Rockford Fosgate Punch P3SD4-10 (Open Box, Like New)

600W Peak (300W RMS) 10" Punch Series Dual 4-ohm Shallow Car Subwoofer

Lowest price in 30 days
highlight-star-icon

• Peak Power: 600 watts
• RMS Power: 300 watts
• Impedance: Dual 4 ohm
• Anodized Aluminum Cone
• M-Roll Santoprene Surround
• Mount depth: 3.50"
• Sensitivity: 83 dB

Learn more about the p3sd410_obn

We apologize

This item has been discontinued

Description


Rockford Fosgate brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


Punch P3SD4-10

The Rockford Fosgate P3S 10" shallow mount subwoofer delivers Punch, even in depth limited situations. Rockford Fosgate understands all vehicles are not the same, because some cannot accommodate deep subwoofers. In the past, that meant no Bass. Not anymore! Now even depth challenged vehicles can have REAL Bass and the Dual Voice Coil allow configurations for every application. Shallow woofers are specifically designed for spaces where a traditional woofer cannot be used.


Rockford Fosgate Punch P3 P3SD4-10

600W Peak (300W RMS) 10" Punch Series Dual 4-ohm Shallow Car Subwoofer
Quantity: 1

Product Details:

  • 10" Dual 4 ohm Punch Series Subwoofer
  • Power Handling:
    • Peak: 600 watts
    • RMS: 300 watts
  • Anodized Aluminum Cone
  • M-Roll Santoprene Surround
  • Shallow Motor Assembly
  • Optimized for both sealed and vented enclosures
  • StampCast basket with integrated spider venting
  • Dual linear spider with embedded 16 AWG tinsel leads
  • Diamond cut cast aluminum trim ring
  • 2.5" High Temperature Voice coil
  • 10-13/16 mm Xmax
  • 47 oz. Double Stacked magnet motor structure
  • Frequency Response: 45 - 250 Hz
  • Resonance Frequency (Fs): 42 Hz
  • Sensitivity: 83 dB
  • Recommended sealed box volume: 0.5 cubic feet
  • Recommended ported box volume: 1.0 cubic feet
  • Top-mount depth: 3.50"
  • Cutout diameter: 9.06"
  • CTA-2031 Compliant
  • Authorized Internet Dealer
  • Optional protective subwoofer grille (sold separately) Rockford Fosgate P3SG-10
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Rockford Fosgate Punch P3SD4-10 (Open Box, Like New) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Rockford Fosgate Punch P3SD4-10 (Open Box, Like New) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Rockford Fosgate Punch P3SD4-10 (Open Box, Like New) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Rockford Fosgate Punch P3SD4-10 (Open Box, Like New) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Punch Series
Subwoofer Size
10"
Peak Power Handling
600 watts
RMS Power Handling
300 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
2.5"
Frequency Response
45 - 250 Hz
Sensitivity
83 dB
Xmax (millimeters)
10-13/16 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Anodized Aluminum
Woofer Surround
M-Roll Santoprene
Magnet Structure
Double Stacked
Magnet weight
47 oz.
Subwoofer Grille
Optional (Accessory required and sold separately)
CTA-2031 Compliant
Yes
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.5 cubic feet
Optimum Ported Box Volume
1.0 cubic feet
Top-Mount Depth (Mounting Depth)
3.50"
Cutout Diameter
9.06"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
42 Hz
Equivalent Compliance (Vas)
14.3 liters
Total Speaker Q Value (Qts)
0.78
Electrical Q Value (Qes)
0.90
Electrical Resistance of Voice Coil (Re)
6.80 ohm
Mechanical Q Value (Qms)
6
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

P3SD410_OBN

Weight:

11.50lbs

Internal SKU:

p3sd410_obn

Internal Product ID:

223744

Customer Ratings & Reviews


Rockford Fosgate Punch P3SD4-10 (Open Box, Like New) thumbnail image

5 star
64%
4 star
27%
3 star
9%
2 star
0%
1 star
0%



Durability
4.6
Value
4.2
Features
4.5
Design
4.7
Usability
4.7

Customer Reviews

Sort by:

Loading...

p3 shallow 10s

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

i put 2 p3 shallows under the back seat in my f150 and couldnt be happier. i only have a cheap amp pushing them for now and they are way louder then i would have ever expected out of 2 10s

By moto for life on March 21, 2014

68 found this helpful


Great little sub!

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

Put this in a Q-Logic custom box, 0.66 cubic ft., for a 06 Dodge Ram Quad, the box was expensive but worth it, and powered it with Rockford Fosgate P300X1. This little guy is a great upgrade for folks looking for some extra thump. Also put Fosgate in the doors and a Pioneer head. If you listen to rock or country this is a phenom with the correct box and head. If you want SPL in the tight space of the Dodge I would go with the loaded MTX.

By Broken on April 25, 2014

60 found this helpful


Great subs!

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

I have two of these subs in my 2005 4 door 2500hd chevy silverado and that sound great they thus hard and clean I'm running them at 2 ohms with a nvx jad 1200.1d I love them they might not go as deep as full size but they sound great rockford all the way!

By Georgia boy on February 9, 2013

62 found this helpful


good

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

Excellent product. I would recommend to everyone to buy and head pretty good for being a shallow mount subwoofer

By jose on June 9, 2014

60 found this helpful


great value

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

Great sub! Performance is fantastic. I have it in a vented enclosure and sounds great.

By jason on September 11, 2015

55 found this helpful


03 Tundra extended cab!!!!

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

I was told nothing fits in this truck except the Qforms sub box that holds 2- 8" shallow mount subs. This speaker was the solution. Made a new sub floor under the back seat *unbolted stock metal frame* and now I've got 10" sub where I was told there's nothing that fits. Sounds great super happy.

By Jason S on March 6, 2014

55 found this helpful


Great Sub!!!!

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

I have 2 of these sub in my 05 colorado crew cab. Sounds nice and clean.

By JMIR2K11 on December 3, 2012

51 found this helpful


Good sub

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

If you just want some better quality sound than stock without taking up too much room, this is for you. If you're younger or looking for heavy bass, stay away. This shallow sub is supposed to be tucked away, who cares what it looks like.

I have mine set at 20Hz - 60/70Hz crossover frequency with a Rockford fosgate PBR 300x1 amp. This setup takes up almost no room in my little car, and it doesn't weigh a lot which is good. The bass output is decent to below par, but it's a good overall sound which I prefer now in my 30's. It isn't going to drain out your mid or high range at all, and it won't rattle your car or head to pieces. But it will annoy other drivers and your neighbors. It's a nice blend but nothing to write home about. Better than anything in an OEM setup for sure.

By Mike on February 25, 2017

45 found this helpful


Great shallow subwoofer!

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

Great product, thumps good for being in a small sealed enclosure, hits hard when you want it to but nice and clean also for good sq builds.

By Timmyt on June 27, 2016

41 found this helpful


Mildly ok

The following review is for P3SD4-10, which is a part of the bundle you are viewing.

Decent product. I’m just not happy with it. Hits some notes great, others sound sloppy on this woofer. I’ve found it really hard to adjust & find the “sweet” spot. I’ve even taken it back to the professional shop that installed it & they said the same thing. It’s not terrible however, I do wish now that I would’ve went with another brand.

By tommy on March 15, 2024 Checkmark Icon Verified purchase

15 found this helpful
