JL Audio 10W6v3-D4 (Open Box, Like New)

600W RMS 10" W6v3 Series Dual 4-ohm Car Subwoofer

JL Audio
Shop all JL Audio
highlight-star-icon

• RMS Power: 600 watts
• Impedance: Dual 4 ohm
• Mineral-Filled Polypropylene Cone
• Rubber Surround
• Mount depth: 6.89"
• Sensitivity: 82.7 dB

Learn more about the 10w6v3d4_obn

We apologize

This item has been discontinued

Description


JL Audio brand icon

Authorized dealer

Item Condition - Like New (Open Box):

This product works and looks like new. It may have been opened for a visual demo or product video. In some cases there may be signs of an attempt at installation like opened packaging or mounting screw holes used, but there is no real sign of use or wear. Includes all original parts, packaging and accessories (or suitable replacement)


JL Audio 10W6v3-D4

If you are seeking to reproduce the highest quality sub-bass in a very compact enclosure application, the 10W6v3 is the ultimate choice. This advanced Subwoofer offers several technologies shared with the flagship W7AE subwoofers to provide powerful advantages in motor linearity and suspension behavior. These combine with a very efficient cooling circuit to deliver reduced distortion and outstanding dynamic balance. The 10W6v3 is best used with amplifier power in the 200W - 600W range and is optimized to operate in a sealed enclosure with only 0.55 cu. ft. (15.6 liters) of air space, or a 0.75 cu. ft. (21.2 liters) ported enclosure.


JL Audio 10W6v3-D4

600W RMS 10" W6v3 Series Dual 4-ohm Car Subwoofer
Quantity: 1

Product Details:

  • 10" Dual 4 ohm W6 v3 Series Subwoofer
  • Power Handling:
    • RMS: 600 watts
  • Mineral-Filled Polypropylene Cone
  • Rubber Surround
  • Equipped with cooling circuit
  • 19 mm Xmax
  • Double Stacked magnet motor structure
  • Resonance Frequency (Fs): 30.12 Hz
  • Sensitivity: 82.7 dB
  • Recommended sealed box volume: 0.55 cubic feet
  • Recommended port box volume: 0.75 cubic feet
  • Top-mount depth: 6.89"
  • Cutout diameter: 9.02"
  • Authorized Internet Dealer
  • JL Audio SGR-10W6v2/v3 optional protective subwoofer grille (sold separately)
  • 1-year Manufacturer's Warranty

  • Priced Individually

Subwoofer Wiring Guide


Wiring Guide to Wire 1 JL Audio 10W6v3-D4 (Open Box, Like New) Subwoofer

Mono Amp

2 Channel Amp - Bridged

Wiring Guide to Wire 2 JL Audio 10W6v3-D4 (Open Box, Like New) Subwoofers

Mono Amp

Mono Amp - Option 1

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp - Bridged

Wiring Guide to Wire 3 JL Audio 10W6v3-D4 (Open Box, Like New) Subwoofers

Mono Amp

4 Channel Amp

Wiring Guide to Wire 4 JL Audio 10W6v3-D4 (Open Box, Like New) Subwoofers

Mono Amp

2 Channel Amp

2 Channel Amp - Bridged

4 Channel Amp

Specifications & Details


Subwoofer Specifications
Series
W6 v3 Series
Subwoofer Size
10"
RMS Power Handling
600 watts
Voice Coil(s)
Dual
Impedance (Per Voice Coil)
4 ohm
Sensitivity
82.7 dB
Xmax (millimeters)
19 mm
Subwoofer Design
Round / Circle
Main Cone Color
Black
Woofer Composition
Mineral-Filled Polypropylene
Woofer Surround
Rubber
Magnet Structure
Double Stacked
Subwoofer Grille
Optional (Accessory required and sold separately)
Recommended Enclosure Specifications
Recommended Enclosure Type
Ported / Vented
Sealed
Optimum Sealed Box Volume
0.55 cubic feet
Optimum Ported Box Volume
0.75 cubic feet
Top-Mount Depth (Mounting Depth)
6.89"
Cutout Diameter
9.02"
Shallow Mount Installation
No
T/S Parameters (Electromechanical)
Free-Air Resonance (Fs)
30.12 Hz
Equivalent Compliance (Vas)
23.25 liters
Total Speaker Q Value (Qts)
0.513
Electrical Q Value (Qes)
0.543
Electrical Resistance of Voice Coil (Re)
6.452 ohm
Mechanical Q Value (Qms)
9.228
What is in the box?
Paperwork
User manual
WITB: Subwoofers
Subwoofer
Warranty and Return Policy
Parts Warranty Duration
1 year
Labor Warranty Duration
1 year
Warranty Provider
Manufacturer

Item Details


Manufacturer:

Model Number:

10W6V3D4_OBN

Weight:

24.90lbs

Internal SKU:

10w6v3d4_obn

Internal Product ID:

224008

Customer Ratings & Reviews


JL Audio 10W6v3-D4 (Open Box, Like New) thumbnail image

5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%



Durability
5
Value
4.5
Features
5
Design
5
Usability
5

Customer Reviews

Sort by:

Loading...

Best mix of SQ & SPL ever created.

The following review is for 10W6v3-D4, which is a part of the bundle you are viewing.

The v3 w6's are flat out perfect. I've been waiting along time to get my hands on this. I already had the w6v2 but I wanted the new model because its a piece of fine art. In fact I spent 3 days just admiring it before I got anywhere close to installing it.Given the similarities between the two model, I wasn't expecting too much of a bump in performance but I was dead wrong. The extra 25% in Xmax gives it an even deeper tone and very noticeable SPL gains. The new w6 makes buying a w7 futile. There' is no better mix of SQ and SPL for a sub on the market. I'm running the 1 ten of the 600/1 but to be honest all you really need is 300-400 watts to make this woofer straight out bang with zero distortion. Hands down its the best I've ever had and I've had just about every brand over the last 15 years. Most importantly thank you sonic for making magic happen and getting these subs before 90% of the world hadn't even seen one let alone buy it! Great job guys!

By Donnie E. on August 1, 2013

60 found this helpful


Best company

The following review is for 10W6v3-D4, which is a part of the bundle you are viewing.

JL audio is the best company I've person ever owned. Subwoofers, high, and mid all great products. With the right airspace and correct power you will have the best quality at your fingered tips. JL audio you can't beat it.

By Joe on March 30, 2014

54 found this helpful


Quick service

The following review is for 10W6v3-D4, which is a part of the bundle you are viewing.

I've had JL Audio equipment on and off over 20 years, and have always been impressed by their performance and quality. This sub is typical of JL. Sounds bigger than it is, with tons of deep, yet articulate bass. Far and away the best 10" sub I've ever had. Worth every penny.
Also, received my order on the exact day promised, and I'm in Canada, excellent service.

By Fred on October 13, 2013

50 found this helpful


Best price available!

The following review is for 10W6v3-D4, which is a part of the bundle you are viewing.

I was going to get an open box since it was cheaper however Travis N. the salesman reached out to me and got me an even better deal on a brand new one. Great company and even better customer support. I will definitely be giving Travis N. a shout for future purchases!!

By Steven on July 27, 2020 Checkmark Icon Verified purchase

34 found this helpful
