Alpine HCE-C210RD- OPEN BOX

HCE-C210RD Features:

• Add-on rear multi-view camera
• Product is Open Box
• Damaged Packaging
• Connects to any Alpine monitor
• Uses black box image processing and control
• Displays a mirror image
• Provides multiple wide angle views
• Allows for rear, panorama, corner, and ground views
• Rear Panoramic View: Displays 185 degrees
• Rear Top View: Displays an image from above to gauge distance
• Rear Corner View: Splits the image to the left and the right view
• Requires Alpine HCE-C212F when connected to any monitor with an RCA
• Comes with its own mounting bracket
• Perfect for parking in any situation
• Dimensions: 27/32"D x 29/32"W x 29/32"H
• 1-year SonicElectronix.com Warranty

HCE-C210RD Features:

• Power Requirements: 6.0V DC (5 to 9V allowable)
• Ground Type: Negative ground type
• Max Power Consumption: 0.8W
• Output Image: Normal Image, CVBS(NTSC) 16:9 Image Output for Wide Screen
• Image Output Impedance: 75 Ohm (1Vp-p)
• Image Sensor: 1/3.8 Type color CMOS Image Sensor, aspect ratio 4:3
• Effective Number of Pixels: 1280(H) x 960(V) approximately 1.23 Mega Pixels
• Lens Section: Focal Length f=0.89mm, Brightness F=2.8
• Angle of Field: 186°H & 144°V
• Automatic Image Adjusting Function: Automatic exposure and white balance adjustment
• Synchro-System: Internal synchronization
• Luminance S/N: 40dB or more
• Resolution (horizontal): 300 TV lines or more (central area)
• Illumination range: 2.0lx or more (50 IRE or more)
• Operating Temperature Range: -22° to +176°F (-30&def; to +80°C)
• Storage Temperature Range: -40° to +185°F (-40° to +85°C)
