Boss P156DVC

2500W Peak (1250W RMS) 15" Phantom Series Dual 4 Ohm Subwoofer

Boss
Shop all Boss
Product videos
highlight-star-icon

• 2500W Peak
• 1500W RMS
• 2-1/2" High Temperature Kapton Voice Coil
• Dual 4 Ohm
• Red Stitching
• Designed for Ported and Sealed Enclosures
• Frequency Response: 25-1,000 Hz

Learn more about the p156dvc

We apologize

This item has been discontinued


Loading...
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

MPK 163.3 main

Hertz MPK163.3

600W Peak (300W RMS) 6.5" Mille PRO Series 3-way 4-ohm Component Speaker System

2
-14.89%

$999.99

List price $1175.00

PNW-65CS2 main

AudioControl PNW-65CS2

250W Peak (200W RMS) 6.5″ PNW Series 2 Way Component 3-ohm Speakers

4
-5.90%

$319.00

List price $339.00

NSP65 main

NVX NSP65

540W Peak (180W RMS) 6.5" N-Series 2 Way Coaxial Car Speakers

93
-35.19%

$69.99

List price $107.99

XED62 main

Cerwin-Vega XED62

600W Peak (70W RMS) 6.5" XED Series 2-Way Coaxial 4-ohm Speakers

15
-16.67%

$49.99

List price $59.99

PH654 main

Cerwin-Vega PH654

600W Peak (300W RMS) 6.5" PRO Series Full Range Coaxial 4-ohm Speakers

2
-16.67%

$189.99

List price $227.99

T2652-S main

Rockford Fosgate Power T2 T2652-S

400W Peak (200W RMS) 6.5" Power Series 2 Way Component 4-ohm Speaker System

42

Product Highlights


• 2500W Peak
• 1500W RMS
• 2-1/2" High Temperature Kapton Voice Coil
• Dual 4 Ohm
• Red Stitching
• Designed for Ported and Sealed Enclosures
• Frequency Response: 25-1,000 Hz

Description


Boss brand icon

Authorized dealer

General Features:

  • 15" Dual 4 Ohm Phantom Series Subwoofer
  • Power Handling:
    • Peak: 2500 watts
    • RMS: 1500 watts
  • Impedance: Dual 4 ohm
  • Black metallic injection-molded polypropylene cone
  • Butyl rubber surround
  • Red woofer stitching enhances durability
  • Spring-loaded binding posts
  • Mounting Depth: 7-1/8"
  • 2-1/2" High temperature Kapton voice coil
  • Large magnet with protective cover
  • Designed for use in sealed and ported enclosures
  • Frequency response: 25-1,000 Hz
  • Sensitivity: 96dB
  • Authorized Platinum Internet Dealer
  • 1 year Sonic Electronix, and 2 years Manufacturer's warranty

Priced Individually

Boss P156DVC owner’s manual

Subwoofer Wiring Guide


Wiring Guide to Wire 1 Boss P156DVC Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 Boss P156DVC Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 Boss P156DVC Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 Boss P156DVC Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp


Best selling similar products

DB-SA305 D1 small

Deaf Bonce Apocalypse DB-SA305 D1

• Peak Power: 4000 watts
• RMS Power: 2000 watts
• Pressed Paper Cone
• Foam Surround
• Impedance: Dual 1 ohm
• Mount depth: 7.85"
• Sensitivity: 88.30 dB

(1)

$399.90

List price $399.90

DB-SA255 D2 small

Deaf Bonce Apocalypse DB-SA255 D2

• Peak Power: 2000 watts
• RMS Power: 1000 watts
• Pressed Paper Cone
• Foam Surround
• Impedance: Dual 2 ohm
• Mount depth: 7.4"
• Sensitivity: 87.50 dB

(1)

$259.90

List price $259.90

VCW152v3 small

NVX VCW152 Version 3 (VCW152v3)

• Peak Power: 3000 watts
• RMS Power: 1500 watts
• Impedance: Dual 2 ohm
• Carbon Fiber Enhanced Non-Pressed Paper Cone
• Custom High Roll Foam Surround with black nylon stitching
• Mount depth: 8.19"
• Sensitivity: 88 dB (1W/1m)

(39)

$259.99

List price $311.99

Specifications & Details


Subwoofer Specifications
Series
Phantom Series
Subwoofer Size
15"
Peak Power Handling
2500 watts
RMS Power Handling
1500 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Frequency Response
25 - 1,000 Hz
Sensitivity
96 dB
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Injection Molded Polypropylene
Woofer Surround
Butyl Rubber
Magnet Type
Ferrite
Subwoofer Grille
No
Re-Cone Kit Available
No
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Minimum Sealed Box Volume
0.8 cubic feet
Optimum Sealed Box Volume
0.8 cubic feet
Maximum Sealed Box Volume
0.8 cubic feet
Minimum Ported Box Volume
1.2 cubic feet
Optimum Ported Box Volume
1.2 cubic feet
Maximum Ported Box Volume
1.2 cubic feet
Shallow Mount Installation
No
Warranty and Return Policy
Parts Warranty Duration
3 years
Labor Warranty Duration
3 years
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

P156DVC

Weight:

20.00lbs

Internal SKU:

p156dvc

Internal Product ID:

24661

Product and How-to Videos


Customer Ratings & Reviews


Boss P156DVC thumbnail image

5 star
45%
4 star
18%
3 star
20%
2 star
4%
1 star
13%



Durability
3.9
Value
4.4
Features
4
Design
4.4
Usability
4.4

Customer Reviews

Sort by:

Loading...

Very Good Sub

This sub is a great purchase for the price. Not only does this sub produce good bass frequencies it also is a good competitor. From what I've seen it has a pretty big damn magnet and the cone and stitching are both made of durable material. If you wire this sub up correctly or get an audio retailer to do it you sure to not go wrong. Most people who complain on this site about there subs shorting out or quitting is because they were installed improperly. I've his 154 on the db with 2 of these in a custom box.

By Clark on February 7, 2011

84 found this helpful


BoSs PhAnToM

This sub is cheap and hits hard lol i own 2 and im really impressed

By Juan on April 4, 2011

78 found this helpful


do not go by power rating!

i ordered these subwoofers about 6 months ago, they are supposed to hold 1500 rms and 2500 peak watts. i have two of them in a box, they were professionally installed correct wiring capacitor the whole nine yards. i have a 1200 watt rockford fosgate prime series amp, the amp was turned ALL the way down as far as possible. its been about 6 months give or take so they were broke in, once again amp turned down as much as possible. i was driving yesterday with the song mercy playing. i started smelling that smell like no other lol looked in back mirror and the whole back of my suv was filling with smoke. got home took subs out and they were 100% MELTED. sounded decent just WONT HOLD ADVERTISED POWER. atleast not true pwer. thanks.

By forrest on May 18, 2014

73 found this helpful


Great deal

I would recommond these for cheap good speakers there not the best but they do hit pretty hard for being so cheap i would buy these again if i had to!

By 2 real for fake poeple on January 13, 2014

71 found this helpful


Bad

I went and bought 2 of them and the voice coil started smoking. I do not recommend anyone to buy these subs

By David on March 8, 2013

69 found this helpful


Boss

Works great haven't had a problem with it. Has good bass more than I expected for the price.

By skyler on June 27, 2011

67 found this helpful


really surprised

I am really surprised how good these speakers sound especially because I had two 15" kicker comp vr's and blew them. I bought the boss phantoms because of the price and I am surprised they sound the same as my vr's did. I would recommend these to anyone looking to beat.

By Damian on January 6, 2013

67 found this helpful


Suprised Definately love it

I had never heard of boss before buying this. i'd always heard about kewwood jvc kicker etc but i saw these and figured i'd give it a shot,

amazing sub, hit really hard although it did end up blowing after 3 weeks cuz im an idiot...

don't push a 4000w on a 2500w sub ;) bad move there. none the less ordered another one because this sub is amazing!

my only advice is when getting a new sub follow the setup instructions to a t. make sure your grounds posi's leads and everything are 100% perfect don't half ass it you will regret it later (nearly had a car fire) and seeing as it's new equiptment make sure u kinda break it in. get like 10 hours on it just smooth light to medium bass before beating the hell out of it

By grayson on November 10, 2012

68 found this helpful


Great Sub & Design

I purchased this sub 2 weeks ago along with the boss 2-channel 3000 watt amp and they fit together perfect everything has been working great so far it produces good bass frequencies and I'm very impressed so far. If you hook everything up correctly or recommended im sure this sub will last a LONG time. I'd recommend a ported enclosure instead of a sealed enclosure also. For the price this sub is top of the line!

By Brandon on February 7, 2011

68 found this helpful


good

This product is a good buy n sounds really nice

By dean on October 21, 2014

64 found this helpful
