Image Dynamics ID8 D2 V.4

150W RMS 8" ID V.4 Series Dual 2 ohm Car Subwoofer

Product videos
highlight-star-icon

• Peak Power: 300W
• RMS Power: 150W
• Polypropylene Cone
• Rubber Surround

Learn more about the id8d2v4

We apologize

This item has been discontinued


Loading...
KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

CDX3119 main

Jensen CDX3119

Single DIN CD Multimedia Receiver with Bluetooth

3

Product Highlights


• Peak Power: 300W
• RMS Power: 150W
• Polypropylene Cone
• Rubber Surround

Description


Image Dynamics brand icon

Authorized dealer

General Features:

  • 8" Dual 2 ohm ID V.4 Series Subwoofer
  • Power Handling:
    • Peak: 300 watts
    • RMS: 150 watts
  • Recommend power range: 50 - 150 watts RMS
  • Mica Polypropylene cone woofer
  • Rubber surround
  • Top-mount depth: 4.75"
  • Cutout Diameter: 7.125"
  • Sensitivity: 85.4dB
  • Stamped steel basket for improved rigidity and better power handling
  • Optimized motor structure that uses finite element analysis for symmetrical and long linear excursion
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

T/S Parameters:

  • Re: .95/3.8 ohm
  • FS: 22.7 Hz
  • Qes: .317
  • Qms: 3.331
  • Qts: .289
  • Vas: 1.7ft3/48 L
  • Xmax: 15mm
  • Sd: 231 cm2

Product history:

Image Dynamics ID8 D2 V.4 thumbnail
(newest, current model)
Image Dynamics ID8 D2 V.3 thumbnail
(previous model, replaced by Image Dynamics ID8 D2 V.4)

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Image Dynamics ID8 D2 V.4 Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Image Dynamics ID8 D2 V.4 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Image Dynamics ID8 D2 V.4 Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 Image Dynamics ID8 D2 V.4 Subwoofers

2 Channel Amp

4 Channel Amp


Loading...
CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth (SiriusXM Ready)

43
-16.69%

$149.95

List price $180.00

Limited time!
XAV-AX8500 main

Sony XAV-AX8500

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Wired Android Auto (SiriusXM Ready)

2
-20.20%

$798.00

List price $999.99

DEH-S7200BHS main

Pioneer DEH-S7200BHS

Single DIN CD Receiver with Bluetooth, HD Radio and SiriusXM Ready

2
-10.72%

$249.99

List price $280.00

KMM-X705 main

Kenwood eXcelon KMM-X705

Single DIN Digital Media Receiver with Bluetooth, Built-in Alexa (Sirius XM Ready)

6
-20.40%

$199.00

List price $250.00

KDC-X305 main

Kenwood eXcelon KDC-X305

Single DIN CD Receiver with Bluetooth and Built-in Alexa (Sirius XM Ready)

23
-17.08%

$199.00

List price $240.00

CAR1013 main

Jensen CAR1013

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto

5
KDC-BT782HD main

Kenwood KDC-BT782HD

Single DIN CD Receiver with Bluetooth, Built-in Alexa, and HD Radio Tuner (SiriusXM Ready)

5
-18.89%

$219.00

List price $270.00

DMH-WT8000NEX main

Pioneer DMH-WT8000NEX

10.1" Single DIN Floating Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, Alexa and Dolby Atmos Feature (SiriusXM and iDataLink Maestro Ready)

-18.75%

$1,299.99

List price $1600.00

MEX-N5300BT main

Sony MEX-N5300BT

Single DIN CD Receiver with Bluetooth and Built-in NFC

4

$158.00

List price $159.99


Best selling similar products

VCW82v3 small

NVX VCW82 Version 3 (VCW82v3)

• Peak Power: 1300 watts
• RMS Power: 650 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• High Roll Foam Surround with black nylon stitching
• Mount depth: 5.31"
• Sensitivity: 83 dB (1W/1m)

(12)

$169.99

List price $203.99

DB-SA2508 D1 small

Deaf Bonce Apocalypse DB-SA2508 D1

• Peak Power: 1600 watts
• RMS Power: 800 watts
• Pressed Paper Cone
• Foam Surround
• Impedance: Dual 1 ohm
• Mount depth: 5.22"
• Sensitivity: 84.7 dB

(1)

$229.90

List price $229.90

47KBRW8 small

Kicker 47KBRW8 ReFLEX™

• 8" ReFLEX™ Passive Radiator
• Rubber covered plastic Cone
• Rubber Surround

(1)

$49.99

List price $59.99

VCW84v3 small

NVX VCW84 Version 3 (VCW84v3)

• Peak Power: 1300 watts
• RMS Power: 650 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 5.31"
• Sensitivity: 83 dB (1W/1m)

(15)

$169.99

List price $203.99

8W3V3-4 small

JL Audio 8W3V3-4

• RMS Power: 250 watts
• Impedance: Single 4 ohm
• Mineral-Filled Polypropylene Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 4.63"
• Sensitivity: 83.24 dB

(45)

$349.99

List price $349.99

L7S82 small

Kicker L7S82 (44L7S82)

• Peak Power: 900 watts
• RMS Power: 450 watts
• Impedance: Dual 2 ohm
• Injection Molded Polypropylene Cone
• Ribbed Santoprene Surround
• Mount depth: 4-3/4"
• Sensitivity: 82.37 dB

(1)

$175.96

List price $239.99

SPK-8S4 small

AudioControl SPK-8S4

• RMS Power: 500 watts
• Impedance: Single 4 ohm
• Paper Fiber with Mica Coating Cone
• Rubber Surround
• Mount depth: 4.291"
• Sensitivity: 81.9876 dB

(1)

$179.00

List price $229.00

KAPPA 83WDSSI small

Infinity Kappa 83WDSSI (INFSUBKA83WDSSIAM)

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Impedance: Single 2 or 4 ohm
• Glass Fiber Cone
• Rubber Surround
• Mount depth: 5.42"
• Sensitivity: 91 dB

(2)

$149.95

List price $289.95

8W1v3-4 small

JL Audio 8W1v3-4


• RMS Power: 150 watts
• Impedance: Single 4 ohm
• Mica Injected Polypropylene - MIPP Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 3.86"
• Sensitivity: 84.8 dB

(10)

$199.99

List price $199.99

CWRT84 small

Kicker CWRT84 (48CWRT84)

• Peak Power: 600 watts
• RMS Power: 300 watts
• Impedance: Dual 4 ohm
• UV-Treated Polypropylene Cone
• UV-resistant Santoprene Surround
• Mount depth: 2-11/16"
• Sensitivity: 81.8 dB

(4)

$151.96

List price $209.99

Specifications & Details


Subwoofer Specifications
Series
ID V.4 Series
Subwoofer Size
8"
Peak Power Handling
300 watts
RMS Power Handling
150 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohm
Sensitivity
85.4 dB
Xmax (millimeters)
15.5 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Polypropylene
Woofer Surround
Rubber
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
.2 cubic feet
Optimum Sealed Box Volume
.35 cubic feet
Maximum Sealed Box Volume
.45 cubic feet
Minimum Ported Box Volume
.5 cubic feet
Optimum Ported Box Volume
.6 cubic feet
Maximum Ported Box Volume
.9 cubic feet
Top-Mount Depth (Mounting Depth)
4.75"
Cutout Diameter
7.125"
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
22.7 Hz
Equivalent Compliance (Vas)
48 liters
Total Speaker Q Value (Qts)
.289
Electrical Q Value (Qes)
.317
Electrical Resistance of Voice Coil (Re)
3.8 ohm
Mechanical Q Value (Qms)
3.331
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

ID8 D2 V.4

Weight:

8.80lbs

Internal SKU:

id8d2v4

Internal Product ID:

94033

Product and How-to Videos


Customer Ratings & Reviews


Image Dynamics ID8 D2 V.4 thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
4.7
Usability
4.7

Customer Reviews

Sort by:

Loading...

Very Well Done

Running a pair of these units in a '17 RAM crew cab in 0.4 cu.ft. sealed enclosures. One is wired directly to the factory subwoofer amps (2 x 2 ohms) and the other to a 300W alpine class D amp and Audio Control LC2i processor (with voice coils in series for 4 ohms), both enclosures loosely filled with dacron batting. I am very impressed with how low they can go and how well controlled the bass output is. Not going to win any SPL competitions, but for music sound quality for all types of music, these units really work well and are very reasonably priced. Looks like Image Dynamics focused on the important things!

By Todd H. on February 12, 2018 Checkmark Icon Verified purchase

10 found this helpful


Great sound quality!

These little guys provide great sound quality in a very small sealed enclosure for a very affordable price. Very musical and clean lows...well done Image Dynamics!

By Andrew on March 4, 2016 Checkmark Icon Verified purchase

10 found this helpful


Old school sub but modern bass

Love, this subwoofer. Have had this sub for a while and it just keeps going. Not going to hear it down the block but it sounds great in the car.

By manuel on July 7, 2025 Checkmark Icon Verified purchase
