Gemini XGA-4000

4000W High Power Professional Power Amplifier with DC Output Protection & Short Circuit Protection

Gemini
Shop all Gemini
highlight-star-icon

High Power Professional Power Amplifier • 4000 Watts Peak • Front-To-Rear Airflow • Cooling Fan • Limiter Circuit Switch • Stereo and Mono Bridge • Front Panel Indicators • 3 Speakon Outputs • Rack Mountable

Learn more about the xga4000

We apologize

This item has been discontinued


Loading...
82-7805 main

Metra 82-7805

6" to 6-3/4" Speaker Plate Adapter for select 2004-2023 vehicles from Honda, Acura

12
-47.38%

$19.99

List price $37.99

72-7800 main

Metra 72-7800

Install New Speakers in select 1990-2024 vehicles from Honda, Acura, Isuzu

90
-33.36%

$9.99

List price $14.99

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Description


Gemini brand icon

Authorized dealer

Gemini XGA-4000 Power Amplifier

The XGA series power amps come in four models with different wattage: XGA-5000, XGA-4000, XGA-3000, and XGA-2000. Each amp comes designed to deliver maximum wattage and power to any speaker. Each XGA amp is durable and lightweight, and offers unmatched value in their class. With their powerful reliable performance, the XGA series amps easily handle any amount of usage and can deliver deep, pulsating lows that rattle your insides. Each amp also comes with a variable-speed cooling fan. Their extreme reliability, clean sound, and durability make them the professional’s choice when it comes to sound.

Product Features
  • High Power Professional Power Amplifier
  • Power Handling
    • 8 ohm: 250 watts x 2 chan.
    • 4 ohm: 350 watts x 2 chan.
    • Bridged @ 8 ohm: 700 watts x 1 chan.
  • 4000 Watts peak
  • Front-to-rear airflow and cooling fan for thermal stability and reliability
  • XLR and 1/4” (6.5mm Jack) balanced and RCA unbalanced inputs
  • Limiter circuit switch for amp output protection
  • Stereo and mono bridge
  • Variable speed fan for low noise
  • Comprehensive front panel indicators including signal, clip, protect and bridge
  • 3 Speakon outputs for channels A/B/Bridge
  • 5-Way binding banana plug channel outputs
  • Bridge control switch
  • DC output protection and Short circuit protection
  • Ground lift switch
  • Rack mountable
  • Frequency Response: 10-50,000 Hz
  • Total Harmonic Distortion: Less than 0.1%
  • Input Sensitivity & Impedance: 0.77v
  • Signal-To-Noise Ratio: >90 dB
  • Dimensions: 13-13/16"D x 19"W x 3-1/2"H
  • 1-year Manufacturer's warranty

Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

123
-33.36%

$79.96

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

PH654 main

Cerwin-Vega PH654

600W Peak (300W RMS) 6.5" PRO Series Full Range Coaxial 4-ohm Speakers

2
-16.67%

$189.99

List price $227.99

SXE-1726S main

Alpine SXE-1726S

440W Peak (80W RMS) 6.5" SXE Series 2-way 4-ohm Coaxial Car Speakers

13
-21.82%

$42.99

List price $54.99


Best selling similar products

VS-1200-AMP small

Wet Sounds VS-1200-AMP

• Venue Series 4-Channel Class D Power Amplifier
• Power RMS @ 4 ohm: 200 watts x 4 channel
• Power RMS @ 2 ohm: 300 watts x 4 channel
• Cooling fan for cooling system

$1249.99

List price $1249.99

VS-AmplifierSystem-4 small

Wet Sounds VS-AmplifierSystem-4

• Venue Series 4-Channel Class D Power Amplifier
• Includes VS-LS-ENC landscape enclosure
• Power RMS @ 4 ohm: 200 watts x 4 channel
• Power RMS @ 2 ohm: 300 watts x 4 channel
• Cooling fan for cooling system

$1999.98

List price $1999.98

Specifications & Details


Power Specifications
Number of Channels
2 Channels
Continuous Power @ 8 ohm
250 watts x 2 channel
Continuous Power @ 4 ohm
350 watts x 2 channel
Continuous Power @ 8 ohm (Bridged)
700 watts x 1 channel
Total Continuous Power
700 watts
Max Power Output
4000 watts x 1 channel
Total Max Power
4000 watts
Amplifier Specifications
Signal-to-Noise Ratio
>100 dB
Frequency Response
10 - 50000 Hz
THD (Total Harmonic Distortion)
0.1%
Cooling Options
Cooling Fan
Inputs
1/4" TRS
RCA
XLR
Outputs
Binding Posts (Banana Clip Ready)
SpeakOn
Physical Specifications
Height
3-1/2"
Width
13-13/16"
Depth
19"
Weight (Pounds)
25.8 lbs
Rackmount Spaces
2U
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

XGA-4000

Weight:

25.80lbs

Internal SKU:

xga4000

Internal Product ID:

33380

Customer Ratings & Reviews


Gemini XGA-4000 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
4
Usability
5

Customer Reviews

Sort by:

Loading...

Great!

I spent a lot of time looking online for a amp that had good quality with all the features that i wanted. The gemini had it. Its a great amp with a lot of power. The cooling fan keeps it nice and cool. It seems really durable if you move from place to place all the time with it.
