JL Audio 10W1v3-2 (Open Box, Great)

300W RMS 10" W1v3 Series Single 2-ohm Subwoofer

JL Audio
Shop all JL Audio
Product videos
highlight-star-icon


• RMS Power: 300 watts
• Impedance: Single 2 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 4.6"
• Sensitivity: 83.9 dB

Learn more about the ls-10w1v32-u8

We apologize

This item has been discontinued

Product Highlights



• RMS Power: 300 watts
• Impedance: Single 2 ohm
• Mica Injected Polypropylene - MIPP Cone
• Rubber Surround
• Mount depth: 4.6"
• Sensitivity: 83.9 dB

Description


JL Audio brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.


JL Audio 10W1v3-2

The 10W1v3 is an outstanding choice when space is very tight and amplifier power is moderate. It features shallow mounting depth (4.6 in. / 117 mm) and a compact motor structure, allowing it to comfortably fit in a lot of spaces where a typical 10-inch driver will not.

Lacking a pole vent, the rear of the motor structure can be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow it to reproduce sub-bass with shocking extension and quality.

The 10W1v3-2 is best used with amplifier power in the 75W - 300W range and is optimized to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.


Product Details:

  • 10" Single 2 ohm W1 v3 Series Subwoofer
  • Power Handling:
    • RMS: 300 watts
  • Mica Injected Polypropylene - MIPP Cone
  • Rubber Surround
  • DMA Optimized Motor
  • Elevated Frame Cooling design
  • Patented FCAM technology
  • Vented Reinforcement Collar (VRC) composite structure
  • 11 mm Xmax
  • Resonance Frequency (Fs): 25.23 Hz
  • Sensitivity: 83.9 dB
  • Recommended sealed box volume: 0.55 cubic feet
  • Recommended ported box volume: 0.90 cubic feet
  • Top-mount depth: 4.6"
  • Cutout diameter: 9.0625"
  • Authorized Internet Dealer
  • Does not includes subwoofer grille
  • 1-year Manufacturer's Warranty

  • Priced Individually

PDF IconJL Audio 10W1V32 owner’s manual

Product history:

JL Audio LS-10w1v32-u8 thumbnail
(newest, current model)
JL Audio 10W1v2-8 thumbnail
(previous model, replaced by JL Audio 10W1v3-2 (Open Box, Great))

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 10W1v3-2 (Open Box, Great) Subwoofer

Mono Amp

Wiring Guide to Wire 2 JL Audio 10W1v3-2 (Open Box, Great) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 10W1v3-2 (Open Box, Great) Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 10W1v3-2 (Open Box, Great) Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
W1 v3 Series
Subwoofer Size
10"
RMS Power Handling
300 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
2 ohm
Sensitivity
83.9 dB
Xmax (millimeters)
11 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mica Injected Polypropylene - MIPP
Woofer Surround
Rubber
Magnet Structure
Single Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.55 cubic feet
Optimum Ported Box Volume
0.90 cubic feet
Top-Mount Depth (Mounting Depth)
4.6"
Cutout Diameter
9.0625"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
25.23 Hz
Equivalent Compliance (Vas)
44.15 liters
Total Speaker Q Value (Qts)
0.436
Electrical Q Value (Qes)
0.463
Electrical Resistance of Voice Coil (Re)
2.233 ohm
Mechanical Q Value (Qms)
7.246
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Mounting screws (4)
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

LS-10w1v32-u8

Weight:

11.47lbs

Internal SKU:

ls-10w1v32-u8

Internal Product ID:

231187
