JL Audio 13TW5v2-4 (Like New (Open Box))

600W RMS 13.5" TW5v2 Series Single 4-ohm Shallow Car Subwoofer

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon

• RMS Power: 600 watts
• Impedance: Single 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Santoprene Rubber Surround
• Mount depth: 2.625"
• Sensitivity: 85.63 dB

Learn more about the ls-13tw5v24-u9

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Product Highlights


• RMS Power: 600 watts
• Impedance: Single 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Santoprene Rubber Surround
• Mount depth: 2.625"
• Sensitivity: 85.63 dB

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


JL Audio 13TW5v2-4

In keeping with its “tight-spaces” mission, the 13TW5v2 is optimized for enclosures that are far smaller than most 12-inch woofers require and only a bit larger than the air space needs of a typical, small-box 10-inch woofer. The mounting system is designed to fit in about the same footprint as a typical 12-inch woofer. The 13TW5v2 is best used with amplifier power in the 250W - 600W range and is optimized to operate in a 0.80 cu. ft. (22.7 liters) sealed enclosure.


Product Details:

  • 13.5" Single 4 ohm TW5 Shallow Mount Series Subwoofer
  • Power Handling:
    • RMS: 600 watts
  • Mica Injected Polypropylene - MIPP Cone
  • Santoprene Rubber Surround
  • Cast alloy basket
  • 7-inch diameter voice coil
  • Unique design allows for small airspace requirements
  • Requires only 0.8 cubic feet of airspace
  • 13% greater linear excursion capability over previous model
  • Redesigned motor features an annular vent
  • DMA-optimized motor designs
  • 11 mm Xmax
  • Single Stacked magnet motor structure
  • Resonance Frequency (Fs): 27.61 Hz
  • Sensitivity: 85.63 dB
  • Recommended sealed box volume: 0.80 cubic feet
  • Top-mount depth: 2.625"
  • Cutout diameter: 12.50"
  • Authorized Internet Dealer
  • JL Audio SGRU-13 optional protective subwoofer grille (sold separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

PDF IconJL Audio 13TW5V24 owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 13TW5v2-4 (Like New (Open Box)) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 13TW5v2-4 (Like New (Open Box)) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 13TW5v2-4 (Like New (Open Box)) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 13TW5v2-4 (Like New (Open Box)) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
TW5 Shallow Mount Series
Subwoofer Size
13.5"
RMS Power Handling
600 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
7"
Sensitivity
85.63 dB
Xmax (millimeters)
11 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mica Injected Polypropylene - MIPP
Woofer Surround
Santoprene Rubber
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Sealed
Optimum Sealed Box Volume
0.80 cubic feet
Top-Mount Depth (Mounting Depth)
2.625"
Cutout Diameter
12.50"
Shallow Mount Installation
Yes
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
27.61 Hz
Equivalent Compliance (Vas)
60.31 liters
Total Speaker Q Value (Qts)
0.526
Electrical Q Value (Qes)
0.553
Electrical Resistance of Voice Coil (Re)
3.513 ohm
Mechanical Q Value (Qms)
10.692
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

13TW5v2-4-4

Weight:

23.15lbs

Internal SKU:

ls-13tw5v24-u9

Internal Product ID:

227548

Product and How-to Videos


  • Cutting Open a JL Audio TW5 Shallow Sub | Subwoofer Guts!
  • JL Audio TW5 Thin-Line Subwoofer | Best Shallow Mount Sub Ever?
  • Car Subwoofer Size Buying Guide | What Size of Sub Should I Get?
