Pioneer GM-5400T R/B

Refurbished 760W Max, 2-Channel GM Series Car Amplifier w/ High-Level Speaker Inputs

Pioneer
Shop all Pioneer
Product videos
highlight-star-icon

GM Series 2-Channel Car Amplifier • 125W x 2 Chan. @ 4 Ohm • 190W x 2 Chan. @ 2 Ohm • 380W x 1 Chan. Bridged • 760 Watts Max • Selectable Bass Boost • Speaker-Level Inputs • Selectable Low-Pass Filter

Learn more about the LS-gm5400t-RB

We apologize

This item has been discontinued

NVX - Worth the Envy - Direct to Consumer Car Audio

Loading...
Limited time!
KFC-1666S main

Kenwood KFC-1666S

600W Peak (60W RMS) 6.5" Sport Series 2 Way Coaxial 4-ohm Car Speakers

51
-38.75%

$49.00

List price $80.00

Limited time!
TS-G1620F main

Pioneer TS-G1620F

600W Peak (80W RMS) 6.5" G-Series 2-Way Coaxial 4-ohm Car Speakers

13
-26.15%

$48.00

List price $65.00

PRO-X6BM main

DS18 PRO-X6BM (Sold Individually)

500W Peak (250W RMS) 6.5” PRO-X Series Pro Audio Mid-range 8-ohm Loudspeaker

1

Product Highlights


GM Series 2-Channel Car Amplifier • 125W x 2 Chan. @ 4 Ohm • 190W x 2 Chan. @ 2 Ohm • 380W x 1 Chan. Bridged • 760 Watts Max • Selectable Bass Boost • Speaker-Level Inputs • Selectable Low-Pass Filter

Description


Pioneer brand icon

Authorized dealer

Only Accept the Best

Make sure that your system is working to it's full potential with the GM series amplifiers from Pioneer. Using the latest Pioneer technology, the GM-5400T will give your system the boost that it needs to be the best. Amplifiers increase the systems sound and frequency, resulting in a overall higher sound quality. With the GM-5400T from Pioneer, you can count on superior quality and a name that you can trust.

Product Features:
  • GM Series 2-Channel Class AB Car Amplifier
  • Item Condition: Refurbished
  • RMS Power Rating:
    • 4 ohm: 125 watts x 2 chan.
    • 2 ohm: 190 watts x 2 chan.
    • Bridged, 4 ohm: 380 watts x 1 chan.
  • Max power output: 760 watts x 1 chan.
  • MOSFET power supply
  • Selectable bass boost (0, 6, 12 dB at 50 Hz)
  • Hi-volt input level control (400mV ~ 6.5V)
  • 2/1 Channel operation
  • 2-Channel speaker-level inputs
  • Balanced Isolator Input Circuit
  • 2-Channel RCA inputs
  • Heavy duty heatsink and a sub-heatsink for maximum heat dissipation
  • RCA level inputs
  • Screw terminals
  • Selectable low-pass filter
  • CEA-2006 compliant amplifier
  • Frequency response: 10-50,000 Hz
  • Dimensions: 10-1/2"D x 13-5/8"W x 2-1/2"H
  • 4-gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits when purchased together with this amplifier.
  • 90 Day SonicElectronix.com warranty
