Product Highlights


15 Band Graphic Equalizer with 3-Way Crossover • Brushed Aluminum Finish • +-12dB EQ Boost / Cut • PWM Switching Power Supply • Removable Aluminum Handles

Description


MA Audio brand icon

Authorized dealer

  • 15 Band Graphic Equalizer with 3-Way Crossover
  • Brushed Aluminum Finish
  • Flush Mount Panel
  • Removable Aluminum Handles
  • PWM Switching Power Supply
  • Power and Clip LED Indicator
  • +-12dB EQ Boost / Cut
  • Subwoofer Control:
    • Variable Input Gain Control
    • Variable Crossover Frequency: 45 - 500 Hz
    • Mode Switch (Subwoofer / Full)
    • 0 - 12 dB Variable Bass Boost
    • 25 - 250 Hz Variable Bass Frequency
    • 0° - 180° Phase Control
  • Mid-Range Controls:
    • Variable Input Gain Control
    • Mode Switch (LPF / Full)
    • 45 Hz - 1.6 kHz Variable Crossover Frequency
    • Variable Equalizer Frequency Range: 32, 63, 100, 180, 250, 400, 650, 1k, 1.6k, 2.5k, 4k, 6.4k,10k, 14k, 18.
  • Tweeter Controls:
    • Variable Input Gain Control
    • Mode Switch (HPF / Full)
    • Frequency Multiplier Switch (x1, x10)
    • 50 Hz - 5 kHz Variable Crossover Frequency
    • Variable Equalizer Frequency Range: 32, 63, 100, 180, 250, 400, 650, 1k, 1.6k, 2.5k, 4k, 6.4k,10k, 14k, 18.
  • Dimensions: 13" L x 8-3/4" W x 2" H
  • 1-year Manufacturer's warranty

Loading...
BV850ACP main

Boss Elite BV850ACP

6.75" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto with Backup Camera

5
Limited time!
46CSC654 main

Kicker CSC65 (46CSC654)

600W Peak (200W RMS) 6.5” CS Series 2 Way Coaxial 4-ohm Speakers

122
-33.36%

$79.96

List price $119.99

DMH-1800NEX main

Pioneer DMH-1800NEX

6.8" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay, Android Auto, and SiriusXM Ready

2
-16.67%

$349.99

List price $420.00

iLX-W650 main

Alpine iLX-W650

7" Double DIN Touchscreen Digital Multimedia Receiver with Bluetooth, Apple CarPlay and Android Auto (SiriusXM Ready)

123
-5.72%

$329.95

List price $349.95

Club 322F main

JBL Club 322F (SPKCB322FAM)

150W Peak (50W RMS) 3.5" Club Series 2 Way Coaxial 3-ohm Speakers

1
-27.29%

$79.95

List price $109.95

DMH-W4660NEX main

Pioneer DMH-W4660NEX

6.8" Double DIN Digital Multimedia Receiver with Bluetooth, Wireless Apple CarPlay, and Android Auto (SiriusXM Ready)

2
-20.00%

$599.99

List price $750.00

43DSC6504 main

Kicker DSC650 (43DSC6504)

480W Peak (120W RMS) 6.5” DS Series 2-way 4-ohm Coaxial Car Speakers (DSC6504)

28
-10.53%

$84.99

List price $94.99

DB652 main

Polk Audio DB652 (DB 652)

600W Peak (200W RMS) 6.5" DB+ Series 2 Way Coaxial 4-ohm Car, Marine and Powersports Speakers

12
-9.16%

$109.00

List price $119.99

Limited time!
Club 622 main

JBL Club 622

360W Peak (120W RMS) 6.5" Club Series 2-way Coaxial 3-ohm Speakers

5
-28.58%

$99.95

List price $139.95

CV15BT main

Cerwin-Vega CV15BT

Single Din Digital Media Receiver with Bluetooth

3

Best selling similar products

XEQ7 small

NVX XEQ7

• 7 band-Band Graphic Equalizer
• 3 Sets of preamp outputs (front, rear and subwoofer)
• 7 volts Max preamp outputs
• Subwoofer frequency and level control
• Gold-plated RCA level inputs

(51)

$49.99

List price $89.99

EQX7PRO small

DS18 EQX7PRO

• 7 band-Band Graphic Equalizer
• 3 Sets of preamp outputs (front, rear, and subwoofer)
• 8 volts Max preamp outputs
• Subwoofer frequency and level control
• Gold-plated RCA level inputs

$119.95

List price $143.99

HFEQ-2 small

Hifonics HFEQ-2

• 4 band-Band Equalizer
• 3 sets of preamp outputs (front, rear and subwoofer)
• 9 volts max preamp outputs
• Subwoofer frequency and level control
• Gold-plated RCA level inputs

(1)

$59.99

List price $99.99

EQL7 small

Memphis EQL7

• 7 band-Band Parametric Equalizer
• 3 sets of preamp outputs (front, rear and subwoofer)
• 8 volts max preamp outputs
• Subwoofer frequency and level control

(1)

$99.99

List price $159.95

EQ-4000BT v2 small

Earthquake Sound EQ-4000BT v2

• 4 band-Band Parametric Equalizer
• 3 sets of preamp outputs (front, rear and subwoofer)
• 9 volts max preamp outputs
• Subwoofer frequency and level control
• Gold-plated RCA level inputs

$179.99

List price $199.99

EQP850 small

Cerwin-Vega EQP850

• 5-Band Parametric Equalizer
• 3 sets of preamp outputs (front, rear and subwoofer)
• 9 volts max preamp outputs
• Subwoofer frequency and level control
• Nickel-plated RCA level inputs

$139.99

List price $139.99

EQ-770 small

Cerwin-Vega EQ-770

• 7 band-Band Parametric Equalizer
• 3 sets of preamp outputs (front, rear and subwoofer)
• 7 volts max preamp outputs
• Subwoofer frequency and level control

(2)

$99.99

List price $115.99

EQX7 small

DS18 EQX7

• 7 band-Band Graphic Equalizer
• 3 Sets of preamp outputs (front, rear and subwoofer)
• 8 volts Max preamp outputs
• Subwoofer frequency and level control
• Gold-plated RCA level inputs

$95.95

List price $95.95

eqx5 small

DS18 EQX5

• 5 band-Band Graphic Equalizer
• 3 Sets of preamp outputs (front, rear and subwoofer)
• 8 volts Max preamp outputs
• Subwoofer frequency and level control
• Gold-plated RCA level inputs

(1)

$65.95

List price $65.95

Specifications & Details


Crossover Specifications
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
Equalizer Frequencies
32 - 14,000 Hz
Signal Boost/Cut
12 dB
Width
8-3/4"
Height
2"
Depth
13"
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

MA15EQX

Weight:

7.00lbs

Internal SKU:

ma15eqx

Internal Product ID:

5835
