JL Audio XDM800/8-24V (XDM800/8)

800W RMS Class D XDM Series 8-Channel Car and Marine Amplifier for 24-Volt Systems

JL Audio
Shop all JL Audio
highlight-star-icon

• 75 watts x 8 channel @ 4 ohm
• 100 watts x 8 channel @ 2 ohm
• Bridged: 200 watts x 4 channel @ 4 ohm
• Total RMS Power: 800 watts
• Class D 2 ohm Stable 8-Channel-Channel Amplifier

Learn more about the xdm800824v

We apologize

This item has been discontinued


Loading...
NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Description


JL Audio brand icon

Authorized dealer


JL Audio XDM800/8-24V (XDM800/8)

With NexD technology, XDM amplifiers achieve total amplifier efficiencies exceeding 80%. This results in reduced energy use, making them much kinder to your electrical system.


Product Details:

  • XDM Series Class D 2 ohm Stable 8-Channel Marine Amplifier
  • Intended for use in 24-volt operations
  • RMS Power Rating:
    • 4 ohm: 75 watts x 8 channel
    • 2 ohm: 100 watts x 8 channel
    • Bridged: 200 watts x 4 channel @ 4 ohm
  • Total power output: 800 watts
  • LED power and protect light
  • 2 pairs of pre-amp outputs
  • Remote level controller JL Audio MHD-RLC (sold separately)
  • Multiple configurations for installation in nearly every location
  • Exclusive input filter for amazing audio on land or sea
  • Efficient design for high output with less energy
  • Full suite of studio-grade signal processing on board
  • Unique design adjusts operation to avoid thermal events
  • NEXD advanced switching technology
  • Studio-grade signal processing
  • All-aluminum, powder-coated housing inhibits corrosion
  • Optional HD-RLC or MHD-RLC remote controls (Sold separately)
  • Input sensitivity: 200 mV - 4 volts
  • Frequency Response: 12 - 22000 Hz
  • Total Harmonic Distortion (THD): 1%
  • Signal to Noise Ratio: 104 dB
  • Variable high-pass filter: 50 - 500 Hz
  • Variable low-pass filter: 50 - 500 Hz
  • Fuse Rating: 40A
  • 4 AWG gauge amplifier wiring kit is recommended for installation
  • Dimensions: 14.73" L x 7.09" W x 2.05" H
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty
  • MFR #: XDM800/6-24V


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

Club 620F main

JBL Club 620F (SPKCB620FAM)

330W Peak (110W RMS) 6.5" Club Series 2-way 3-ohm Shallow Mount Coaxial Car Speakers

2
-38.48%

$79.95

List price $129.95

PH654 main

Cerwin-Vega PH654

600W Peak (300W RMS) 6.5" PRO Series Full Range Coaxial 4-ohm Speakers

2
-16.67%

$189.99

List price $227.99


Best selling similar products

VADM4v2 small

NVX VADM4 v2 (VADM4v2)

• 80 watts x 4 channel @ 4 ohm
• 125 watts x 4 channel @ 2 ohm
• Bridged: 250 watts x 2 channel @ 4 ohm
• Total RMS Power: 500 watts
• Class D 2 ohm Stable 4-Channel Amplifier

(41)

$209.99

List price $239.99

VAD11005v2 small

NVX VAD11005 v2 (VAD11005v2)

• 80 watts x 4 channel + 350 watts x 1 channel @ 4 ohm
• 125 watts x 4 channel + 600 watts x 1 channel @ 2 ohm
• Bridged: 250 watts x 2 channel @ 4 ohm + 600 watts x 1 channel @ 2 ohm
• Total RMS Power: 1100 watts
• Class D 2 ohm Stable 5-Channel Amplifier

(46)

$349.99

List price $419.99

VAD17001v2 small

NVX VAD17001 v2 (VAD17001v2)

• 800 watts x 1 channel @ 4 ohm
• 1350 watts x 1 channel @ 2 ohm
• 1700 watts x 1 channel @ 1 ohm
• Total RMS Power: 1700 watts
• Class D 1 ohm Stable Monoblock Amplifier

(35)

$259.99

List price $335.99

Specifications & Details


Power Specifications - Full Range Channels
RMS Power @ 4 ohms
75 watts x 8 channel
RMS Power @ 2 ohms
100 watts x 8 channel
Bridged RMS Power
200 watts x 4 channel
Amplifier Specifications
Series
XDM Series
Amplifier Class
D
Number of Channels
8-Channel
Total RMS Power Output
800 watts
Maximum Input Gauge Size
4 AWG
Minimum Impedance Unbridged
2 ohm
Minimum Impedance Bridged
4 ohms
Frequency Response
12 - 22000 Hz
THD at Rated RMS Power
1%
Speaker Level Inputs
No
Preamp Outputs
2 pairs
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
High-Pass Crossover Frequency
50 - 500 Hz
Low-Pass Crossover Frequency
50 - 500 Hz
Signal-to-Noise Ratio
104 dB
Remote bass/level controller
No
Total Fuse Rating
40
Strappable
No
Sonic Certified Amplifier
No
Amp Bluetooth Connectivity
No
Hi-Res Certified
No
Low-Level Input Sensitivity
200 mV - 4 volts
What is in the box?
Paperwork
User manual
WITB: Amplifiers
Amplifier
Adhesive brand badge
Allen wrench
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

XDM800/8-24V

Weight:

8.95lbs

Internal SKU:

xdm800824v

Internal Product ID:

219711
