MTX Audio TR5512-04

12" Single 4 ohm TR55 Thunder Round Series Subwoofer

MTX
Shop all MTX
Product videos
highlight-star-icon

12" Single 4 ohm TR55 Thunder Round Series Subwoofer • 800W Max • 400W RMS • Impedance: Single 4 ohm • Polypropylene cone woofer • Die-cast, stamped aluminum basket

Learn more about the tr551204

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

mtx-551222 thumbnail

MTX 5512-22

OUR PRICE: $189.95

View item

Loading...
43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

Product Highlights


12" Single 4 ohm TR55 Thunder Round Series Subwoofer • 800W Max • 400W RMS • Impedance: Single 4 ohm • Polypropylene cone woofer • Die-cast, stamped aluminum basket

Description


MTX brand icon

Authorized dealer

Thunderous Output

MTX Audio has taken subwoofer design and bass output to the next level with the introduction of MTX’s new thunder round subwoofers. These subs were designed with one goal, to bring the noise! Updating and upgrading the technology found in past MTX Super and High Performance Subwoofers, the TR Series has all the beef and brawn you need to be the loudest ride on the block. Whether you are looking to hit some sick SPL numbers or you want to roll with your favorite tunes, the Thunder Round subwoofers are up to the task.

The TR55 series subwoofers don't hold anything back and also deliver the heaviest beats. These subs have a glossy black metallic paint on the polypropylene dust cap with a raised MTX Audio gothic logo, stitched surround for durability, stamped basket design, and a rubber magnet boot to enhance the look of the subs when reversed mounted.

Authorized MTX Dealer
  • 12" Single 4 ohm TR55 Thunder Round Series Subwoofer
  • Power Handling:
    • Peak: 800 watts
    • RMS: 400 watts
  • Impedance: Single 4 ohm
  • Polypropylene cone woofer
  • Stitched NBR surround
  • Die-cast, stamped aluminum basket
  • 8-gauge nickel compression terminals
  • Rubber magnet boot
  • ALDS (Asymmetrical Linear Drive System)
  • Flat progressive spider
  • Extended pole piece for smooth, linear, piston like drive
  • Exclusive spider plateau venting cooling system
  • 1.75" High temperature single 4 ohm voice coil
  • 70oz. Magnet
  • Frequency response: 29-150 Hz
  • Sensitivity: 87 dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's warranty

Product history:

MTX 5512-22 thumbnail
(newest, current model)
MTX TR5512-04 thumbnail
(previous model, replaced by MTX 5512-22)
MTX T5512-04 thumbnail
(previous model, replaced by MTX Audio TR5512-04)

Subwoofer Wiring Guide


Wiring Guide to Wire 1 MTX Audio TR5512-04 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 MTX Audio TR5512-04 Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 MTX Audio TR5512-04 Subwoofers

4 Channel Amp

Wiring Guide to Wire 4 MTX Audio TR5512-04 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Limited time!
46CSC6934 main

Kicker CSC693 (46CSC6934)

900W Peak (300W RMS) 6x9” CS Series 3 Way Coaxial 4-ohm Speakers with Integrated Midrange Speakers

40
-30.02%

$111.96

List price $159.99

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

SXE-6926S main

Alpine SXE-6926S

280W Peak (90W RMS) 6x9” SXE Series 2-way 4-ohm Coaxial Speakers

13
-20.84%

$56.99

List price $71.99

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Club 620F main

JBL Club 620F (SPKCB620FAM)

330W Peak (110W RMS) 6.5" Club Series 2-way 3-ohm Shallow Mount Coaxial Car Speakers

2
-38.48%

$79.95

List price $129.95


Best selling similar products

Marine Club 12 small

JBL CB122 Club Marine 12

• Peak Power: 1200 watts
• RMS Power: 400 watts
• Polypropylene Cone
• Rubber Surround
• Impedance: Single 4 ohm
• Mount depth: 7-13/16"
• Sensitivity: 89 dB

(1)

$119.95

List price $379.95

VCW124v3 small

NVX VCW124 Version 3 (VCW124v3)

• Peak Power: 2400 watts
• RMS Power: 1200 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 7.02"
• Sensitivity: 85 dB (1W/1m)

(132)

$239.99

List price $287.99

12W6v3-D4 small

JL Audio 12W6v3-D4

• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Mineral-Filled Polypropylene Cone
• Butyl Rubber Surround
• Mount depth: 7.52"
• Sensitivity: 85.4 dB

(25)

$949.99

List price $949.99

Specifications & Details


Subwoofer Specifications
Subwoofer Size
12"
Peak Power Handling
800 watts
RMS Power Handling
400 watts
Voice Coil(s)
Single
Impedance (Per Voice Coil)
4 ohm
Frequency Response
29 - 150 Hz
Sensitivity
87 dB
Xmax (millimeters)
13 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Polypropylene
Woofer Surround
Nitrile Butadiene Rubber NBR
Subwoofer Grille
Optional (Accessory required and sold separately)
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
1.25 cubic feet
Maximum Sealed Box Volume
1.25 cubic feet
Minimum Ported Box Volume
2.0 cubic feet
Maximum Ported Box Volume
2.0 cubic feet
Top-Mount Depth (Mounting Depth)
6-7/8"
Cutout Diameter
11-1/8"
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

MTX

Model Number:

TR5512-04

Weight:

16.00lbs

Internal SKU:

tr551204

Internal Product ID:

13260
