DC Audio Level 2 12D4 (M2LV212D4) (OPEN BOX COMPLETE)

600W RMS 12" Level 2 Series Dual 4 ohm Car Subwoofer

DC Audio
Shop all DC Audio
Product videos
highlight-star-icon

• Peak Power: 1200W
• RMS Power: 600W
• Dual 4 ohm Voice Coil
• Extremely Rigid Non-Pressed Paper Cone Assembly
• Multilayered Polymer Wide Roll Foam Surround

Learn more about the LS-m2lv212d4-OBCRA236535

We apologize

This item has been discontinued

Show me more products from this category
Go to Category

Product Highlights

• Peak Power: 1200W
• RMS Power: 600W
• Dual 4 ohm Voice Coil
• Extremely Rigid Non-Pressed Paper Cone Assembly
• Multilayered Polymer Wide Roll Foam Surround

Description

DC Audio brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.

This is an Open Box Item


We have checked, tested, and confirmed this item to function properly. It contains all the same parts as a new unit, but shows some visible signs of use.

This open box product has a 30-day return policy and a 90-day warranty

Item Condition: Open Box Complete

  • Item has been installed, used

    • General Features:

    • 12" Dual 4 ohm Level 2 Series Subwoofer
    • Power Handling:
      • Peak: 1200 watts
      • RMS: 600 watts
    • Extremely rigid non-pressed paper cone assembly
    • Multilayered polymer wide roll foam surround
    • Polypropylene dust cover with embossed DC logo
    • 8" OD flat linear roll spider
      • Extra heavy duty interwoven tinsel lead wire sewn to spider
    • 2.5" high temperature copper voice coil
    • Rubber mounting gasket
    • Chrome spring loaded push terminals
    • FEA analyzed and optimized motor assembly
      • Fully CNC machined
    • Top-mount depth: 6"
    • Mounting Hole Diameter: 11"
    • Authorized Internet Dealer
    • 1-year Manufacturer's Warranty

    m2 Level 2 12" T/S Parameters:

    • Electrical Q Value (Qes): 0.639
    • Mechanical Q Value (Qms): 8.46
    • Total Speaker Q Value (Qts): .594
    • Free Air Resonance (Fs): 33 Hz
    • Equivalent Compliance (Vas): 30.6 liters
    • One-Way, Linear Excursion (Xmax): 22 mm
    • Efficiency (Ref SPL @ 1W): 84.2 dB (84.7dB @ 2.83V)
    • Effective Piston Area (Sd): 481 cm²
    • DC Resistance (Re): 7.20 ohm
    • Nominal Impedance (Znom): Dual 4 ohm
    • Force Factor (Bl): 24
    • Mechanical Compliance (Cms): .095 mm/N
    • Mechanical Mass (Mms): 245 g
    • Voice Coil Inductance (Le): 7 mH
    • Suggested Sealed Enclosure: .75³ ft
    • Suggested Ported Enclose: 1.25³ ft

    For more information on the Thiele and Small Parameters, visit our T/S Parameters Article

    Subwoofer Wiring Guide

    Wiring Guide to Wire 1 DC Audio Level 2 12D4 (M2LV212D4) (OPEN BOX COMPLETE) Subwoofer

    Mono Amp

    2 Channel Amp - Bridged

    Wiring Guide to Wire 2 DC Audio Level 2 12D4 (M2LV212D4) (OPEN BOX COMPLETE) Subwoofers

    Mono Amp

    Mono Amp - Option 1

    2 Channel Amp

    2 Channel Amp - Bridged

    4 Channel Amp - Bridged

    Wiring Guide to Wire 3 DC Audio Level 2 12D4 (M2LV212D4) (OPEN BOX COMPLETE) Subwoofers

    Mono Amp

    4 Channel Amp

    Wiring Guide to Wire 4 DC Audio Level 2 12D4 (M2LV212D4) (OPEN BOX COMPLETE) Subwoofers

    Mono Amp

    2 Channel Amp

    2 Channel Amp - Bridged

    4 Channel Amp

    Specifications & Details

    Subwoofer Specifications
    Series
    Level 2 Series
    Subwoofer Size
    12"
    Peak Power Handling
    1200 watts
    RMS Power Handling
    600 watts
    Voice Coil(s)
    Dual
    Impedance (Per Voice Coil)
    4 ohm
    Voice Coil Diameter
    2.5"
    Sensitivity
    84.2 dB
    Xmax (millimeters)
    22 mm
    Subwoofer Design
    Round / Circle
    Main Cone Color
    Black
    Woofer Composition
    Non-Pressed Paper
    Woofer Surround
    Poly-Foam
    Magnet Structure
    Double Stacked
    Recommended Enclosure Specifications
    Recommended Enclosure Type
    Ported / Vented
    Sealed
    Optimum Sealed Box Volume
    0.75 cubic feet
    Optimum Ported Box Volume
    1.25 cubic feet
    Top-Mount Depth (Mounting Depth)
    6"
    Cutout Diameter
    11"
    T/S Parameters (Electromechanical)
    Free-Air Resonance (Fs)
    33 Hz
    Equivalent Compliance (Vas)
    30.6 liters
    Total Speaker Q Value (Qts)
    .594
    Electrical Q Value (Qes)
    .639
    Electrical Resistance of Voice Coil (Re)
    7.20 ohm
    Mechanical Q Value (Qms)
    8.46
    Warranty and Return Policy
    Parts Warranty Duration
    90 days
    Labor Warranty Duration
    90 days
    Warranty Provider
    Sonic Electronix

    Item Details

    Manufacturer:

    DC Audio

    Model Number:

    M2LV212D4-2

    Weight:

    21.80lbs

    Internal SKU:

    LS-m2lv212d4-OBCRA236535

    Internal Product ID:

    106047
