DS18 ZXI6.2D

600W Peak (300W RMS) 6.5" ZXI Series Dual 4-ohm High Excursion Subwoofer

DS18
Shop all DS18
highlight-star-icon

• Peak Power: 600 watts
• RMS Power: 300 watts
• Impedance: Dual 2 ohm
• Non-Pressed Paper Cone
• Foam Surround
• Mount depth: 4.41"
• Sensitivity: 87 dB

Learn more about the zxi62d

We apologize

This item has been discontinued


Loading...
Limited time!
DMH-241EX main

Pioneer DMH-241EX

6.2" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth and Built-in Alexa

20
-35.00%

$194.99

List price $300.00

Description


DS18 brand icon

Authorized dealer


ZXI6.2D

The ZXI subline is renowned for its high excursion capabilities, and the ZXI6.2D is no exception. This subwoofer handles wattage as high as 600W while delivering smooth ultra-low frequency responses. The ZXI6.2D’s lower than normal FS (Resonant Frequency), allows it to excel in larger boxes with lower tuning. Whether you prefer sealed or ported boxes, the ZXI6.2D will excel in both, giving you the flexibility to optimize placement in any vehicle.

The ZXI6.2D goes beyond raw power and precision. It features a strong stamped basket adorned with show-quality DS18 logos on the frame, magnet boot, magnet, and dust cap. The quad stacked magnets on the ZXI6.2D offer a multitude of benefits, including increased magnetic field strength, improved power handling, enhanced cone control, higher excursion capabilities, greater durability, and superior heat dissipation. Not only will it impress your ears, but it will also outlast any vehicle. This subwoofer is designed to provide you with crisp and clear bass for years to come.


Product Details:

  • 6.5" Dual 2 ohm ZXI Series Subwoofer
  • Power Handling:
    • Peak: 600 watts
    • RMS: 300 watts
  • Non-Pressed Paper Cone
  • Foam Surround
  • Glossy red aluminum basket
  • Copper clad aluminum winding material
  • PPI dust cap material
  • 1.5" High Temperature Aluminum Voice coil
  • 80 oz. Quad Stacked Ferrite magnet motor structure
  • Frequency Response: 35 - 1800 Hz
  • Resonance Frequency (Fs): 65 Hz
  • Sensitivity: 87 dB
  • Recommended sealed box volume: 0.4 cubic feet
  • Recommended ported box volume: 0.6 cubic feet
  • Top-mount depth: 4.41"
  • Cutout diameter: 5.78"
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

  • Priced Individually

PDF IconDS18 ZXI62D owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 DS18 ZXI6.2D Subwoofer

Mono Amp

Mono Amp - Option 1

2 Channel Amp - Bridged

Wiring Guide to Wire 2 DS18 ZXI6.2D Subwoofers

Mono Amp

2 Channel Amp

4 Channel Amp - Bridged

Wiring Guide to Wire 3 DS18 ZXI6.2D Subwoofers

Mono Amp

Mono Amp - Option 1

4 Channel Amp

Wiring Guide to Wire 4 DS18 ZXI6.2D Subwoofers

2 Channel Amp

4 Channel Amp


Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

BMV62W main

Belva BMV62W

6.2" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto and Phone Mirroring

28
-66.67%

$89.99

List price $269.99

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3
Limited time!
DMH-W3050NEX main

Pioneer DMH-W3050NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay and Android Auto, and Built-in Alexa (Sirius XM Ready)

1
-24.20%

$469.99

List price $620.00

Club 522F main

JBL Club 522F (SPKCB522FAM)

270W Peak (90W RMS) 5.25" Club Series 2 Way Coaxial 3-ohm Speakers

-42.29%

$74.99

List price $129.95

KW-M560BT main

JVC KW-M560BT

6.8" Double-DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto (Sirius XM Ready)

10
Reference 5030cx main

Infinity Reference 5030cx (REF5030CX)

390W Peak (130W RMS) 5.25" Reference Series 2-Way 3-ohm Component Speaker System

2
-60.01%

$99.95

List price $249.95

UTE-73BT main

Alpine UTE-73BT

Single DIN Digital Media Receiver with Bluetooth (SiriusXM Ready)

43
-16.69%

$149.95

List price $180.00


Best selling similar products

SW-UV16.5D4 small

Sundown Audio U-6.5SW D4 6.5" (U65SWD4)

• Peak Power: 1000 watts
• RMS Power: 500 watts
• Impedance: Dual 4 ohm
• Pressed Paper Cone
• Double-Stitched Surround
• Mount depth: 5.71"
• Sensitivity: 78.14 dB

(3)

$199.99

List price $239.99

SW-SA6.5SWD2 small

Sundown Audio SA-6.5 SW D2 6.5" (SA65D2)

• Peak Power: 600 watts
• RMS Power: 300 watts
• Impedance: Dual 2 ohm
• Paper Cone
• Foam Surround
• Mount depth: 3.79"
• Sensitivity: 81.6 dB

$154.99

List price $167.99

SW-SA6.5SWD4 small

Sundown Audio SA-6.5 SW D4 6.5" (SA65D4)

• Peak Power: 600 watts
• RMS Power: 300 watts
• Impedance: Dual 4 ohm
• Paper Cone
• Foam Surround
• Mount depth: 3.79"
• Sensitivity: 81.5 dB

$154.99

List price $167.99

6W3V3-4 small

JL Audio 6W3V3-4

• RMS Power: 150 watts
• Impedance: Single 4 ohm
• Mineral-Filled Polypropylene Cone
• Nitrile Butadiene Rubber NBR Surround
• Mount depth: 4.25"
• Sensitivity: 80.49 dB

(25)

$319.99

List price $319.99

V65DV4 small

Cerwin-Vega V65DV4

• Peak Power: 1500 watts
• RMS Power: 500 watts
• Impedance: Dual 4 ohm
• Carbon Fiber Polypropylene Cone
• Santoprene Rubber Surround
• Mount depth: 4.65"
• Sensitivity: 82 dB

$129.99

List price $155.99

SWS-6.5X small

Earthquake Sound SWS-6.5X

• Peak Power: 200 watts
• RMS Power: 100 watts
• Impedance: Single 4 ohm
• Polypropylene Cone
• Butyl Rubber Surround
• Mount depth: 1-3/4"
• Sensitivity: 77.3 dB

(9)

$119.99

List price $149.00

CWRT672 small

Kicker CWRT672 (48CWRT672)

• Peak Power: 300 watts
• RMS Power: 150 watts
• Impedance: Dual 2 ohm
• UV-Resistant Polypropylene Cone
• UV-resistant Santoprene Surround
• Mount depth: 2-3/4"
• Sensitivity: 82.6 dB

(1)

$103.96

List price $149.99

SUMMO64XL small

Massive Audio SUMMO64XL

• Peak Power: 400 watts
• RMS Power: 200 watts
• Kevlar Fiber-Enforced Non-Pressed Paper cone
• EROM Foam with red stitching surround
• Impedance: Dual 4 ohm
• Mount depth: 4.37"
• Sensitivity: 85 dB

(4)

$104.99

List price $134.99

V65DV2 small

Cerwin-Vega V65DV2

• Peak Power: 1500 watts
• RMS Power: 500 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Polypropylene Cone
• Santoprene Rubber Surround
• Mount depth: 4.65"
• Sensitivity: 80 dB

$129.99

List price $155.99

VMAX65D2 small

Cerwin Vega VMAX65D2

• Peak Power: 400 watts
• RMS Power: 200 watts
• Treated Semi-Pressed Pulped Cone
• Impedance: Dual 2 ohm
• Mount depth: 4.25"

$129.99

List price $155.99

Specifications & Details


Subwoofer Specifications
Series
ZXI Series
Subwoofer Size
6.5"
Peak Power Handling
600 watts
RMS Power Handling
300 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
2 ohm
Voice Coil Material
Aluminum
Voice Coil Diameter
1.5"
Frequency Response
35 - 1800 Hz
Sensitivity
87 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Non-Pressed Paper
Woofer Surround
Foam
Magnet Structure
Quad Stacked
Magnet weight
80 oz.
Magnet Type
Ferrite
Subwoofer Grille
No
Re-Cone Kit Available
No
CTA-2031 Compliant
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.4 cubic feet
Optimum Ported Box Volume
0.6 cubic feet
Top-Mount Depth (Mounting Depth)
4.41"
Cutout Diameter
5.78"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
65 Hz
Equivalent Compliance (Vas)
2.4 liters
Total Speaker Q Value (Qts)
0.942
Electrical Q Value (Qes)
1.121
Electrical Resistance of Voice Coil (Re)
Dual 2.6 ohm
Mechanical Q Value (Qms)
5.919
Efficiency Bandwidth Product (EBP)
57.9
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

ZXI6.2D

Weight:

9.50lbs

Internal SKU:

zxi62d

Internal Product ID:

204649
