See all parts that fit your 1966 2000cs

JBL GT5-10D (Open Box, Complete)

275W 10" GT Series Dual 4 ohm Subwoofer

JBL
Shop all JBL
highlight-star-icon

• 1000W Peak
• 275W RMS
• Dual 4 Ohm
• Polypropylene Woofer
• Hi-Roll Rubber Surround
• Progressive Spider
• Fully Vented Motor Structure
• Rubber-Coated Tinsel Leads

Learn more about the ls-gt510d-obc7

We apologize

This item has been discontinued

Description


JBL brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Like New:
A Open Box, Like New product is an apparently untouched product in perfect condition that includes all accessories and packaging. Original protective wrapping may be missing, but the original packaging is intact and pristine. There are absolutely no signs of wear on the item or installation. Instructions are included. Warranty details are included in the item description or comments. Item is suitable for presenting as a gift and savings should be abundant!

Big Bass

For anyone who likes to crank it up in the car, the JBL® high-output GT5-10D subwoofer is the real deal. The JBL GT5-10D subwoofer features dual 4-ohm voice coils and a vented motor structure, and offers 1100 watts of peak power handling. The GT5-10D also features JBL’s newest design, combining classic elements with modern ones.

All-New Design

The GT5-10D follows the design of the more-expensive JBL subwoofers, combining classic elements with modern ones.


Significant Power Handling Capabilities

The GT5-10D handles 275W/1100W (RMS/Peak) power and offers nearly 20 percent higher Xmax than many competitors.


Increased Reliability

With its fully vented motor structure and rubber-coated tinsel leads, the GT5-10D is able to withstand even the most intense bass assault.


Dual-Stacked, Oversized Magnets

Unlike competing entry-level subwoofers, the GT5-10D is based on a solid motor structure featuring two large magnets covered by the classic JBL rubber ring.




The Sound of quality

Sonic Electronix, one of the leaders in car audio, recently visited Harman, the premium global audio and infotainment group, at their research and development locations in Northridge, California and Detroit, Michigan. The purpose of these visits was to utilize and combine the powerful brand of Harman and the industry leading knowledge behind Sonic Electronix to begin working together on developing future car audio projects.


General Features:

  • 10" Dual 4 Ohm GT5 Series Subwoofer
  • Power Handling:
    • Peak: 1000 watts
    • RMS: 275 watts
  • Recommended power range: 150 - 275 watts RMS
  • Impedance: 4 Ohm
  • Polypropylene woofer cone material
  • Hi-roll rubber surround
  • Progressive spider
  • Fully vented motor structure for smoother response
  • Rubber-coated tinsel leads help to protect the leads against wear and harsh use
  • Double stacked magnets covered in a classic black rubber ring
  • Frequency response: 30 - 500 Hz
  • Sensitivity: 91 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty
Tips for Installing the your subwoofer


Subwoofer Wiring Guide


Wiring Guide to Wire 1 JBL GT5-10D (Open Box, Complete) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JBL GT5-10D (Open Box, Complete) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JBL GT5-10D (Open Box, Complete) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 JBL GT5-10D (Open Box, Complete) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
GT5 Series
Subwoofer Size
10"
Peak Power Handling
1000 watts
RMS Power Handling
275 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Frequency Response
30 - 500 Hz
Sensitivity
91 dB
Xmax (millimeters)
14.2 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Silver
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Bandpass
Ported / Vented
Sealed
Minimum Sealed Box Volume
.75 cubic feet
Maximum Sealed Box Volume
.75 cubic feet
Minimum Ported Box Volume
1.25 cubic feet
Maximum Ported Box Volume
1.25 cubic feet
Top-Mount Depth (Mounting Depth)
5-15/16"
Cutout Diameter
9-3/16"
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
30 days
Labor Warranty Duration
30 days
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

JBL

Model Number:

GT5-10D-3

Weight:

13.00lbs

Internal SKU:

ls-gt510d-obc7

Internal Product ID:

182065
