Name: NVX VAD22008 v2 (VAD22008v2)
Brand: NVX
SKU: vad22008v2
Price: 399.99 USD
Availability: InStock
Rating: 5.0000 (2 reviews)

Description

Authorized dealer

Product Details:

Marine Certified V Series Class D 2 ohm Stable 8-Channel Amplifier
RMS Power Rating:

4 ohm: 150 watts x 6 channel + 250 watts x 2 channels
2 ohm: 225 watts x 6 channel + 400 watts x 2 channels
Bridged: 450 watts x 3 channel + 850 watts x 1 channel @ 4 ohm

Total RMS power output: 2200 watts
Conformal Coated Marine Grade Circuit Board
LED Indicators: Power and Protect lights
Platinum-plated Power and Speaker terminals
Includes a Wired Bass Level Remote Control
Balanced differential inputs eliminate noise picked up by signal cables
Speaker-Level (High-Level) Inputs (Requires adapter like the Kicker KISL)
2 or 8 channel selectable input mode
RCA Pre-Amp Outputs
Signal-Sensing Remote Turn-On: Supports Remote, DC Offset, and Audio activation
4-Way Protection Circuitry: Thermal, overload, speaker short, and DC offset protection
Input sensitivity: 0.2 - 18 volts
Frequency Response: 20 - 20000 Hz
Total Harmonic Distortion (THD): <0.3%
Signal to Noise Ratio: >80 dB
Variable high-pass filter: 40 - 400 Hz, 12 dB/octave
Variable low-pass filter: 40 - 400 Hz, 12 dB/octave
Fuse Rating: 220A
4 AWG gauge amplifier wiring kit is recommended for installation
Dimensions: 15.01" L x 6.81" W x 2.05" H
Authorized Internet Dealer
1-year Manufacturer's Warranty
MFR #: VAD22008v2

NVX VAD22008v2 owner’s manual

Frequently Asked Questions (FAQ)

What makes NVX's V-Series amplifiers worth checking out for versatile amplifiers?

NVX V-Series amplifiers provide flexible options for audio enthusiasts. Not only are they built with high power output and great sound quality, but they also cover a wide range of applications, including car, marine and off-road use.

How are NVX V-series amplifiers marine-certified?

V-Series amps are all built with conformal coated PCB boards and heavy-duty aluminum chassis that are weather-certified and marine-rated. It’s the solution for reliable bass in boats or exposed truck beds.

Would the VAD22008v2 work while submersed on water?

Not recommended. While VAD22008v2 has weather-resistant elements, it is not great to use this while exposed with water. While not submersible, it handles the splashes and humidity common in off-road and marine use.

Why is there a "x10" switch for the VAD22008v2's high-pass and low-pass filters?

VAD22008v2 has an option for "x1" and "x10" for its crossover filters. The "x10" switch is for bandpass filtering. This is the solution for active systems, letting you filter both lows and highs for a dedicated mid-range driver without an external DSP.

Why are the terminals of VAD22008v2 platinum-plated?

NVX has the marine-readiness in mind with the V-series amps, and platinum-plated terminals ensure corrosion resistance. Platinum doesn't oxidize like gold or copper, ensuring a perfect connection even in salt-air environments.

Why is there an input mode switch? When should I use the 2-channel and 8-channel switch options?

The switch provides you with flexible options on how to use your VAD22008v2. Use the 8-channel switch to cover all speaker inputs, or the 2-channel for bridged connections that would also provide bigger power for your speakers.

Will it fit in my SUV's rear storage panel?

Absolutely. Believe it or not, VAD22008v2 is surprisingly slim for an 8-channel with its 15" length. This would let you tuck a complete system into one hidden location.

Can I run a 4-way active setup with the VAD22008v2?

Yes. You can connect pairs of tweeters, midrange, midbass and a subwoofer that would cover all frequencies. This will give you total control over every driver in your vehicle.

I noticed the 'clipping' LED indicator of the VAD22008v2 turned on for quite some time now. Is it normal?

It should never stay on. If it's solid, you're frying your voice coils with distortion. The clipping indicator should only turn on during a square wave signal that could destroy your drivers.

How does the VAD22008v2 stop the burning smell from my speakers?

Check your crossover filters. Clipping causes heat. Use the filter to cut out frequencies your box can't play. You might also want to check your speakers if they're toasted and needs a replacement.
