Massive Audio HIPPO XL 84

1400W Max (700W RMS) 8" HIPPO XL Series Dual 4-Ohm Car Subwoofer

highlight-star-icon

• 1400 Watts Max
• 700 Watts RMS
• CEA 2031 Certified
• Kevlar Fiber Reinforced Non-Pressed Paper Cone
• Tall and Narrow Foam Surround
• Dual Impedance High Temp Aluminum 2” Voice Coil Former
• High Energy Double Stack 120oz Strontium Magnet Structure

Learn more about the hippoxl84

We apologize

This item has been discontinued

Description


Massive Audio brand icon

Authorized dealer

Hippo XL 84 is a NEW CEA 2031 Certified Subwoofer and an add-on to the current wildly popular HIPPO series subwoofers. Big Bass with a Big Bottom! The XL84 is Dual 4 Ohm, 700 RMS 1400 Max and uses a high temp 2.5” Aluminum VC, 120oz stacked Strontium Magnets with tight Red stitching that’s sewn through Kevlar Fiber Non-Pressed Paper Cones.

General Features:

  • 8" Dual 4 Ohm HIPPO XL Series Subwoofer
  • Power Handling:
    • Peak: 1400 watts
    • RMS: 700 watts
  • Recommended power range: 500 - 700 RMS
  • CEA 2031 Certified
  • Kevlar Fiber Reinforced Non-Pressed Paper Cone
  • Tall and Narrow Foam Surround
  • Heavy Duty, Rugged Industrial Textured Cast Aluminum Basket
  • High Energy Double Stack 120oz Strontium Magnet Structure
  • Dual Impedance High Temp Aluminum 2.5" Voice Coil Former
  • Red Stitched Edge to the Cone’s Edge for Added Strength
  • Over Sized Mirror Image Dual Poly / Nomex Spiders
  • Black Anodized One Piece Pole-Plate for Added Motor Force
  • Heavy Duty Direct Input Wires Connection to Voice Coils
  • Reinforced Fiberglass Woven Dust Cap
  • Custom Tooled Rubber Gasket and Magnet Boot
  • Top-mount depth: 5.28”
  • Cutout diameter: 7.32”
  • Sensitivity: 83.3dB
  • Resonance Frequency (Fs): 49.96
  • Xmax: 14mm peak to peak
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • Priced Individually

Massive Audio HIPPOXL 84 owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Massive Audio HIPPO XL 84 Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Massive Audio HIPPO XL 84 Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Massive Audio HIPPO XL 84 Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Massive Audio HIPPO XL 84 Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
Hippo XL Series
Subwoofer Size
8"
Peak Power Handling
1400 watts
RMS Power Handling
700 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohms
Voice Coil Diameter
2.5"
Sensitivity
83.3 dB
Xmax (millimeters)
14 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Non-Pressed Paper
Woofer Surround
Foam
Magnet Structure
Double Stacked
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.6 cubic feet
Optimum Sealed Box Volume
1.1 cubic feet
Minimum Ported Box Volume
0.7 cubic feet
Optimum Ported Box Volume
1.2 cubic feet
Top-Mount Depth (Mounting Depth)
5.28"
Cutout Diameter
7.32"
Shallow Mount Installation
No
Electromechanical Parameters
Free-Air Resonance (Fs)
49.96 Hz
Equivalent Compliance (Vas)
3.255 liters
Total Speaker Q Value (Qts)
0.636
Electrical Q Value (Qes)
0.716
Electrical Resistance of Voice Coil (Re)
1.6 ohms
Mechanical Q Value (Qms)
5.687
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

HIPPOXL 84

Weight:

15.43lbs

Internal SKU:

hippoxl84

Internal Product ID:

136925

Customer Ratings & Reviews



5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
5
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

Massive sound!!!

Overly impressed by these subwoofers. I bust a box out of birch to the specs given by massive audio. I have two of these in a dual ported enclosure tuned to about 39HZ. Powered by an alpine Mrx-m240 mono block that is rated at 1500 watts at 4ohms. In comparison to my last enclosure which was two 12" subs in a sealed box, the 8's hit just as hard and have the same frequency response. I showed a couple of people and they all thought I was rocking a set of 12" subs! At this point I am still wearing them in but I will say these are impressive. They take up way less space and perform like 12" subs! I have been in car audio for way over 20 years and have had some pretty insane setups. I went for 8" subs because I wanted some bass but not take up allot of space in my car, and also not shake the hell out of it. These little 8's do shake the hell out of the car to my surprise. My trunk, roof and doors all flex! These subs hit really low also. I won't say they are amazing with frequencies above 90HZ. It could be my enclosure but typically i set my crossover at 80hz and let my midrange speakers do 80 and above. For the size, PRICE, and the performance you get with these, you won't be disappointed!

By Anonymous on September 4, 2018 Checkmark Icon Verified purchase

22

found this helpful.

Grass Taste Bad

These are great. I would say that I love them but what people calls "love" is just a chemical reaction that compels animals to breed. It hits hard, then it slowly fades, leaving you stranded in a failing marriage. The reason you should buy these, if you could, which you can't, would be because you could, which you can't. Running a pair in a 1.48cuft ported box under the back seat of my truck, which that airspace is on the small side but it's still louder than the Hippo's got on the same amp (Massive Audio E3) and the lows are wubba lubba dub dub. And that's the way the news goes.

By Pickle Rick on September 6, 2020 Checkmark Icon Verified purchase

17

found this helpful.

Excellent buy

These subs are an excellent buy for the money alot of bass in this little monster

By Anonymous on May 19, 2019

15

found this helpful.

Slap Happy

I have four of these on 2 Crescendo 1500's. "Pure thunder" very well made
The specs are accurate slightly underrated. Triple spider still breaking in and feels like about 150db's no doubt.
After they finally max ill meter them
But who knows how long that will be.
ONE OF THE BEST SUBS IVE SEEN IN 20 YEARS FOR THE MONEY. SLAPS REAL HARD

By Anonymous on October 17, 2018

16

found this helpful.

Amazing subs

I bought 2 of these without knowing anything about them and all i can say is these are amazing subs for there size!

By BruceBruce on April 12, 2018

12

found this helpful.
