Infinity REF697CF (INFSPKRF697CFUS) (Like New (Open Box))

750W Peak (250W RMS) 6x9" Reference Series 2-Way 3-ohm Component Speaker System

Infinity
Shop all Infinity
highlight-star-icon

• 375 watts Peak Each, 125 watts RMS Each
• 3/4" Textile Edge Driven Dome tweeters
• Polypropylene cone material
• Impedance: 3 ohm
• Sensitivity: 93 dB

Learn more about the ls-ref697cf-u9

We apologize

This item has been discontinued

Description


Infinity brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


Infinity REF697CF (INFSPKRF697CFUS)

New Reference speakers are designed to deliver Infinity’s signature sound in more vehicles. They feature edge-driven textile tweeters for smooth, clear highs and the larger models offer an adjustable tweeter output level control for high-frequency optimization based on installation location or the listener's preference. Oversized Plus One woofers offer more surface area for higher bass output and enhanced midrange performance. Plus, their newly engineered baskets are optimized to fit most factory speaker locations. Available in a range of standard sizes, they’re the perfect upgrade from factory speakers.


Product Details:

  • 6" x 9" 2-way Component System Car Speakers
  • Power Handling:
    • Peak: 750 watts per set / 375 watts each side
    • RMS: 250 watts per set / 125 watts each side
  • Polypropylene cone material
  • Rubber speaker surround
  • 3/4" Textile Edge Driven Dome Tweeters
  • +3dB tweeter boost switch function
  • 3-ohm impedance combines with speaker wire for 4-ohm load
  • Features Plus One woofer cone architecture
  • Increased low-frequency output and accurate sound production
  • Optimized frame size featuring compact design
  • Adjustable tweeter output level control to suit installation location
  • Top-mount Depth: 3-1/8"
  • Cutout Dimensions: 8-1/2 x 5-3/4
  • Impedance: 3 ohm
  • Frequency Response: 46 - 21000 Hz
  • Sensitivity: 93 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

  • Priced Per Complete Component System: 2 midwoofers, 2 tweeters and 2 crossover networks.

Specifications & Details


Speaker Specifications
Series
Reference Series
Priced Per
Pair
Number of Speakers
2 Speakers + 2 Tweeters
Speaker Size
6" x 9"
Design
2-way Component System
Tweeter Design
Edge Driven Dome
Tweeter Size
3/4"
Tweeter Composition
Textile
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Peak Power Handling
375 watts
RMS Power Handling
125 watts
Total PEAK Per Pair/Set
750 watts
Total RMS Per Pair/Set
250 watts
Sensitivity
93 dB
Frequency Response
46 - 21000 Hz
Impedance (Per Voice Coil)
3 ohm
Shallow Mount Installation
No
Top-Mount Depth (Mounting Depth)
3-1/8"
Cutout Dimensions
8-1/2 x 5-3/4
CTA-2031 Compliant
No
General specifications
Marine Certified
No
Hi-Res Certified
No
Color
Black
Illumination
None
Speaker Grilles
No
Includes Damping Kit
without Damping Kit
Compatible vehicle types
Car/Truck/SUV/Van
What is in the box?
Paperwork
User manual
WITB: Speakers
Foam Gasket
Speakers (2)
Washers
Grilles (2, attached)
Tweeters (2)
Tweeter angle mounts (2)
Tweeter flush mounts (2)
Tweeter surface mounts (2)
Mounting screws (4)
Mounting screws (8)
Mounting clips (8)
Speaker connection cables (2)
Adhesive brand badges
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

REF697CF

Weight:

6.85lbs

Internal SKU:

ls-ref697cf-u9

Internal Product ID:

225831
