AudioControl DM-810

8-Channel DSP Matrix Processor with AccuBASS

Out of stock
highlight-star-icon

• Digital Sound Matrix Processor
• Allows users to truly optimize the performance of their audio system
• Line-level and Digital audio inputs
• 30 bands of equalization
• Dimensions: 10.5"W x 5.7"D x 1.6"H

Learn more about the dm810
Thanks , You Pay:

$749.00

 with warranty

Heads up

We confirm fitment and offer accessories for speakers. Please set your vehicle first if you would like to purchase more than one dm810.

Set your vehicle or Return to product page
Quantity
Out of stock - Order risk-free, cancel any time.
Brand new

Acima Logo

No Credit Option

Flexible Lease Payments

Early Purchase Options

Quick Approval Decision

Allstate logo

Keep your product protected longer! Extend the warranty after the manufacturer warranty expires.

  • Mechanical, electrical and product failure covered! 100% parts and labor covered. (Coverage starts after Mfr. warranty)
  • Easy online management! Zero hassle claim service, available 24/7
Swoosh Icon Icon of Swoosh

For over 23 years, we've been your X-Factor – the team dedicated to having the biggest impact on your shopping experience!

Award winning icon
Award-Winning Service
Shipping icon
FREE Shipping Orders $49+
60 days return policy icon
60-Day Easy Returns
lowest price guarantee icon
Guaranteed Lowest Price
inHouseExpert
In-House Experts

Description


AudioControl brand icon

Authorized dealer


AudioControl's award winning patented AccuBASS technology offers users unprecedented bass accuracy. In most systems the bass is reduced due to the stress put on the overall audio system when the volume is turned up. With AccuBass smart circuit technology, more bass is added to compensate for the loss and restore the levels to how it was intended to be heard. AccuBASS technology can also be used in an "always on" mode to enhance the low frequency performance of any sound system.

DM-810: Preview at CES 2016



General Features:

  • 2017 In-Vehicle Audio-Video "The Best of Innovation Award" Winner!
  • Premium Digital Sound Matrix Processor
  • 8 Input Channels
  • 10 Output Channels
  • Allows users to truly optimize the performance of their audio system
  • Compatible with factory or aftermarket source
  • Active speaker level inputs
  • Optional remote level knob (sold separately): AudioControl ACR-3 REMOTE
  • Line-level and Digital audio inputs
  • RTA (real-time analyzers) for inputs and outputs
  • Provides up to 10 channels of output
  • Configure settings such as:
    • 30 bands of equalization
    • Signal time-alignment
    • Input delay
    • Phase Control
  • Smart User Interface software included
  • Proprietary AudioControl Feature:
    • GTO Signal Sensing
    • MILC Clip Detection
    • AccuBASS
  • 12 and 26 dB/octave crossovers
  • Total Harmonic Distortion: 0.01%
  • Frequency Response: 20 Hz to 24 kHz
  • Recommended Fuse Rating: 2A
  • Dimensions: 10.5"W x 5.7"D x 1.6"H
  • Authorized Internet Dealer
  • 5 Year Manufacturer's Warranty

What's Included

  • DM-810
  • Power and Speaker Connectors
  • Manual
  • Warranty

AudioControl DM-810 manual

Specifications & Details


General Specifications
Equalizer Bands
30 band
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Built-in Bass Reconstruction
Yes
Speaker Level Inputs
Yes
Total Number of Inputs
8
Total Number of Outputs
10
Max Output Level
10 volts
Frequency Response
20 - 24,000 Hz
THD (Total Harmonic Distortion)
0.01%
Width
10.5"
Height
1.6"
Depth
5.7"
Warranty and Return Policy
Parts Warranty Duration
5 years
Labor Warranty Duration
5 years
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

DM-810

Weight:

5.00lbs

Internal SKU:

dm810

Internal Product ID:

107761

Customer Ratings & Reviews



5 star
71%
4 star
29%
3 star
0%
2 star
0%
1 star
0%



Durability
4.7
Value
4.9
Features
5
Design
4.6
Usability
4.7

Customer Reviews

Sort by:

Loading...

Unbelievable Sound.

Ignorance is bliss. You have no idea how much you are missing until you let AudioControl take over. This is what they do. They are the Kings of great sound, and this is thier latest testament to that. Soundstaging at its finest. The control the DM-810 gives you is without precedent, and so is the sound.

By Anonymous on November 3, 2018

15

found this helpful.

For the audiophile

THIS THING MADE MY SYSTEM COME ALIVE!! I did a lot of research before deciding on this Audio Control unit. To me, it had the most level of customization, and quality components, and once installed, I was truly blown away.

By Anonymous on August 4, 2018 Checkmark Icon Verified purchase

14

found this helpful.

Big Investment, ENORMOUS Payoff!!

This is pricey, but worth every dollar. I chose this DSP because it's made in the USA, and because it's AudioControl. They are the best at what they do and this product is no exception.

I looked at other DSPs, cheaper ones, and they all lacked one thing or another. The DM-810 had everything I was looking for. The software is extremely easy to install and use. The various connections will help keep this product relevant for many years to come. Installation of the DSP was a breeze and the results are mind blowing.

My factory system does not currently have any harnesses or dash kits to allow me change out my factory HU, nor bypass my factory amp. This seems to be the direction many car manufacturers are heading to. It is getting more difficult to upgrade car audio systems. This DSP will allow me to upgrade ANY vehicle I will ever own.

If you are serious about your car audio, this is a must have product. It is future-proof, has a 30 band EQ, allows for time alignment, can actively crossover all speakers, and sends the cleanest signal to your amps. Just make sure you also get the ACR-3 so you can have a bass knob and change your presets.

By Matt on September 2, 2017 Checkmark Icon Verified purchase

13

found this helpful.

amazing little DSP

not very many reviews for this product, so here is my 2 cents. good build quality . very easy to install. There is a bit of a learning curve as far as using the software, at least there was for me, but if you have experience with DSP's you should be fine. Once i got a better understanding of how the software works i could not be happier with the Audiocontrol DM810. it does a very effective job at cutting out all the low bass frequency's from my door speakers ,as it should. i have noticed with other built in crossovers and amplifier crossovers that they tend to let some bass in and ultimately end up distorting my sound. Not this unit, when it is set to cutoff under 100Hz ,its cut off! The time alignment is great and was very easy to set up. what i love best about the unit is the 30 band EQ, with a RTA mic and some pink noise tracks you can really get your sound at its best. The auto EQ feature is great for overriding the factory radios preset EQ curve and will send a nice flat signal to the DSP. This thing for me was worth the money. Highly recommend this to anyone wanting ultimate control of their sound.

By Jerry on June 28, 2017 Checkmark Icon Verified purchase

11

found this helpful.

Multiple speakers need processing

As an upgrade to a very similar processor, it should be great. If you want your speakers playing at correct ranges, this it, and it provides so much more.

By Jay on January 21, 2017

12

found this helpful.

Impressive!

Started setting this product mid-day, I was still playing around with the settings ten hours later! I was very pleased with the different presets I could save for my different music.
I am glad I held off buying a different brand dsp! Thanks!

By Greg on January 21, 2017

10

found this helpful.

By Jay on June 29, 2023 Checkmark Icon Verified purchase

4

found this helpful.
