Rockford Fosgate P1L-2X12 (09P1L-2X12)

Dual 12" P1 Series Loaded Punch Enclosure

Rockford Fosgate
Shop all Rockford Fosgate
Product videos
highlight-star-icon

12" P1 Series Dual Loaded Vented Punch Enclosure • 600W Peak • 300W RMS • Wired in Parallel Internally • Computer Optimized Design • Constructed with 5/8" MDF • High Current AWG binding Posts • Covered with Industrial Grade Carpet

Learn more about the 09p1l2x12

Good news and a little bad...

This item has been discontinued

But you may be interested in the newest model that's available.

p12x12 thumbnail

Rockford Fosgate Punch P1-2X12

OUR PRICE: $409.99

View item

Product Highlights


12" P1 Series Dual Loaded Vented Punch Enclosure • 600W Peak • 300W RMS • Wired in Parallel Internally • Computer Optimized Design • Constructed with 5/8" MDF • High Current AWG binding Posts • Covered with Industrial Grade Carpet

Description


Rockford Fosgate brand icon

Authorized dealer

Subwoofer Features:
  • 12" Single 8 Ohm Punch Series Stage 1 Subwoofer
  • RMS Power Rating (per woofer):
    • Peak: 300 watts
    • RMS: 150 watts
  • Impedance: Single 8 ohm
  • Thermoformed Polypropylene Cone
  • Poly-foam Surround
  • Custom 10-AWG nickel plated push terminals
  • Linear spider with embedded 16 AWG tinsel leads
  • Protective PVC textured magnet cover
  • Reversable ABS trim ring
  • Parabolic injection molded ABS/Acrylic dustcap
  • 1.5" 6-Layer high-temp 8 ohm voice coil with spun-laced Nomex® reinforced collar
  • 40oz. magnet
  • Frequency response: 24-250 Hz
  • Sensitivity: 87 dB
  • 1-year SonicElectronix.com warranty
General Enclosure Features:
  • 12" P1 Series Dual Loaded Vented Punch Enclosure
  • RMS Power Rating (woofers combined):
    • Peak: 600 watts
    • RMS: 300 watts
  • Wired in parallel internally
  • Final impedance of 4 ohms at the terminals
  • Computer optimized design
  • Covered with industrial grade carpet
  • High current AWG binding posts
  • Proprietary high-flow, low-noise port
  • Wired exclusively with Rockford Fosgate speaker cable
  • Subwoofer mounting depth: 5-7/8"
  • Subwoofer cutout diameter: 11-1/8"
  • 5/8" MDF (Medium Density Fiberboard) enclosure material
  • Dimensions: 16-3/8"D x 33-7/8"W x 15-1/8"H

Product history:

Rockford Fosgate P1-2X12 thumbnail
(newest, current model)
Rockford Fosgate P1L-2X12 thumbnail
(previous model, replaced by Rockford Fosgate Punch P1-2X12)

Specifications & Details


Subwoofer Specifications
Subwoofer Size
12"
RMS Power Handling
150 watts
Peak Power Handling
300 watts
Woofer Composition
Thermoformed Polypropylene
Woofer Surround
Poly-Foam
Sensitivity
86 dB
Frequency Response
26 - 250 Hz
Enclosure Specifications
Box Type
Ported
Number of Subwoofers
2
Box Style/Shape
Square/Rectangle
Wood Thickness
5/8"
Number of Terminals
1
Terminal Type
Binding posts
Box Exterior Color
Black
Box Finish
Carpet
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Sonic Electronix

Item Details


Manufacturer:

Model Number:

P1L-2X12

Weight:

62.70lbs

Internal SKU:

09p1l2x12

Internal Product ID:

28004
