JL Audio JD1000/1 (Open Box, Like New)

1000W RMS Class D JD Series Monoblock Car Amplifier

JL Audio
Shop all JL Audio
highlight-star-icon

• 600 watts x 1 channel @ 4 ohm
• 1000 watts x 1 channel @ 2 ohm
• Total RMS Power: 1000 watts
• Class D 2 ohm Stable Monoblock Amplifier

Learn more about the jd10001_obn

We apologize

This item has been discontinued

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)

JL Audio JD1000/1

1000W RMS Class D JD Series Monoblock Car Amplifier
Quantity: 1

Product Details:

  • JD Series Class D 2 ohm Stable Monoblock Amplifier
  • RMS Power Rating:
    • 4 ohm: 600 watts x 1 channel
    • 2 ohm: 1000 watts x 1 channel
  • Total power output: 1000 watts
  • LED Power/Protect Light
  • Optional wired bass remote control (sold separately)
  • Speaker-level (high-level) inputs (Requires adapter like the JL Audio XD-CLRAIC2-SW)
  • Input under/over voltage, over temperature, short protection
  • NextD switching amp technology
  • Differential-balanced inputs help eliminate noise
  • Advanced Rollback Protection System prevents thermal shut-down
  • Input sensitivity:
    • Low level: 0.2 - 2 volts
    • High level: 0.8 - 8 volts
  • Frequency Response: 7 - 500 Hz
  • Total Harmonic Distortion (THD): <1%
  • Signal to Noise Ratio: 80 dB
  • Variable low-pass filter: 50 - 500 Hz
  • Variable Bass Boost: 0 - 12 dB
  • Fuse Rating: 80A (AFS, AGU or MaxiFuse)
  • 4 AWG gauge amplifier wiring kit is recommended for installation
  • Dimensions: 11.40" L x 7.50" W x 2.10" H
  • Authorized Internet Dealer
  • 2 Year Manufacturer's Warranty
  • MFR #: JD1000/1

Specifications & Details


Key Features
Amplifier Key Features
Bass Boost
Speaker Level Inputs
Power Specifications - Subwoofer Channel
RMS Power @ 4 ohms
600 watts x 1 channel
RMS Power @ 3 ohm
1
RMS Power @ 2 ohms
1000 watts x 1 channel
Amplifier Specifications
Series
JD Series
Amplifier Class
D
Number of Channels
1 - Mono
Total RMS Power Output
1000 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
Not Bridgeable
Frequency Response
7 - 500 Hz
THD at Rated RMS Power
<1%
Speaker Level Inputs
Optional (Requires Accessory Adapter)
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
Low-Pass Crossover Frequency
50 - 500 Hz
Signal-to-Noise Ratio
>80 dB
Bass Boost
0 - 12 dB
Remote bass/level controller
Optional (Accessory required and sold separately)
Fuse Rating
80A x 1
Total Fuse Rating
80
Strappable
No
Amp Bluetooth Connectivity
No
Hi-Res Certified
No
Low-Level Input Sensitivity
200mV - 2 volts
High-Level Input Sensitivity
800mV - 8 volts
What is in the box?
Paperwork
User manual
Warranty/Registration card
WITB: Amplifiers
Amplifier
Mounting screws (4)
Washers (4)
Warranty and Return Policy
Parts Warranty Duration
2 years
Labor Warranty Duration
2 years
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

JD10001_OBN

Weight:

8.00lbs

Internal SKU:

jd10001_obn

Internal Product ID:

224112

Customer Ratings & Reviews


JL Audio JD1000/1 (Open Box, Like New) thumbnail image

5 star
91%
4 star
9%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
4.9
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

Excellent quality like you would expect from JL Audio

The following review is for JD1000/1, which is a part of the bundle you are viewing.

I upgraded from the jx 1000/1 to this JD 1000/1 monoblock amp and it is absolutely an upgrade further than what I expected. I expected almost the same product. Between the jx and the JD there are major differences when it comes to sound and signal management. My favorite aspect is the red ring that lights up around the game adjuster when you are getting a clipped signal. No more guesswork involved! This is especially helpful when you are doing the recommended gain adjustment that is given to you in your manual that comes with the amplifier. Personally, I need to keep my gain much lower than the level I could put it up to without getting a clipped signal, although it overloads my door and dash speakers. So in order to get the good sound quality, I must dial it back some so the mix is both hard-hitting but also collaborative. I use this amp to run a JL w3 V3 12-in subwoofer. I used to use it and run them in parallel down to two ohms and I found there is absolutely no need to run 2 of these subwoofers. Just one of them hits plenty hard enough. The amplifier is A cut above any other amplifier I have owned. Including my previous jx1000 version. There are three separate signal detectors. As I stated, there is a red light that comes on when you are getting a clipped signal when your gain is too high. Along with other little regular goodies such as your bass boost that is centered at 45 hz. I find no use in using the bass boost. But to each their own. I have always ran to our audio everything when it comes to speakers amps and subs. And as long as they continue their progress and engineering as they have in the past, I always will. Personally the best deal I could find online was from Sonic electronics.com and I think them for that. I've ordered multiple products from these guys. And most of the reason being is because they are the cheapest I can find, yet they are not just some backdoor slinging company. They are authentic dealers of whatever company they are selling for. Including JL audio.

By Robert L on July 8, 2021 Checkmark Icon Verified purchase

58 found this helpful


The following review is for JD1000/1, which is a part of the bundle you are viewing.
By Eliezer on February 17, 2024 Checkmark Icon Verified purchase

25 found this helpful


JL Audio Amp

The following review is for JD1000/1, which is a part of the bundle you are viewing.

I was impressed with the quick shipping!

By Daniel on June 11, 2024 Checkmark Icon Verified purchase

8 found this helpful


The following review is for JD1000/1, which is a part of the bundle you are viewing.
By Kage on January 7, 2025 Checkmark Icon Verified purchase

2 found this helpful


The following review is for JD1000/1, which is a part of the bundle you are viewing.
By Michael on December 16, 2024 Checkmark Icon Verified purchase

2 found this helpful


Messed up shipping

The following review is for JD1000/1, which is a part of the bundle you are viewing.

I ordered this amp and they said it would be FedEx and they shipped it you USPS I had to order another one like the guy on the phone told me they shipped it out FedEx the next day now they want $29 to send it back when It’s their fault

By Matt on October 22, 2024 Checkmark Icon Verified purchase

2 found this helpful


The following review is for JD1000/1, which is a part of the bundle you are viewing.
By Alfonso on September 28, 2024 Checkmark Icon Verified purchase

2 found this helpful


The following review is for JD1000/1, which is a part of the bundle you are viewing.
By William on March 31, 2026 Checkmark Icon Verified purchase
1996 Ford Ranger

1 found this helpful


The following review is for JD1000/1, which is a part of the bundle you are viewing.
By Damien on April 25, 2025 Checkmark Icon Verified purchase

1 found this helpful


JL Audio

The following review is for JD1000/1, which is a part of the bundle you are viewing.

Installed and works fantastic!

By Julio on January 9, 2025 Checkmark Icon Verified purchase

1 found this helpful
