper
Voice Coil Diameter
2.5"
Frequency Response
25 - 200 Hz
Sensitivity
82 dB
Xmax (millimeters)
25 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Non-Pressed Paper
Woofer Surround
Foam
Magnet Structure
Single Stacked
Magnet weight
100 oz.
Magnet Type
Ferrite
Subwoofer Grille
No
Re-Cone Kit Available
No
CTA-2031 Compliant
Yes
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
1.5 cubic feet
Optimum Ported Box Volume
2.4 cubic feet
Top-Mount Depth (Mounting Depth)
6.58"
Cutout Diameter
11"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
28 Hz
Equivalent Compliance (Vas)
22.7 liters
Total Speaker Q Value (Qts)
0.79
Electrical Q Value (Qes)
0.94
Electrical Resistance of Voice Coil (Re)
3.4 ohm
Mechanical Q Value (Qms)
5.08
Efficiency Bandwidth Product (EBP)
29.8
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

ZR12.4D-2

Weight:

18.50lbs

Internal SKU:

ls-zr124d-u7

Internal Product ID:

207191
