RE Audio XXX15 Factory Refurbished

(Factory Refurbished) 15" Dual 2 ohm XXX Series Subwoofer (XXX15D2)

RE Audio
Shop all RE Audio
Product videos
highlight-star-icon

15" XXX Series Car Subwoofer • 2000 Watts RMS • Dual 2 ohm • Rubber Surround • Dual Composite 2-Piece Cone • Tork-Tite Terminals • Dual Progressive Spiders • Triple Stacked Magnets • Flat Wire Voice Coil • Venting System

Learn more about the LS-xxx15d2-RB

We apologize

This item has been discontinued

Product Highlights


15" XXX Series Car Subwoofer • 2000 Watts RMS • Dual 2 ohm • Rubber Surround • Dual Composite 2-Piece Cone • Tork-Tite Terminals • Dual Progressive Spiders • Triple Stacked Magnets • Flat Wire Voice Coil • Venting System

Description


RE Audio brand icon

Authorized dealer

Item Condition - Refurbished:

A manufacturer refurbished product will function like new with all parts inspected or replaced as necessary. There may be slight cosmetic issues such as scratches or similar. See the description for additional details.

Built for Brutality

You’ve stumbled upon RE Audio’s XXX Subwoofer. Don’t be afraid. This subwoofer is built for brutality, but capable of so much more. This subwoofer competes with any high output SPL based subwoofer, but is capable of outputting amazing sound quality as well.

RE Audio knew this subwoofer was meant for those serious about the bass in their vehicles, and manufactured this subwoofer accordingly. With such a gigantic magnet, a new venting system had to be engineered; this Vented Magnet System (or VMS) allows the subwoofer to output amazing levels of power without getting too hot.

RE Audio’s XXX Subwoofer may intimidate some, however after getting to know the XXX Subwoofer, it has a kind side as well. One part of the RE Audio XXX Subwoofer completely boasts pure, unrivaled power handling, engineered primarily for excess. Another side of the XXX may surprise some, the subwoofer also sounds extremely clean and tightly responsive. RE Audio XXX Subwoofers are proudly manufactured in the USA, RE Audio truly cares about fine crafting their flagship subwoofers.

Subwoofer Features:
  • 15" Dual 2 ohm XXX Series Car Subwoofer
  • Power Handling:
    • RMS: 2000 watts
  • Impedance: Dual 2 ohm
  • Kevlar reinforced kraft pulp, dual composite 2-piece cone
  • Rubber surround
  • Integrated tinsel leads
  • FEA Optimized motor structure
  • Dual progressive spiders
  • Integrated gasket
  • Tork-Tite terminals
  • 3" 4-Layer aluminum flat wire voice coil
  • Split coil design
  • VMS Vented magnet system
  • Cast aluminum basket
  • Triple stacked magnets
  • Designed specifically for sealed or ported enclosures
  • Proudly made in the USA
  • Authorized Internet Dealer
  • 90 Day Manufacturer's warranty
XXX 15" T/S Parameters:
  • Electrical Q Value (Qes): 0.58
  • Mechanical Q Value (Qms): 3.62
  • Total Speaker Q Value (Qts): 0.501
  • Free Air Resonance (Fs): 19.10 Hz
  • Equivalent Compliance (Vas): 207 liters
  • One-Way, Linear Excursion (Xmax): 54 mm
  • Efficiency (SPL 1W/1m): 85.81 dB SPL
  • Effective Piston Area (Sd): 810 cm2
  • DC Resistance (Re): 4.2 ohm
  • Nominal Impedance (Znom): Dual 2 ohm
  • Thermal Power Handling (Pe): 2000 W
  • Force Factor (Bl): 18.16

For more information on the Thiele and Small Parameters, visit our T/S Parameters Article

Subwoofer Wiring Guide


Wiring Guide to Wire 1 RE Audio XXX15 Factory Refurbished Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 RE Audio XXX15 Factory Refurbished Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 RE Audio XXX15 Factory Refurbished Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 RE Audio XXX15 Factory Refurbished Subwoofers

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Subwoofer Size
15"
RMS Power Handling
2000 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohm
Xmax (millimeters)
54 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Kevlar reinforced kraft pulp, dual composite 2-piece cone
Woofer Surround
Rubber
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
1.6 cubic feet
Maximum Sealed Box Volume
2.1 cubic feet
Minimum Ported Box Volume
3.2 cubic feet
Maximum Ported Box Volume
4.0 cubic feet
Top-Mount Depth (Mounting Depth)
13-1/2"
Cutout Diameter
14-1/2"
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
90 days
Labor Warranty Duration
90 days
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

XXX15D2-RB

Weight:

100.00lbs

Internal SKU:

LS-xxx15d2-RB

Internal Product ID:

38792

Product and How-to Videos


  • RE Audio New Product Line Overview | CES 2015
  • Car Subwoofer Size Buying Guide | What Size of Sub Should I Get?
