DC Audio Level 2 10 m2 D4 - Open Box, Acceptable Condition (Used)

1200W Peak 10" Level 2 Series m2 Version Dual 4-Ohm Car Subwoofer - M2LV210D4 - Open Box, Acceptable Condition (Used)

DC Audio
Shop all DC Audio
highlight-star-icon

• Peak Power: 1200W
• RMS Power: 600W
• Dual 4 ohm Voice Coil
• Extremely Rigid Non-Pressed Paper Cone Assembly
• Multilayered Polymer Wide Roll Foam Surround

Learn more about the LS-m2lv210d4-OBC4

We apologize

This item has been discontinued

Description


DC Audio brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

Item Condition - Open Box, Acceptable Condition:
An Acceptable Open Box used product is fairly worn and used, but functions and works. Signs of wear can include aesthetic issues such as scratches, dents, and worn corners or installation marks. The product may have identifying markings on it or show other signs of previous use. Original packaging, paperwork or protective wrapping may be missing or not included. Warranty details, if any, are included in the item description or comments.

General Features:

  • 10" Dual 4 ohm Level 2 Series m2 Version Car Subwoofer
  • Power Handling:
    • Peak: 1200 watts
    • RMS: 600 watts
  • Recommended power range: 200 - 600 watts RMS
  • Extremely rigid non-pressed paper cone assembly
  • Multilayered polymer wide roll foam surround
  • Polypropylene dust cover with embossed DC logo
  • 8" OD flat linear roll spider
    • Extra heavy duty interwoven tinsel lead wire sewn to spider
  • 2.5" high temperature copper voice coil
  • Rubber mounting gasket
  • Chrome spring loaded push terminals
  • FEA analyzed and optimized motor assembly
    • Fully CNC machined
  • Top-mount depth: 5.5"
  • Mounting Hole Diameter: 9.35"
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

m2 Level 2 10" T/S Parameters:

  • Electrical Q Value (Qes): 0.592
  • Mechanical Q Value (Qms): 8.96
  • Total Speaker Q Value (Qts): .555
  • Free Air Resonance (Fs): 35.6 Hz
  • Equivalent Compliance (Vas): 13.89 liters
  • One-Way, Linear Excursion (Xmax): 22 mm
  • Efficiency (Ref SPL @ 1W): 82.1 dB (82.6dB @ 2.83V)
  • Effective Piston Area (Sd): 324 cm²
  • DC Resistance (Re): 7.20 ohm
  • Nominal Impedance (Znom): Dual 4 ohm
  • Force Factor (Bl): 24
  • Mechanical Compliance (Cms): .095 mm/N
  • Mechanical Mass (Mms): 210 g
  • Voice Coil Inductance (Le): 7 mH
  • Suggested Sealed Enclosure: .5 ft³
  • Suggested Ported Enclose: 1.0 ft³

For more information on the Thiele and Small Parameters, visit our T/S Parameters Article

Subwoofer Wiring Guide


Wiring Guide to Wire 1 DC Audio Level 2 10 m2 D4 - Open Box, Acceptable Condition (Used) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 DC Audio Level 2 10 m2 D4 - Open Box, Acceptable Condition (Used) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 DC Audio Level 2 10 m2 D4 - Open Box, Acceptable Condition (Used) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 DC Audio Level 2 10 m2 D4 - Open Box, Acceptable Condition (Used) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Level 2 Series
Subwoofer Size
10"
Peak Power Handling
1200 watts
RMS Power Handling
600 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Voice Coil Diameter
2.5"
Sensitivity
82.1 dB
Xmax (millimeters)
22 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Non-Pressed Paper
Woofer Surround
Poly-Foam
Magnet Structure
Double Stacked
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.5 cubic feet
Optimum Ported Box Volume
1 cubic feet
Top-Mount Depth (Mounting Depth)
5.5"
Cutout Diameter
9.35"
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
35.6 Hz
Equivalent Compliance (Vas)
13.89 liters
Total Speaker Q Value (Qts)
.555
Electrical Q Value (Qes)
.592
Electrical Resistance of Voice Coil (Re)
7.20 ohm
Mechanical Q Value (Qms)
8.96
Warranty and Return Policy
Parts Warranty Duration
90 days
Labor Warranty Duration
90 days
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

M2LV210D4-2

Weight:

21.20lbs

Internal SKU:

LS-m2lv210d4-OBC4

Internal Product ID:

138133
