Audiopipe APMB-6SB , Open Box (Very Good, Used)

250W 6" APMB Series Loudspeaker w/ Sealed Back

Audiopipe
Shop all Audiopipe
highlight-star-icon

• Item Condition: Open Box, Very Good, Used
• Peak Power: 250W • RMS Power: 125W
• Low Mid Frequency
• Mounting Depth: 2-3/8"
• 20 Oz. Magnet
• Sealed Back Design
• Sensitivity: 99dB

Learn more about the LS-apmb6sb-OBC6

We apologize

This item has been discontinued

Description


Audiopipe brand icon

Authorized dealer

Item Condition - Open Box, Great:

This product works like new, is well-cared-for and in great condition. May show limited signs of wear or use and may be missing non-essential parts, accessories or original packaging.



Pro Audio Quality in Your Car

The Audiopipe APMB series speakers were designed to produce pro audio quality sound in your car. These outstanding speakers thoughtfully engineered to handle significant amounts of amplified power, resulting in clean, crisp sound reproduction. Ideal for virtually any application, the APMB series is meant to let you take your music with you and show off your system in any kind of environment and each speaker in the series has it's own unique purpose. Hear more than just bass with the APMB series pro audio speakers!

Phase Plug for Sound Quality Incorporated Phase Plugs Provide Better Sound

Audiopipe designed the 6SB speaker with an incorporated phase plug to provide quality high frequency response. The phase plug equalizes sound wave lengths which prevents the sound waves from colliding. Sound wave collisions can cause cancellations and frequency response problems, resulting in greatly reduced overall sound quality.

Sealed Basket Design Sealed Basket Limits Cone Movement and Improves Speaker Life

The Audiopipe 6SB sealed back design speaker limits the cone movement by utilizing a basket design that encloses the rear of the speaker entirely. As a result of the minimal movement within, sealed back speakers are incredibly durable, very difficult to damage speakers, ensuring use for years to come.

Light and Strong Durable Audiopipe Paper Cones

Despite all of the advances in audio technology, a quality paper cone is still tough to beat, and Audiopipe's 6SB speaker features a light weight yet incredibly stiff pressed paper cone. These cones deliver outstanding linear movement and when combined with the out-of-this world power handling of the APMB series, you will hear some of the best sound reproduction possible.


Item Condition - Open Box, Very Good Condition:
A Very Good Open Box used product represents a well-cared-for product that has seen only brief installation and/or limited use, but remains in great condition. The item is complete, unmarked, and undamaged, but may show some limited signs of wear. Original packaging, paperwork or protective wrapping may be missing or slightly damaged from the item being opened. Product works perfectly. Warranty details are included in the item description or comments.

General Features:

  • 6" APMB Series Sealed Back Midrange Driver
  • Power Handling:
    • Peak: 250 watts
    • RMS: 125 watts
  • Low mid frequency loudspeaker
  • Loudspeaker design provides pro audio quality sound in your car
  • Bullet dust cap ensures high quality high frequency sound
  • Pressed paper cone
  • Corrugated surround
  • Sealed basket design for improved speaker life
  • Heavy duty 20 oz. magnet
  • Durable 1.5" TIL voice coil
  • 8 ohm impedance
  • Frequency Response: 350-5,000 Hz
  • Top-mount Depth: 2-3/8"
  • Mounting Diameter: 5-11/16"
  • Sensitivity: 99dB
  • Authorized Internet Dealer
  • 1-year Manufacturer's Warranty

Specifications:

  • FS (Free Air Resonance): 470 Hz
  • RE (DC Resistance): 7.4 ohm
  • Le (Voice Coil Inductance): 0.18 mH
  • QMS (Mechanical Q Value): 2.05
  • QES (Electrical Q Value): 1.76
  • QTS (Total Speaker Q Value): 1.0
  • VAS (Equivalent Compliance): 0.3 L (0.011 cu ft.)
  • Xmax (One-Way Linear Excursion): 0.2 mm (0.008")
  • F3 (for Sealed Enclosure):
    • 0.35 cu ft.: 492 Hz
    • 0.45 cu ft.: 476 Hz
  • F3 (for Vented Enclosure):
    • 0.4 cu ft.: 460 Hz

Priced Per Speaker

Specifications & Details


Speaker Specifications
Series
APMB Series
Priced Per
Each Speaker
Speaker Size
6"
Design
Mid-range
Woofer Composition
Pressed Pulp Fiber
Woofer Surround
Corrugated
Peak Power Handling
250 watts
RMS Power Handling
125 watts
Sensitivity
99 dB
Frequency Response
350 - 5000 Hz
Impedance (Per Voice Coil)
8 ohm
Top-Mount Depth (Mounting Depth)
2-3/8"
Cutout Dimensions
5-11/16"
General specifications
Speaker Grilles
No
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

APMB-6SB-2

Weight:

4.40lbs

Internal SKU:

LS-apmb6sb-OBC6

Internal Product ID:

135937
