Product highlights

• 8-Channel Speaker Level Inputs
• 8-Channel RCA Outputs
• Handles up to 40V (400 watts RMS)
• Provides up to 9.5 Volts of output
• Auto turn-on via DC offset or Audio detection
• Load selection switch (20, 60, or 20K ohm)
• Wired remote bass level control included
• LED Clip indicator

Learn more about the xloc88x

Other Toyota Sienna owners bought

Metra 70-1761 Wiring Harness

Install a new car stereo in select 1984-2022 vehicles from Toyota, Subaru, Scion

-14.31%

$5.99

List price $6.99

6x9" Speaker Bracket for select 2002-2024 vehicles from Toyota, Subaru, Lexus

-46.07%

$19.95

List price $36.99

6"-6 3/4" Speaker Adapter for select 2002-2024 vehicles from Toyota, Subaru, Lexus

-44.45%

$24.99

List price $44.99

AXBUCH-TYCAM26V main

Axxess AXBUCH-TYCAM26V

Install a New Car Stereo and Retain Backup Camera in select 2006-2013 vehicles from Toyota

-11.32%

$46.99

List price $52.99

Axxess AXRSEH-T

Install a New Car Stereo and Retain Rear Seat Entertainment (RSE) in select 2003-2014 vehicles from Toyota

-10.01%

$17.99

List price $19.99

HRN-HRR-TO1 main

iDataLink Maestro HRN-HRR-TO1 Wiring harness

Install a New Car Stereo in select 2005-2018 vehicles from Toyota, Scion (Requires ADS-MRR or ADS-MRR2 Module)

-25.38%

$99.99

List price $133.99

Install New Speakers in select 2001-2022 vehicles from Toyota

-13.34%

$12.99

List price $14.99

American International ToyK984

Double DIN Stereo Dash Kit for select 2004-2010 Sienna

-61.79%

$12.99

List price $34.00

Universal 6x9" Waterproof Silicone Rubber Speaker Baffle Ring Kit (Pack of 2)

-42.51%

$22.99

List price $39.99

Limited time!

Kenwood eXcelon DMX809S

6.8” Double DIN Digital Multimedia Touchscreen Bluetooth Receiver with Wireless Apple CarPlay and Android Auto (SiriusXM Ready)

-37.63%

$499.00

List price $800.00

Product Highlights

• 8-Channel Speaker Level Inputs
• 8-Channel RCA Outputs
• Handles up to 40V (400 watts RMS)
• Provides up to 9.5 Volts of output
• Auto turn-on via DC offset or Audio detection
• Load selection switch (20, 60, or 20K ohm)
• Wired remote bass level control included
• LED Clip indicator

Description

Authorized dealer

Line Output Converter

Auto Turn-On

9.5 Volt Output

Bass Boost

8 Channel In 8 Channel Out

Product Features:

Active 8 channel line output converter
8 channels of speaker-level inputs handle up to 40V (400 watts RMS)
8 channels of RCA outputs provide up to 9.5 volts of output
Designed to work with factory audio systems
Auto turn-on via DC offset or Audio Detection
Load selection switch (20, 60, or 20K ohms) to prevent factory stereo shut-down
Adjustable 0 - 12dB Bass Boost (Fixed at 45 Hz)
Selectable 250 Hz full range or low pass filter switch
12 volt turn-on output for aftermarket amplifiers
Selectable Ground Isolation switch to eliminate ground and alternator noise
Molex terminals for speaker signal and power
NVX XLOCXLC wired remote bass level control included
LED clip status indicator
Selectable impedance load: 20, 60, 20k ohm
Frequency response: 10 - 20000 Hz
Signal-to-noise ratio: 110dB
Total harmonic distortion (THD): 0.01%
Dimensions: 5.43" W x 6.40" L x 0.96" H
Authorized Internet Dealer
1-year Manufacturer's Warranty

Frequently Asked Questions (FAQ)

My car has separate wires for tweeters and woofers. How do I get a full signal?

The XLOC88X is designed for this as it can sum multiple input signals together. By tapping both the factory tweeter and woofer wires and feeding them into the LOC, the unit combines them to output a clean, "Full-Range" signal for your aftermarket amp.

I have 4 amps but only 2 factory speaker wires. Can this unit run everything?

Yes. Set the Input Mode to 2CH. This "splits" your single pair of input wires internally to all 8 RCA outputs. It’s the easiest way to power a 4-amplifier setup (Highs, Mids, Rear, and Sub) without a mess of RCA "Y-splitters."

The "Clip" light is flickering on just one channel. How do I fix the output?

Each pair of channels on the XLOC88X has its own Gain Control. If Channel 1/2 is clipping but 3/4 is quiet, turn down the dial for 1/2 specifically. This allows you to "level match" different parts of your car.

What is the best way to wire the 12V power for this 8-channel unit?

Run a dedicated 14-16 gauge power and ground wire directly to your amp’s distribution block to ensure the Blue remote trigger stays strong enough for all your amps.

How do I get 8 channels of output if I only have a few input wires?

Set the Input Mode switch to 2CH, 4CH, or 6CH. This "copies" your available signals across all eight RCA outputs. This is the ultimate solution for running a full active system without using messy RCA "Y-splitters" or damaging your factory wiring.
