JL Audio M12IB6-SG-TB (Open Box Complete)

12" 4-Ohm M-Series Marine Subwoofer with Titanium Sport Grill

JL Audio
Shop all JL Audio
highlight-star-icon

• 600W RMS
• Injection-Molded mica-filled polypropylene cone bodies
• Synthetic rubber surround specifically formulated with UV inhibitors
• Marine grade progressive roll synthetic fiber spider
• Gold-Plated marine-grade brass connection terminals
• Long linear excursion for enhanced output and reduced distortion

Learn more about the ls-m12ib6sgtb-obc

We apologize

This item has been discontinued

Description


JL Audio brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.


JL Audio M12IB6-SG-TB

JL Marine M12IB6-SG-TB - M Series 12" Marine Subwoofer Driver

Purpose-engineered and built for real marine duty, the M Series infinite-baffle subwoofers are designed to operate without a dedicated enclosure and are targeted towards moderate power applications. The M12IB6-SG-TB is best used with amplifier power in the 200W - 600W RMS range and is optimized to operate with a large volume of air behind it (at least 3 cu. ft.). Like all JL Audio marine speakers, this driver is built to withstand a real saltwater marine environment and deliver years of listening enjoyment.


General Features:

  • Item Condition: Like New, Open Box, Complete
    Not Refurbished






  • 12" M Series Infinite Baffle Marine Subwoofer
  • Power Handling:
    • RMS: 600 watts
  • Impedance: 4 ohm
  • Injection-Molded mica-filled polypropylene cone bodies
  • Synthetic rubber surround specifically formulated with UV inhibitors
  • Marine grade progressive roll synthetic fiber spider
  • Gold-Plated marine-grade brass connection terminals
  • Proprietary Dynamic Motor Analysis (DMA) technology
  • Long linear excursion for enhanced output and reduced distortion
  • Vented motor design with marine-grade, stainless steel rear diffuser plate
  • Specifically engineered Centrex polymer baskets are corrosion & UV-resistant
  • Stainless steel mounting hardware included
  • Efficiency: 86.7 dB
  • Xmax: 18.5 mm
  • Mounting Depth: 8.05"
  • Cutout Diameter: 12.0625"
  • Minimum Sealed Enclosure Volume: 2.0 cu ft / 56.6 L (or larger)
  • Optimum Sealed Enclosure Volume: 3.0 cu ft / 70.8 L
  • Infinite Baffle Use: Yes
  • Authorized Internet Dealer
  • 30 Day Sonic Electronix Warranty
JL Audio M12IB6-SG-WH Recommended Power Range
Check out the JL Audio M12IB6-SG-TB Owner's Manual

Subwoofer Wiring Guide


Specifications & Details


Subwoofer Specifications
Subwoofer Size
12"
Peak Power Handling
1200 watts
RMS Power Handling
600 watts
Impedance (Per Voice Coil)
4 ohm
Sensitivity
86.7 dB
Xmax (millimeters)
18.5 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Dark Gray
Woofer Composition
Injection-Molded Mica-Filled Polypropylene
Woofer Surround
Synthetic Rubber
Subwoofer Grille
Yes - Included
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Top-Mount Depth (Mounting Depth)
8.05"
Cutout Diameter
12.0625"
Warranty and Return Policy
Parts Warranty Duration
30 days
Labor Warranty Duration
30 days
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

M12IB6-SG-TB-2

Weight:

23.80lbs

Internal SKU:

ls-m12ib6sgtb-obc

Internal Product ID:

124429
