AKG D5 (3138 Z 00070)

Super Cardioid Vocal Dynamic Microphone

AKG
Shop all AKG
Product videos
highlight-star-icon

• Extremely Rugged Vocal/Speech Microphone
• Patented AKG Laminated Varimotion Diaphragm
• Spring Steel Wire-Mesh Grill
• Recording
• Sound/AV Company
• Supercardiod
• Vocals

Learn more about the d5

We apologize

This item has been discontinued


Loading...
KMM-BT732HD main

Kenwood KMM-BT732HD

Single DIN Digital Media Bluetooth Receiver with HD Radio

3
-14.09%

$189.00

List price $220.00

MPR2110 main

Jensen MPR2110

Single DIN Digital Media Receiver with Bluetooth

13
H7653 main

Cerwin-Vega H7653

680W Peak (120W RMS) 6.5" HED Series 3-Way Coaxial 4-ohm Speakers

43
-16.67%

$79.99

List price $95.99

Lowest price in 30 days
H7694 main

Cerwin Vega H7694

800W Peak (150W RMS) 6x9" HED Series 4-Way Coaxial 4-ohm Speakers

32
-25.93%

$79.99

List price $107.99

C2-690tx main

JL Audio C2-690tx

140W RMS 6x9" C2 Series 3-Way Coaxial 4-ohm Car Speakers

21

Crunch CS653

600W Peak (120W RMS) 6.5" CS Series 3-Way Coaxial 4-ohm Car Speakers

21
-9.09%

$29.99

List price $32.99

Kenwood KFC-6996PS

1300W Peak (300W RMS) 6x9" Performance Series 5-way Dual 4-ohm Coaxial Car Speakers

2
-46.67%

$79.99

List price $150.00

Limited time!

Kenwood KFC-ST01

320W Peak (80W RMS) 1" KFC Series PEI Balanced Dome Car Tweeters

11
-37.89%

$59.00

List price $95.00

Product Highlights


• Extremely Rugged Vocal/Speech Microphone
• Patented AKG Laminated Varimotion Diaphragm
• Spring Steel Wire-Mesh Grill
• Recording
• Sound/AV Company
• Supercardiod
• Vocals

Description


Dynamic Era

The D 5 dynamic vocal microphone for lead and backing vocals delivers a powerful sound even on the noisiest stage. Its supercardioid polar pattern ensures maximum gain before feedback. The D 5 stands for a crisp sound that cuts through every mix.

AKG made the first microphone diaphragm ever whose thickness varies across its diameter. The new Laminated Varimotion diaphragm deep-drawing process allows the diaphragm itself to be fine-tuned with no extra tuning resonators, leading to a quantum leap in audio performance.

The dual shock mount eliminates any kind of mechanical noise for trouble-free live use. The audience will hear nothing but the pristine sound of your voice!

General Features:
  • Extremely rugged vocal/speech microphone
  • Available with or without on/off switch
  • Patented AKG Laminated Varimotion diaphragm
  • Spring steel wire-mesh grill
  • Great for:
    • Recording
    • Sound/AV company
    • Live applications
    • Vocals
  • Available versions:
    • D 5: for standard applications
    • D 5 S: with on/off switch
    • D 5 WL 1: D 5 microphone element with threaded connection for use with AKG wireless systems
  • 1-year Manufacturer's warranty
Specifications:
  • Polar pattern: supercardioid
  • Frequency range: 70 Hz to 20 kHz
  • Sensitivity: 2.6 mV/Pa (-52 dBV)
  • Max. SPL: 147/156 dB SPL (for 1% / 3% THD)
  • Equivalent noise level: 18 dB-A
  • Impedance: <= 600 ohm
  • Recommended load impedance: >= 2000 ohm
  • Connector: 3-pin XLR
  • Finish: matte grayish blue
  • Dimensions: length: 185.2 mm (7.3 in.); diameter: 51 mm (2 in.)
  • Net weight: 340 g (12 oz.)
  • Shipping weight: 655 g (1.45 lbs.)
  • Patent(s): Varimotion – multiple-thickness diaphragm for dynamic transducer (Patent no. AT 403.751, US 6,185,809, EP 814.637 (DE, DK, FI, FR, GB, IT, NL), JP 3.927.651)
  • Also found as: 3138 Z 00070, 3138Z00070, AKD5, D 5, D5

Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

123
-33.36%

$79.96

List price $119.99

Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth

44
-16.69%

$149.95

List price $180.00

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

SXE-6926S main

Alpine SXE-6926S

280W Peak (90W RMS) 6x9” SXE Series 2-way 4-ohm Coaxial Speakers

13
-20.84%

$56.99

List price $71.99

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99


Best selling similar products

GMR-MIC small

MB Quart GMR-MIC

• Waterproof Marine Stereo Microphone
• Designed for use with MB Quart GMR-7V1 marine stereo
• 3.5mm audio mini jack connection
• IP67 waterproof rating

$37.50

List price $39.00

JBLPBM100BLKAM small

JBL PBM100 (JBLPBM100BLKAM)

• Wired microphone for JBL PartyBox speakers
• Sleek, rugged built-to-last stage quality casing
• Wire mesh cap with windscreen

$54.95

List price $66.00

Specifications & Details


Microphone Specifications
Microphone Type
Handheld
Designed Applications
Vocals
Spoken Word
Public Address
Karaoke
Number of Microphones
1
Polar Patterns
Super-Cardioid
Transducer Type
Dynamic
Address
Top
Frequency Response
70 - 20,000 Hz
Sensitivity
-52 dB
Maximum Sound Pressure Level
156 dB
Output Impedance
600 ohm
Power Requirement
None
Connection Type
XLR
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

AKG

Model Number:

3138 Z 00070

Weight:

1.20lbs

Internal SKU:

d5

Internal Product ID:

30696
