Product highlights

Portable 2-Channel USB Audio Interface • 24-bit, 48 kHz Operation • High-End A/D and D/A Converters • 2 XLR Mic Inputs • 48V Phantom Power • Illuminated Status Indicators • USB Powered • Includes Steinberg Cubase LE Software

Learn more about the io2

NVX - Worth the Envy - Direct to Consumer Car Audio

Description

Authorized dealer

Product Features:

Portable 2-Channel USB Audio Interface
24-bit, 48 kHz operation with high-end A/D and D/A conversion through integrated USB audio interface
2 XLR mic inputs with 48V phantom power plus 2 1/4" balanced line inputs that can accept guitar level signals
Dedicated four segment signal/clip LED meter on both channels
Ultra low-latency ASIO 2.0 drivers (with zero-latency hardware monitoring)
Monitor sessions with balanced studio monitor and headphone outputs
Tricolor stereo level meter and illuminated status indicators for visual monitoring
USB powered (no external AC power supply necessary)
Low power usage for minimal laptop battery drain
Includes Steinberg Cubase LE software
Works with drivers which are built into Mac OS X, Windows 7 (32-bit and 64-bit), Vista (32-bit and 64-bit), and Windows XP
Authorized Internet Dealer
1-year Manufacturer's warranty

Product Specifications:

Frequency Response:
- MIC/LINE IN to SPDIF/USB OUT: +/-0.1dB Input Gain = minimum
- MIC/LINE IN to MAIN OUT (through ADC/DAC) +/-0.35dB Input Gain=minimum
Signal to Noise Ratio:
- MIC/LINE IN (balanced) to INSERT OUT: 110dB A-weighted, input impedance at XLR or 1/4" jack = 600 Ohm, Input Gain = minimum
- GUITAR IN (unbalanced) to INSERT OUT: 99dB A-weighted, input impedance at 1/4" jack = 600 Ohm, Input Gain = minimum
- MIC/LINE IN (balanced) to SPDIF/USB OUT: 99dB A-weighted, input impedance at MIC or LINE jack = 600 Ohm, Input Gain = minimum
- GUITAR IN (unbalanced) to SPDIF/USB OUT: 94dB A-weighted, input impedance at 1/4" jack = 600 Ohm, Input Gain = minimum
- MIC/LINE IN (balanced) to MAIN OUT (through ADC/DAC): 97dB A-weighted, input impedance at MIC or LINE jack = 600 Ohm, Input Gain = minimum
- MIC/LINE IN (balanced) to MAIN OUT (through direct monitor): 95dB A-weighted, input impedance at MIC or LINE jack = 600 Ohm, Input Gain = minimum
THD (Total Harmonic Distortion):
- MIC/LINE IN (balanced) to INSERT OUT: <0.001% Input Gain = minimum, 1KHz input signal, INSERT OUT = 5.7dBV
- GUITAR IN (unbalanced) to INSERT OUT: 0.034% Input Gain = minimum, 1KHz input signal, INSERT OUT = 5.3dBV
- MIC/LINE IN (balanced) to SPDIF/USB OUT: 0.003% Input Gain = minimum, 1KHz input signal, DIGITAL OUT = -0.3dBFS
- GUITAR IN (unbalanced) to SPDIF/USB OUT: 0.034% Input Gain = minimum, 1KHz input signal, DIGITAL OUT = -0.7dBFS
- MIC/LINE IN (balanced) to MAIN OUT (through ADC/DAC): 0.005% Input Gain = minimum, 1KHz input signal, MAIN OUT = 5.6dBV
- MIC/LINE IN (balanced) to MAIN OUT (through direct monitor): 0.006% Input Gain = minimum, 1KHz input signal, MAIN OUT = 5.6dBV
