Rockford Fosgate Punch P3SD4-8 (Open Box, Like New)

300W Peak (150W RMS) 8" Punch Series Dual 4-ohm Shallow Car Subwoofer

Lowest price in 30 days
highlight-star-icon

• Peak Power: 300 watts
• RMS Power: 150 watts
• Impedance: Dual 4 ohm
• Anodized Aluminum Cone
• M-Roll Santoprene Surround
• Mount depth: 2.66"
• Sensitivity: 82 dB

Learn more about the p3sd48_obn

We apologize

This item has been discontinued

Description


Rockford Fosgate brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


Punch P3SD4-8

The Rockford Fosgate P3S 8" shallow mount subwoofer delivers Punch, even in depth limited situations. Rockford Fosgate understands all vehicles are not the same, because some cannot accommodate deep subwoofers. In the past, that meant no Bass. Not anymore! Now even depth challenged vehicles can have REAL Bass and the Dual Voice Coil allow configurations for every application. Shallow woofers are specifically designed for spaces where a traditional woofer cannot be used.


Rockford Fosgate Punch P3 P3SD4-8

300W Peak (150W RMS) 8" Punch Series Dual 4-ohm Shallow Car Subwoofer
Quantity: 1

Product Details:

  • 8" Dual 4 ohm Punch Series Subwoofer
  • Power Handling:
    • Peak: 300 watts
    • RMS: 150 watts
  • Anodized Aluminum Cone
  • M-Roll Santoprene Surround
  • Shallow Motor Assembly
  • Dual linear spider with embedded 16 AWG tinsel leads
  • Diamond cut cast aluminum trim ring
  • StampCast basket with integrated spider venting
  • Optimized for both sealed and vented enclosures
  • 2" High Temperature Voice coil
  • 8.5 mm Xmax
  • 37.5 oz. Double Stacked magnet motor structure
  • Frequency Response: 38 - 250 Hz
  • Resonance Frequency (Fs): 39 Hz
  • Sensitivity: 82 dB
  • Recommended sealed box volume: 0.25 cubic feet
  • Recommended ported box volume: 0.75 cubic feet
  • Top-mount depth: 2.66"
  • Cutout diameter: 7.13"
  • CTA-2031 Compliant
  • Authorized Internet Dealer
  • Optional protective subwoofer grille (sold separately) Rockford Fosgate P3SG-8
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Rockford Fosgate Punch P3SD4-8 (Open Box, Like New) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Rockford Fosgate Punch P3SD4-8 (Open Box, Like New) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Rockford Fosgate Punch P3SD4-8 (Open Box, Like New) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Rockford Fosgate Punch P3SD4-8 (Open Box, Like New) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Punch Series
Subwoofer Size
8"
Peak Power Handling
300 watts
RMS Power Handling
150 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
2"
Frequency Response
38 - 250 Hz
Sensitivity
82 dB
Xmax (millimeters)
8.5 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Anodized Aluminum
Woofer Surround
M-Roll Santoprene
Magnet Structure
Double Stacked
Magnet weight
37.5 oz.
Subwoofer Grille
Optional (Accessory required and sold separately)
CTA-2031 Compliant
Yes
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.25 cubic feet
Optimum Ported Box Volume
0.75 cubic feet
Top-Mount Depth (Mounting Depth)
2.66"
Cutout Diameter
7.13"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
39 Hz
Equivalent Compliance (Vas)
15.8 liters
Total Speaker Q Value (Qts)
0.87
Electrical Q Value (Qes)
1.05
Electrical Resistance of Voice Coil (Re)
6.0 ohm
Mechanical Q Value (Qms)
5
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

P3SD48_OBN

Weight:

10.00lbs

Internal SKU:

p3sd48_obn

Internal Product ID:

223742

Customer Ratings & Reviews


Rockford Fosgate Punch P3SD4-8 (Open Box, Like New) thumbnail image

5 star
50%
4 star
25%
3 star
25%
2 star
0%
1 star
0%



Durability
4.4
Value
4.7
Features
4
Design
4.7
Usability
4.4

Customer Reviews

Sort by:

Loading...

2012 dodge ram 1500 w/alpine system

The following review is for P3SD4-8, which is a part of the bundle you are viewing.

replaced factory sub with this RF sub in original factory plastic box and not much of a difference but you do hear more punch to it than the factory one. Powered by an alpine MRP-F300 is too much power for the RF sub , it starts to pop. Gain has to be set all the way down. Im going to power the sub with factory amp and use the alpine 4 channel amp to power all 4 door speakers see the results. Great sub though!

By Omar on May 24, 2013

69 found this helpful


Tight Little Sub

The following review is for P3SD4-8, which is a part of the bundle you are viewing.

I bought this sub to compliment my 6.5" comps up front in a big ole Tundra. I have 75 watts to the front stage and 250@ 2ohms to the sub in a sealed box. It's a perfect match. Nice full clean sound throughout the vehicle. I know 250watts is a bit high for this speaker,but it's in a sealed box and I listen to heavy music mostly, it handles it just fine. It feels great in your hands, solid construct. Very happy!!!!!

By CFuzz on September 5, 2013

60 found this helpful


Not a bad sub

The following review is for P3SD4-8, which is a part of the bundle you are viewing.

I have not had a sub any smaller than a 12" in the past, so I do not have a frame of reference for output of these subs. I have also never owned a Rockford Fosgate product. With all of that being said, I was very pleased right out of the box with the styling and sturdiness of the construction of the product. The dual voice coils provide a lot of flexibility with the wiring. I have two of these subs in a 0.45 sq ft enclosure with polyfil wired at a 4 ohm load and 150W per sub. They are not overpowering but are doing well so far.

By Eric on January 2, 2017

37 found this helpful


The following review is for P3SD4-8, which is a part of the bundle you are viewing.
By Charles on October 27, 2024 Checkmark Icon Verified purchase

4 found this helpful
