NuVOICE UF-3

Product Features:

• UHF Wireless Flute System
• Diversity receiver design eliminates dropouts caused by multipathing and interference
• 16 operating channels allow for multiple sets to be used simultaneously
• Operating range of up to 150 feet
• Adjustable squelch control to minimize outside interference
• TS ¼” audio output
• 3 LEDs display power, battery, and antenna link status
• Receiver can operate on 2 AA batteries or included DC power adapter
• Receiver can be paired with any one of the five U-Series transmitters:
• UG-3
• UG-9
• UF-3
• US-3
• UV-3
• Also found as: UF3
• Authorized Internet Dealer
• 1-year Manufacturer's Warranty

Specifications:

Transmitter:
• RF Output Power: 10dBm ± 1dBm
• Spurious: -50dBm
• Modulation Factor: 40kHz
• Pre-emphasis: 50u/sec
• Max. Input Level: +2dBv
• Input Impedance: 20K ohm
• T.H.D.: < 0.8% (1kHz 100mV)
• Frequency Response: 50Hz - 20kHz ± 3dB
• Operating Power Voltage: 1.5V typical, 1.1V min. - 2V max.
• Current Consumption: 80mA
• Battery Life: 12 hrs. (AAA size battery)
• Antenna: Permanently Attached 1/4 Wave Length Wire
• Controls: Power / 15dB Pad Switch
• LED Indicators: Power On (flash) / Low Battery (solid)
• Receiver:
• Frequency Range: 900MHz - 925MHz
• Modulation Type: F3E
• OSC (Oscillator) System: PLL Circuit
• Operating Range: Approx. 328 Feet (100 m)
• De-emphasis: 50u/sec
• Operating Temperature: 0°C - 50°C (32°F - 122°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Receiving Sensitivity: SINAD > 30dB 10dBuV
• Squelch Sensitivity: 17dBuV ± 4dBuV
• S/N (Signal-to-Noise) Ratio: 95dB (A) (f1kHz = 1mV)
• Audio Output Level at div.f15kHz: 800mV (f40kHz)
• Frequency Response: 50Hz - 20kHz ± 3dB
• T.H.D. (@ SG Output 56dBuV): < 0.8% (f1kHz)
• Output Impedance: 5K - 10K ohm
• Power Supply: DC9V / 2x 3V AA Batteries
• Current Consumption: 9V / 60mA, 3V / 100mA
• Antenna: Dual 1/4 Wave Length Rod Antennas
• Controls:
• Audio Volume
• IR ACT
• Ch. Select
• Power
• LED Display:
• White: IR SEND
• Red: Power
• Yellow: Low Battery
• Orange/Green: Antenna
