JBL CS1014 (Open Box, Complete)

125W 10" CS Series Single 4 Ohm Subwoofer - Open Box, Good Condition Used

JBL
Shop all JBL
highlight-star-icon

• Peak Power: 500W
• RMS Power: 125W
• Impedance: 4 ohm
• Polypropylene Cone
• Rubber Surround
• Resonance Frequency (Fs): 30 Hz

Learn more about the ls-cs1014-obc5

We apologize

This item has been discontinued

Description


JBL brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Good Condition:
A Good Open Box used product shows wear from consistent use, but it remains in good condition and works perfectly. It may be marked, have identifying markings on it, or show other signs of previous use or installation. Original packaging, paperwork or protective wrapping may be missing or not included in its entirety. Warranty details are included in the item description or comments.


Hear The Rumble Of The Music, Not The Road.

With 500 watts of peak power handling, the JBL CS Series CS1014 subwoofer outperforms anything you may have heard before. Its polypropylene woofer cone is light as a feather, ensuring maximum efficiency and performance. A progressive spider provides exceptional control, reducing distortion at even the highest output levels.



The Sound of quality

Sonic Electronix, one of the leaders in car audio, recently visited Harman, the premium global audio and infotainment group, at their research and development locations in Northridge, California and Detroit, Michigan. The purpose of these visits was to utilize and combine the powerful brand of Harman and the industry leading knowledge behind Sonic Electronix to begin working together on developing future car audio projects.


General Features:

  • 10" Single 4 Ohm CS Series Car Subwoofer
  • Power Handling:
    • Peak: 500 watts
    • RMS: 125 watts
  • Recommended power range: 50 - 150 watts RMS
  • Impedance: 4 ohm
  • High excursion, high BL motor
  • Polypropylene Cone
  • Rubber Surround
  • 1-1/2 Voice coil diameter
  • Frequency response: 45-200 Hz
  • Resonance Frequency (Fs): 30 Hz
  • Top-mount depth: 4-9/16"
  • Sensitivity: 90dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
Tips for Installing the your subwoofer



PROP 65 WARNING: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer or birth defects or other reproductive harm. Wash hands after handling. For more information, visit www.P65Warnings.ca.gov

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JBL CS1014 (Open Box, Complete) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JBL CS1014 (Open Box, Complete) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JBL CS1014 (Open Box, Complete) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JBL CS1014 (Open Box, Complete) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
CS Series
Subwoofer Size
10"
Peak Power Handling
500 watts
RMS Power Handling
125 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
1-1/2"
Frequency Response
45 - 200 Hz
Sensitivity
90 dB
Xmax (millimeters)
6.6 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Magnet Structure
Single Stacked
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Bandpass
Ported / Vented
Sealed
Minimum Sealed Box Volume
.6 cubic feet
Optimum Sealed Box Volume
.9 cubic feet
Maximum Sealed Box Volume
1.1 cubic feet
Minimum Ported Box Volume
.65 cubic feet
Optimum Ported Box Volume
.9 cubic feet
Maximum Ported Box Volume
1.2 cubic feet
Top-Mount Depth (Mounting Depth)
4-9/16"
Cutout Diameter
9"
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
30 Hz
Equivalent Compliance (Vas)
53.8 liters
Total Speaker Q Value (Qts)
.44
Electrical Q Value (Qes)
.46
Electrical Resistance of Voice Coil (Re)
3.67 ohm
Mechanical Q Value (Qms)
8.34
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

JBL

Model Number:

CS1014-2

Weight:

8.00lbs

Internal SKU:

ls-cs1014-obc5

Internal Product ID:

143355
