Kicker 44DCWC122 + Mono Amplifier and Amp Kit

Product Details:

• 1200W Max Single 12" Vented Subwoofer Enclosure
• Hard Hitting Ported Box
• Polypropylene cone resist distortion
• Strong Steel Basket provides a reliable base for loud music
• Power Handling:
• Peak: 1200W
• RMS: 600W
• Final Impedance: 2ohm
• Preloaded with two 12" COMPC Subwoofers
• Thick black carpet with yellow Kicker logo embroidered on the top
• Enclosure Dimensions: 14" TD x 17-3/8" BD x 32-3/8" W x 16" H
• Authorized Internet Dealer
• 1-year Sonic Electronix Warranty

Subwoofer Features:

• Injection-molded polypropylene cone
• Ribbed Santoprene surround
• Frequency Response: 20-500 Hz
• Sensitivity: 99.9 dB
• Spring post connector type

Enclosure Features:

• Medium-density fiberboard ensures long-lasting enclosure
• Thick MDF construction
• Thick black carpet finish with embroidered Kicker logo
• Side-port enhances bass performance while maintaining a clear sound
• Enclosure Depth 1: 14"
• Enclosure Depth 2: 17.75"
• Enclosure Height: 16"
• Enclosure Width: 31.875"

Kicker DCWC122 owner’s manual

General Features:

• Boss Riot Series R1100M
• Class-AB FullRange 2-Ohm Stable Monoblock Amplifier
• MAX Power Rating:
• 4 ohm: 550 watts x 1 chan.
• 2 ohm: 1100 watts x 1 chan.
• RMS Power Rating:
• 4 ohm: 413 watts x 1 chan.
• 2 ohm: 825 watts x 1 chan.
• Pulse Width Modulated MOSFET power supply
• Wired remote bass level control included
• LED power (green) and protect (red) indicators
• Soft start turn-on
• Speaker-level (high-level) inputs
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Heavy duty aluminum alloy heat-sink for extreme heat dissipation
• Input sensitivity:
• Low level: 100mV - 2V
• High level: 2V - 8V
• Frequency Response: 9 - 50,000 Hz
• Total Harmonic Distortion (THD): 0.01%
• Signal to Noise Ration: 102 dB
• Selectable crossover modes: Low Pass / Full Range
• Variable low-pass filter: 35 - 160 Hz,/octave
• Selectable Bass Boost: 0 to +18 dB
• Fuse Rating: 30A x 1
• 8 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier. Click Here for our contact information.
• Dimensions: 9.13"W x 10.44"L x 2.25"H
• Authorized Platinum Internet Dealer
• 1 year Sonic Electronix, and 5 years Manufacturer's warranty

Product Details:

• 4 Gauge 2-Channel Complete Amplifier Installation Kit
• Designed for car audio systems up to 1200 watts RMS
• Made from 100% Copper-Clad Aluminum (CCA)
• Satin chromed Mini-ANL fuse holder offers ideal protection for high-powered systems
• Full spec power and speaker wire meet or exceed American Wire Gauge standards
• RCA Interconnect Cable
• Twisted-pair construction provides protection against interference
• Split-tip silver-plated ends offer high-quality performance
• Molded ends equipped with colored channel identifiers for easy recognition
• Includes an assortment of wire termination hardware and cable ties
• Authorized Internet Dealer
• 1-year Manufacturer's Warranty

Kit includes:

1. 17 ft. Gray 4 gauge power wire
2. 3 ft. Black 4 gauge ground wire
3. 17 ft. Gray 18 gauge remote lead wire
4. 20 ft. 16 gauge speaker wire
5. One 17 ft. 2-channel twisted-par construction RCA interconnect Cable
6. One Mini-ANL Fuse Holder with 80 amp Mini-ANL fuse
7. One Black rubber firewall grommet
8. Two 4 Gauge Chrome Plated ring terminals
9. Five 16 Gauge Spade terminal
10. One 18 Gauge Red butt connectors
11. Ten 4" Black zip ties
